Titan SUC-30 Benchtop Ultrasonic Cleaner
| Brand | Titan |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Instrument Type | General-Purpose |
| Capacity | 30 L |
| Ultrasonic Frequency | 37 kHz |
| Ultrasonic Power Output | 384 W |
| Adjustable Power | No |
| Adjustable Temperature | No |
| Timer Range | 1–99 min |
| Sound-Dampening Lid | Not Included |
| Drain & Fill Port | Equipped |
Overview
The Titan SUC-30 is a general-purpose benchtop ultrasonic cleaner engineered for consistent, non-invasive cleaning of laboratory glassware, precision components, surgical instruments, and small-volume sample containers. It operates on the principle of acoustic cavitation: high-frequency mechanical vibrations (37 kHz) generate microscopic vacuum bubbles in the cleaning solvent that rapidly collapse, producing localized shockwaves and microstreaming effects. This physical mechanism effectively dislodges particulate contaminants, organic residues, and loosely adhered biofilms without mechanical abrasion or thermal degradation—making it especially suitable for delicate optics, microfluidic devices, and calibration standards where surface integrity is critical.
Designed for routine use in QC labs, academic research facilities, and small-scale manufacturing cleanrooms, the SUC-30 delivers reproducible cleaning performance across standardized protocols. Its robust stainless-steel tank (30 L capacity) supports batch processing of multiple items—including beakers, pipette tips, crucibles, and filter housings—while the integrated timer ensures process repeatability within ±1% tolerance over the full 1–99 minute range.
Key Features
- Stainless-steel tank (30 L internal volume) with corrosion-resistant 304-grade construction for long-term chemical compatibility with aqueous, mild alkaline, and low-concentration solvent-based cleaning solutions.
- Fixed-frequency transducer array operating at 37 kHz—optimized for balanced cavitation intensity and penetration depth in mid-viscosity media; avoids excessive erosion of soft metals or polymer surfaces.
- Stable 384 W total ultrasonic power output, distributed uniformly across the tank base to minimize standing-wave dead zones and ensure homogeneous energy delivery.
- Digital timer with precise 1-minute resolution and automatic shutdown—supports compliance with documented cleaning SOPs and facilitates audit-ready process logging when paired with external data recorders.
- Integrated drain valve and fill port enable rapid solution exchange and residue-free tank rinsing between batches—critical for cross-contamination control in regulated environments.
- No built-in heating element or temperature regulation; intended for ambient-temperature operation only—reducing risk of volatile solvent ignition and eliminating thermal drift during time-sensitive decontamination cycles.
Sample Compatibility & Compliance
The SUC-30 accommodates a broad range of labware geometries and materials, including borosilicate glass, stainless steel, titanium alloys, anodized aluminum, and rigid polymers (e.g., PTFE, PP, PC). It is routinely deployed in applications aligned with ASTM D2603 (Standard Test Method for Sonic Shear Stability of Lubricants), ISO 15883-1 (Washer-disinfectors for medical devices), and USP environmental surface cleaning validation workflows. While not certified for sterile processing per ISO 17664, its consistent cavitation profile supports validated cleaning steps within broader GMP-compliant decontamination sequences. The absence of temperature control ensures adherence to cold-cleaning protocols required for heat-labile biological residues.
Software & Data Management
The SUC-30 is a standalone hardware unit with no embedded firmware, network interface, or proprietary software. All operational parameters are controlled via a tactile membrane keypad and LED display. For laboratories requiring electronic records under FDA 21 CFR Part 11 or GLP/GMP, external USB data loggers or PLC-integrated timers may be used to capture start/stop timestamps and cycle duration. The device’s deterministic behavior—no variable power modulation or adaptive frequency sweeping—ensures full traceability of cleaning conditions across shifts and operators.
Applications
- Routine cleaning of volumetric flasks, burettes, and chromatography vials prior to calibration or trace analysis.
- Removal of solder flux, metal shavings, and polishing compounds from metrology tools and calibration artifacts.
- Pre-sterilization soil removal from reusable surgical instruments in hospital central supply departments.
- Deagglomeration support for nanoparticle suspensions prior to DLS or TEM sample preparation.
- Surface preparation of electrodes, sensors, and MEMS components before functional coating or electrochemical testing.
FAQ
Is the SUC-30 suitable for cleaning delicate optical lenses or semiconductor wafers?
Yes—provided appropriate low-surface-tension solvents (e.g., IPA/water blends) are used and exposure time remains within manufacturer-recommended limits (typically ≤10 min). Cavitation intensity at 37 kHz is moderate and controllable via timer setting.
Can I use acetone or chlorinated solvents in this unit?
No. The SUC-30 is rated exclusively for aqueous and water-miscible solvents. Flammable or halogenated solvents pose fire/explosion hazards and may degrade tank seals.
Does the unit include a degassing function?
No. Degassing must be performed manually by running the unit empty for 5–10 minutes before introducing samples.
What maintenance is required?
Routine cleaning of the tank interior and periodic inspection of the drain valve O-ring. Transducers require no scheduled servicing under normal operating conditions.
Is calibration or qualification documentation available?
Titan provides a Factory Performance Verification Report (FPVR) upon request, confirming nominal frequency output, power stability, and timer accuracy against NIST-traceable references.
