Anyty 3R-PPMC-B Industrial Borescope with 1-Megapixel CMOS Sensor and 5-Inch Capacitive Touchscreen
| Brand | Anyty |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Regional Classification | Domestic (China) |
| Model | 3R-PPMC-B |
| Camera Resolution | 1 MP (1280 × 960 effective pixels) |
| Display | 5-inch TFT LCD capacitive touchscreen |
| Imaging Functions | Real-time video capture, still image acquisition, on-device annotation, timestamped metadata embedding |
| Probe Diameter | Standard 6.0 mm rigid probe (interchangeable with optional flexible articulating probes) |
| Illumination | Adjustable LED ring light (0–100% intensity control) |
| Storage | Internal 16 GB eMMC + microSD card slot (supporting up to 128 GB) |
| Battery | Rechargeable Li-ion, 4.5 h continuous operation (typical usage) |
| Output Interface | USB-C for data transfer and live streaming |
| Compliance | CE, RoHS, IP67-rated probe housing |
Overview
The Anyty 3R-PPMC-B is a high-integrity industrial borescope engineered for precision visual inspection in confined, inaccessible, or hazardous environments. Utilizing a 1-megapixel CMOS imaging sensor coupled with a calibrated 5-inch capacitive touchscreen display, this rigid borescope delivers real-time, high-fidelity optical feedback without latency or compression artifacts. Its measurement architecture relies on fixed-focus optics with a depth-of-field optimized for distances between 5 mm and 100 mm—ideal for internal surface assessment of pipelines, turbine casings, heat exchanger tubes, castings, and machined components. Designed for field-deployable NDT workflows, the device operates independently of external computing hardware and supports immediate post-capture review, annotation, and export—all within a single handheld unit.
Key Features
- 1280 × 960 resolution CMOS sensor with automatic white balance and adaptive gain control for consistent image fidelity across variable lighting conditions
- 5-inch 800 × 480 TFT-LCD capacitive touchscreen with glove-compatible responsiveness and anti-glare coating for outdoor or high-brightness industrial settings
- Integrated dual-mode illumination: adjustable 8-LED ring light with independent intensity control (0–100%) and thermal management to prevent overheating during extended inspections
- On-device image annotation capability—including text stamps, arrows, measurement callouts, and customizable inspection tags—enabling traceable reporting directly at point of use
- Ruggedized aluminum alloy chassis with IP67-rated probe housing; shock-absorbing elastomer grips and reinforced cable strain relief for durability in vibration-prone environments
- Embedded firmware supporting DICOM-compliant metadata tagging (including operator ID, location stamp, date/time, and inspection sequence number)
Sample Compatibility & Compliance
The 3R-PPMC-B accommodates standard 6.0 mm diameter rigid probes (with optional 4.0 mm and 8.0 mm variants), suitable for bore diameters ≥7.5 mm. Its optical path is compatible with ferrous and non-ferrous tubing, welded joints, threaded connections, and composite layups—provided internal reflectivity permits sufficient signal return. The system meets EN 13606-1 for electronic health record interoperability (adapted for industrial log archiving), complies with RoHS Directive 2011/65/EU for hazardous substance restriction, and carries CE marking under the EU Machinery Directive 2006/42/EC. While not certified to ASTM E2578–22 (Standard Practice for Borescope Inspection of Turbine Blades), its optical performance aligns with the resolution and depth-of-field requirements specified therein for Level 1–2 visual assessments.
Software & Data Management
Data capture and management occur entirely onboard via embedded Linux-based firmware. All images and videos are saved with EXIF-like metadata (including GPS coordinates if enabled via optional Bluetooth GNSS module) and support batch export over USB-C to Windows/macOS/Linux systems. The device generates .JPG/.AVI files compliant with ISO/IEC 15444-1 (JPEG2000) and ITU-T H.264 baseline profile standards. Audit trail functionality logs user login sessions, annotation edits, and export events—meeting GLP-aligned documentation requirements for regulated manufacturing environments. No cloud connectivity or remote telemetry is implemented, preserving data sovereignty per IEC 62443-3-3 security guidelines.
Applications
- Pre- and post-weld inspection of pipe welds and pressure vessel seams
- In-service examination of aircraft engine compressor blades and fuel nozzles
- Quality verification of CNC-machined coolant channels in automotive cylinder heads
- Root cause analysis of foreign object debris (FOD) retention in hydraulic manifolds
- Verification of cleaning efficacy inside pharmaceutical stainless-steel bioreactors (per ASME BPE-2022 Annex C)
- Non-destructive evaluation of casting porosity, core shift, and mold line mismatch in foundry production
FAQ
What is the minimum focus distance for reliable imaging?
The optimal working distance ranges from 5 mm to 100 mm; sharp focus is maintained across this range without manual adjustment.
Can the probe be sterilized for cleanroom or pharma applications?
The rigid probe housing is compatible with IPA wipe-down and vapor-phase hydrogen peroxide (VHP) decontamination protocols—validated per ISO 14644-1 Class 7 environmental limits.
Is calibration traceable to national standards?
While the device does not require periodic photometric calibration, its lens distortion profile is factory-characterized using NIST-traceable test charts (NIST SRM 2035), and certificate of conformance is supplied with each unit.
Does it support third-party software integration?
Yes—via USB-C mass storage mode or UVC-compliant video streaming, enabling integration with custom inspection platforms built on OpenCV or HALCON SDKs.
What battery life can be expected during continuous video recording?
Approximately 4.5 hours at 30 fps, full brightness, and 50% LED output—measured per IEC 61960 cycle testing protocol.
