Rigaku
Filter
Showing all 15 results
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | DSC-XRD |
| Configuration | θ–θ goniometer geometry |
| Coupling Type | Synchronized in-situ DSC–XRD |
| Atmosphere Control | Programmable gas environment (N₂, Ar, air, O₂) |
| Temperature Range | RT to 1200 °C (DSC sensor dependent) |
| X-ray Source | Cu Kα (standard), optional Mo or Co anodes |
| Detector | High-speed 1D/2D pixel array detector (e.g., HyPix-400) |
| Data Synchronization | Sub-second temporal alignment of thermal and diffraction signals |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Instrument Type | DSC |
| Temperature Range | Ambient to 1500 °C |
| Manufacturer Status | Authorized Distributor (Non-OEM) |
| Origin Category | Imported Instrument |
| Model | DSC8271 |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Instrument Type | DSC |
| Temperature Range | −170 °C to 725 °C |
| Configuration | Imported System |
| Distribution Model | Authorized Distributor |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | Micro-Z |
| Instrument Type | Scanning WDXRF |
| X-ray Tube Power | 40 W |
| Elemental Range | S (Sulfur) |
| Compliance | ASTM D2622, ISO 20884, JIS K 2541-7 |
| Cooling | Air-cooled (no water or gas required) |
| Power Supply | 220 V AC, 2 A |
| Sample Preparation | None required |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | Mini-Z |
| Detection Principle | Wavelength Dispersive X-Ray Fluorescence (WDXRF) |
| Sample Throughput | 6-position automated sample changer |
| Power Requirement | 220 V AC, 2 A |
| Dimensions | 640 × 580 × 580 mm (W × D × H) |
| Weight | 65 kg |
| Detection Limit for S | 0.3 ppm |
| Precision (S at 10 ppm in gasoline) | σ = 0.17 ppm |
| S Quantification Range | 1 ppm – 4 wt% |
| Compliant Standards | ASTM D2622, ISO 20884, JIS K2541-7 |
| Cooling | Air-cooled (no water or gas required) |
| Operation Interface | Touchscreen control panel |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | Miniflex 600 |
| X-ray Tube Power | 600 W |
| Dimensions (W×H×D) | 560 × 700 × 395 mm |
| Weight | 80 kg |
| Goniometer Accuracy | ±0.01° 2θ |
| Safety | Interlocked X-ray shutter with automatic beam cutoff during sample loading |
| Detector | Standard scintillation counter |
| Sample Stage | Manual stage standard |
| Software Suite | PDXL (with ICDD PDF-4+ database), Qualitative & Quantitative Analysis modules, Multi-scan acquisition, Dust-specific quantification (e.g., respirable crystalline silica per ISO 16258-1, NIOSH 7500) |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | MiniFlex600 |
| Instrument Type | Powder X-ray Diffractometer |
| Power Rating | 0.0001 kW |
| Dimensions | 560 W × 460 D × 700 H mm |
| Detector Type | Advanced Semiconductor Detector |
| Software Suite | PDXL (Phase Identification, Quantitative Analysis, Rietveld Refinement, Crystal Structure Visualization) |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | Simultix15 |
| Instrument Type | Simultaneous Multi-Channel WDXRF |
| X-ray Tube Power | 4 kW |
| Elemental Range | Beryllium (Be, Z=4) to Uranium (U, Z=92) |
| Simultaneous Channels | Up to 40 elements |
| Detector System | High-speed pulse-height-analyzed proportional counters with background subtraction circuitry |
| Vacuum System | Dual-stage vacuum pump with auto-stabilized vacuum control |
| Software | Multi-tasking, multi-window FP (Fundamental Parameters) quantification software with Chinese GUI (localized for operator interface only) |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Instrument Type | Powder X-ray Diffractometer |
| Model | SmartLab |
| X-ray Source | 3 kW or 9 kW sealed-tube generator |
| Anode Materials | Cu, Cr, Fe, Co, Ni, Mo, Ag, Au (selectable) |
| Goniometer Radius | 300 mm |
| Detector | HyPix-3000 2D pixel array detector |
