| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Product Category | Imported Instrument |
| Model | G1 Photochemical |
| Instrument Type | Microchannel Reactor |
| Usable Volume | Small-scale |
| Construction Material | Borosilicate Glass |
| Operating Pressure | Low-pressure (up to 18 bar) |
| Flow Rate Range | 15–250 mL/min |
| LED Wavelength Options | 365 nm, 385 nm, 405 nm, 485 nm, 610 nm, and 4000 K White Light |
| Illumination Intensity | Up to 100 mW/cm² |
| Illumination Geometry | Dual-side transverse illumination through glass walls |
| Thermal Management | Integrated liquid-cooled LED array |
| Scalability Path | Direct process transfer to Corning G3 Photochemical Reactor |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Advanced-Flow® G1 |
| Pricing | Upon Request |
| Brand | Corning |
|---|---|
| Origin | USA |
| Model | Advanced-Flow® G1 |
| Reactor Type | Continuous Flow Microreactor |
| Construction Material | Silicon Carbide (SiC) with Aluminum Heat Exchange Module, PFA Tubing, and Perfluoroelastomer (FFKM) Seals |
| Operating Temperature Range | –60 °C to 200 °C |
| Maximum Operating Pressure | 18 barg (reaction channel), 6 barg (heat exchange layer) |
| Volumetric Flow Rate | 15–250 mL/min |
| Internal Hold-up Volume per Module | ~10 mL |
| Chemical Resistance | HF-compatible, caustic-resistant up to 200 °C |
| Modular Compatibility | Interchangeable with Corning Advanced-Flow® G1 Glass Modules |
| Metal-Free Fluid Path | Yes |
| Scale-up Pathway | Seamless transition from G1 lab-scale to G4 production-scale with no scale-up effect |
| Brand | Corning |
|---|---|
| Origin | USA |
| Model | Corning AFR Lab Microchannel Continuous Flow Reactor |
| Operating Flow Rate | 0–10 mL/min |
| Temperature Range | –40 °C to 200 °C |
| Maximum Operating Pressure | 0–18 bar (gauge) |
| Construction Materials | Specialty glass, PFA, PETE, perfluoroelastomer |
| Reaction Module Volume | 2.7 mL per module |
| Light Source Options | 6 selectable LED wavelengths, irradiance ≥100 mW/cm², dual-side uniform illumination, liquid-cooled, wireless intensity/wavelength control |
| Thermal Management | Integrated portable temperature controller, rapid thermal equilibration |
| Fluid Inlets | 1 gas + 2 or 3 liquid inlets with back-pressure regulation |
| Compliance | Metal-free fluid path, plug-and-play architecture, seamless interoperability with Corning AFR Series reactors |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Imported |
| Model | Cell Culture Roller Bottles |
| Pricing | Available Upon Request |
| Brand | Corning |
|---|---|
| Origin | USA |
| Model | G1 Glass Reactor |
| Flow Rate Range | 15–250 mL/min |
| Operating Temperature | −60 °C to 200 °C |
| Maximum Inlet Pressure (gauge) | 18 bar |
| Material Compatibility | All-glass fluidic path (HF, F₂, and molten alkali above 150 °C excluded) |
| Thermal Management | Dual-zone integrated heat exchange plates (top & bottom) |
| Residence Time | 5.0 s at 100 mL/min |
| Configurability | Standalone or series-connected dual-G1 operation |
| Compliance | Designed for GLP-compliant process development and scalable continuous manufacturing |
| Brand | Corning |
|---|---|
| Origin | USA |
| Model | G1 Hybrid |
| Flow Rate Range | 15–250 mL/min |
| Temperature Range | −60 °C to 200 °C |
| Maximum Inlet Pressure (gauge) | 18 bar |
| Reactor Architecture | Dual-module, modularly configurable (independent or series operation) |
| Core Materials | Corning® Advanced-Flow™ glass modules (optically transparent, photochemically compatible) + silicon carbide (SiC) modules (high chemical resistance, suitable for quenching and aggressive reagents including concentrated alkalis) |
| Compliance | Designed for GLP-compliant lab-scale flow chemistry development |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Product Category | Imported |
| Model | G1 SiC |
| Pricing | Upon Request |
| Instrument Type | Microchannel Reactor |
| Sample Volume Capacity | Trace (≤2.5 mL) |
| Construction Material | Silicon Carbide (SiC) |
| Operating Pressure Range | Medium Pressure (up to 18 bar) |
| Total Internal Volume | 1.7 mL (per reactor unit, configurable) |
| Brand | Corning |
|---|---|
| Origin | USA |
| Model | G3 / G3 Photochemical |
| Instrument Type | Microchannel Reactor |
| Construction Material | Borosilicate Glass |
| Operating Pressure | ≤1.8 MPa (260 psi) |
| Temperature Range | −25 °C to 200 °C |
| Fluid Throughput Capacity | Up to 1000 m³/year |
| Illumination Compatibility | LED-based, six discrete wavelengths (365 nm–455 nm), dual-side irradiation |
| Scalability | Direct process transfer from Corning G1 to G3 platform |
| Regulatory Alignment | Designed for GLP-compliant continuous manufacturing environments |
| Brand | Corning |
|---|---|
| Origin | USA |
| Model | G3 |
