YSI Level Scout VT2-004335 Vented Water Level and Temperature Logger

Overview

The YSI Level Scout VT2-004335 is a high-precision, long-term vented water level and temperature logger engineered for unattended field deployment in hydrogeological monitoring applications. Based on absolute pressure transduction with atmospheric reference via integrated vented cable, the device measures hydrostatic pressure exerted by the water column and compensates for barometric fluctuations in real time—enabling accurate, drift-resistant water level determination over extended periods. Its core sensing architecture employs a 24-bit analog-to-digital converter, piezoresistive silicon pressure sensor, and thermistor-based temperature compensation circuitry, all housed within a NEMA 6P (IP68)-rated titanium alloy body. Designed for multi-year autonomous operation, the VT2-004335 supports up to 600,000 timestamped records (water level, temperature, and UTC time) in non-volatile memory and operates continuously for up to three years on a single user-replaceable battery—without requiring site visits for power maintenance.

Key Features

• Vented pressure measurement configuration optimized for open-well or surface-water applications requiring atmospheric pressure compensation
• Titanium alloy housing (Grade 2) with 19 mm outer diameter—corrosion-resistant, non-magnetic, and suitable for aggressive groundwater chemistries
• Full-scale accuracy of ±0.05 % FS (for water depths >3 m) and ±0.10 % FS TEB (Total Error Band) for shallower deployments
• 24-bit resolution ADC ensures high dynamic range and minimal quantization error across the full 3-meter measurement range
• Configurable sampling modes: Linear, Linear Averaging, Event-Triggered (e.g., threshold crossing), and Logarithmic (adaptive time spacing)
• RS-485 serial interface with built-in transient voltage suppression and fault protection—compatible with industry-standard Modbus RTU protocol
• NEMA 6P/IP68 enclosure rating; rated for continuous submersion at depths up to 300 m (burst pressure: 3× FS; proof pressure: 2× FS)
• Response time <1 ms; time resolution down to 1 second; timekeeping accuracy ±2 minutes per year

Sample Compatibility & Compliance

The VT2-004335 is validated for deployment in boreholes, piezometers, rivers, lakes, reservoirs, and irrigation canals. Its vented design requires a gas-permeable membrane in the field cable (e.g., YSI part 711-S-xx or 741-T-xx) to equalize ambient atmospheric pressure at the sensor diaphragm. This configuration eliminates barometric drift without requiring co-located barometric loggers—though optional BaroScout units (BS2/BS4) may be deployed for redundancy or differential analysis. The instrument complies with ASTM D4043 (Standard Guide for Selection of Instruments for Measuring Ground-Water Levels), ISO 14688-1 (Geotechnical investigation and testing — Identification and classification of soil), and supports data integrity requirements under GLP and GMP frameworks through audit-trail-capable software logging. Its pressure sensor calibration traceability aligns with NIST standards via YSI’s ISO/IEC 17025-accredited calibration laboratory.

Software & Data Management

YSI Data Scout software provides full configuration, visualization, and post-processing capabilities for Level Scout loggers. Users define sampling intervals, trigger conditions, and data export formats (CSV, Excel, or native .lsd binary). The software applies automatic barometric correction using either internal vent reference or external BaroScout inputs, computes derived parameters (e.g., hydraulic head, drawdown), and generates publication-ready plots with dual-axis time-series overlays. Data download occurs via RS-485 communication using YSI’s universal docking interface (778-0-0 or 779-0-0), supporting both batch retrieval and real-time interrogation. Firmware updates and software upgrades are freely available from YSI’s official support portal and include enhanced security features compliant with FDA 21 CFR Part 11 for electronic records and signatures where applicable.

Applications

• Long-term groundwater level monitoring for aquifer sustainability assessments and regulatory reporting (e.g., USGS NWIS, EPA UIC programs)
• Pumping tests (constant-rate, step-drawdown, recovery), slug tests, and hydraulic conductivity estimation per ASTM D4050 and D6028
• Soil vapor extraction (SVE) system performance verification and vadose zone pressure profiling
• Surface water stage monitoring in rivers, streams, and wetlands under USACE, NOAA, or state agency protocols
• Reservoir and detention basin level control with integration into SCADA systems via RS-485 Modbus
• Landfill leachate monitoring and containment system integrity verification per RCRA Subpart F requirements

FAQ

What distinguishes vented from absolute pressure configurations?
Vented models use a gas-permeable cable to reference ambient atmospheric pressure at the sensor, making them ideal for open wells or surface water. Absolute models require a separate barometric logger for compensation and are preferred in sealed or confined aquifer applications.
Can the VT2-004335 be deployed in seawater?
Yes—the Grade 2 titanium housing and PE-jacketed vented cables (e.g., 741-T-xx series) provide excellent resistance to chloride-induced corrosion, supporting long-term marine and estuarine deployments.
How is battery replacement performed in the field?
The unit features a tool-less, O-ring-sealed end cap; battery replacement requires only a standard 10 mm wrench and takes under 90 seconds without compromising IP68 integrity.
Is the device compatible with third-party telemetry systems?
Yes—via RS-485 Modbus RTU output, it integrates with cellular, satellite, or LoRaWAN gateways (e.g., Campbell Scientific CR1000X, Teledyne ISCO 6712) using standard register mapping documentation provided in the Level Scout manual.
What validation documentation is supplied?
Each unit ships with a NIST-traceable calibration certificate, ISO/IEC 17025 test report, RoHS/REACH compliance statement, and CE marking documentation for EU market deployment.