| Optics | CBO-Auto (automated beam optics switching) and CBO-μ (high-resolution micro-beam optics) |
| Primary Source | PhotonMax high-brilliance X-ray tube |
| Software | SmartLab Studio II (with in-situ analysis modules) |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Instrument Type | Powder X-ray Diffractometer |
| Model | SmartLab SE |
| X-ray Generator Power | 3 kW |
| Goniometer Radius Options | 185 mm (standard), 285 mm (optional), 280 mm (TTR configuration) |
| Optical Configurations | Automated切换 between Bragg-Brentano (focused beam) and parallel-beam geometries |
| Detector | Rigaku HyPix-400 or equivalent high-speed 2D photon-counting detector |
| Safety Enclosure | Interlocked, fail-safe shutter-equipped X-ray housing |
| Goniometer Orientation | Horizontal |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | Supermini200 |
| Instrument Type | Scanning WDXRF |
| X-ray Tube Power | 200 W |
| Elemental Range | O (8) to U (92) |
| Cooling | Air-cooled (no liquid nitrogen or external water cooling required) |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | TG-DTA8122 |
| Temperature Range | Ambient to 1500 °C |
| Measurement Principle | Horizontal Dual-Cantilever Differential DTA with Integrated Thermogravimetry (TG) |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | Thermo Mass |
| Coupling Type | TGA-MS |
| Mass Range | up to m/z 400 |
| Ionization Method | Fragment-Free Photoionization |
| Interface Technology | Patented Skimmer Interface |
| Real-Time Synchronization | Quadruple Concurrent Measurement (TGA, DTG, MS Total Ion Current, Selected Ion Monitoring) |
| Compliance | Designed for ISO 11358, ASTM E1131, and USP <621> thermal analysis workflows |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | TMA8311 |
| Maximum Measurement Temperature | 1500 °C |
| Measurement Principle | Dual-rod Differential Dilatometry |
| Instrument Type | Thermomechanical Analyzer (TMA) |
| Brand | Rigaku |
|---|---|
| Origin | Japan |
| Model | ZSX Primus II |
| Excitation Source | End-window Rh-target X-ray tube (3 kW or 4 kW) |
| High-voltage Generator | High-frequency inverter type |
| Max. Output | 60 kV / 150 mA (4 kW) |
| Stability | ±0.005% (against ±10% AC line fluctuation) |
| Cooling | Integrated water-cooling system |
| Sample Changer Capacity | Up to 48 positions |
| Sample Dimensions | Ø51 mm × 40 mm (H) |
| Analyzed Area | Up to Ø35 mm |
| Sample Rotation | 30 rpm |
| Primary Beam Filters | Al, Ti, Cu, Zr (4-position auto-switch) |
| Collimators | 6 automatic apertures (Ø35, 30, 20, 10, 1, 0.5 mm) |
| Divergence Slits | 3 types (standard, high-resolution, ultra-light-element option) |
| Receiving Slits | SC and F-PC compatible |
| Goniometer | Independent θ–2θ drive |
| Angular Range | SC: 5°–118°, F-PC: 13°–148° |
| Max. Scan Speed | 1400°/min (2θ) |
| Continuous Scan Rate | 0.1–240°/min |
| Crystal Changer | 10-position auto-exchange |
| Standard Crystals | LiF(200), Ge, PET, RX25 |
| Optional Crystals | LiF(220), RX4, RX9, RX35–RX80, RX61F, TAP |
| Vacuum System | Dual-chamber rapid evacuation (dual-pump configuration) |
| Detectors | SC scintillation counter (1000 kcps linearity) for heavy elements |
| Pulse Height Analyzer (PHA) | Auto-adjustment (PAS, Rigaku patent) |
| F-PC Anode Wire Cleaning | Automatic thermal cleaning (ACC, Rigaku patent) |
| Optional Accessories | He purge module (with baffle), temperature-controlled sample stage (36.5 °C), CCD-based micro-imaging (100 µm resolution, 0.5 mm micro-area analysis & mapping), r-θ sample stage (Rigaku patent) |
| Software | NEW SQX (qualitative ID, background subtraction, smoothing, peak deconvolution, calibration curve method per JIS, matrix correction, standardless quantification, EZ-scan templates, auto-aperture selection, precision testing, email reporting, multi-standard management) |
| Compliance | Designed for GLP/GMP environments |