| Fluid Throughput Capacity | Up to 1000 m³/year (≈1000 metric tons/year) |
| Temperature Range | –25 °C to 200 °C |
| Maximum Operating Pressure | 18 bar |
| Material | All-Glass Flow Path (Metal-Free) |
| Optical Transmission | Full UV-Vis Transparency (Quartz-Fused Silica Equivalent) |
| Modular Architecture | Interchangeable Reaction Units for Scalable Process Development |
| Photochemical Configuration | Dual-Side Illumination with Optional Wavelength-Selective LED Arrays (6 Standard Wavelengths: 365, 385, 405, 420, 450, 525 nm) |
| Thermal Management | Integrated Liquid-Cooled LED Mounting & Active Reactor Jacketing |
| Scale-Up Pathway | Direct Geometric and Kinetic Scaling from Corning G1 to G3 Platform |
| Brand | Corning |
|---|---|
| Origin | USA |
| Model | G4 |
| Fluid Throughput Capacity | Up to 2000 m³/year |
| Operating Temperature Range | –25 °C to 200 °C |
| Maximum Operating Pressure | 18 bar |
| Material | Metal-Free Carbon–Silicon Alloy Ceramic |
| Scalability | Direct G1-to-G4 Geometric and Performance-Scaled Architecture |
| Regulatory Alignment | Designed for GLP/GMP-compliant environments, compatible with ASTM E2500 and ISO 9001 process validation frameworks |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | G4 |
| Pricing | Upon Request |
| Instrument Classification | Microchannel Reactor |
| Usable Volume | Small-Scale |
| Construction Material | Silicon Carbide (SiC) Ceramic with PFA Tubing and Perlast® Seals |
| Operating Pressure | Low-Pressure (≤10 bar typical, compatible with atmospheric to moderate pressurized operation) |
| Fluid Throughput Capacity | Up to 2000 m³/year |
| Regulatory Compliance | Designed for GLP/GMP-aligned continuous manufacturing environments |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | Microchannel Reactor |
| Quotation | Upon Request |
| Instrument Classification | Microchannel Reactor |
| Sample Volume Capacity | Microliter-to-milliliter scale (microfluidic regime) |
| Construction Material | Chemically resistant glass-ceramic composite |
| Total System Volume | 10 L (modular stack configuration) |
| Maximum Operating Pressure | ≤20 bar (2.0 MPa) |
| Maximum Operating Temperature | 200 °C |
| Vacuum Capability | Not applicable (designed for pressurized operation) |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | Lab |
| Instrument Classification | Microchannel Reactor |
| Usable Volume | Small-Scale |
| Instrument Material | Specialty Glass |
| Operating Pressure | Low to Medium Pressure (0–18 bar g) |
| Capacity | 10 mL |
| Flow Rate Range | 0–10 mL/min |
| Operating Temperature Range | −40 °C to 200 °C |
| Reactor Module Internal Volume | 2.7 mL per module |
| Light Sources | 365 nm, 385 nm, 405 nm, 475 nm, 610 nm, and 4000 K white LED |
| LED Irradiance | >100 mW/cm² (adjustable) |
| Cooling | Liquid-cooled LED modules |
| Control Interface | Wireless wavelength & intensity selection |
| Sealing Materials | PFA, PETE, Perfluoroelastomer |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | LFR |
| Pricing | Upon Request |
| Translation Stage | Contact Manufacturer |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | LFR |
| Flow Rate Range | 0–10 mL/min |
| Operating Temperature Range | −25 °C to 200 °C |
| Maximum Operating Pressure | 18 bar |
| Material | Chemically Resistant Borosilicate Glass |
| Pressure Class | Medium-Pressure |
| Volume Class | Medium-Scale |
| Metal-Free Fluid Path | Yes |
| Scalability | Linear Scale-Up Without Process Deviation |
| Optical Transparency | Full Visual Access for Reaction Monitoring and Photochemistry |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Nebula |
| Pricing | Upon Request |
| Instrument Classification | Microchannel Reactor |
| Usable Volume | Small-scale |
| Material | Specialty Glass |
| Operating Pressure | Low-pressure |
| Capacity | 0.5 mL |
| Additional Application Fields | Food Science, Biotechnology, Agriculture, Petrochemicals |
| Vacuum Capability | 0.6 MPa |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Product Origin | Imported |
| Model | Nebula™ Teaching Platform System |
| Pricing | Available Upon Request |
| Brand | Corning |
|---|---|
| Origin | USA |
| Model | Nebula™ |
| Category | Flow Chemistry Equipment |
| Construction Material | Corning Specialty Glass |
| Channel Geometry | Patented Heart-Shaped Microchannels |
| Control Interface | Touchscreen + Wireless Connectivity |
| Scalability | Seamless Scale-Up Pathway |
| Application Focus | Undergraduate & Graduate Chemical Engineering Education, Flow Synthesis Pedagogy |
| Compliance Context | Designed for GLP-aligned lab instruction and ISO/IEC 17025–compatible teaching environments |
| Brand | Corning |
|---|---|
| Origin | USA |
| Manufacturer Status | Authorized Distributor |
| Origin Category | Imported |
| Model | Zaiput SEP-10 |
| Pricing | Available Upon Request |
