art photonics FBC-CO/CO2-10-SMA 905 Fiber Coupler for CO and CO₂ Laser Beam Combining
| Brand | art photonics |
|---|---|
| Origin | Germany |
| Model | FBC-CO/CO2-10-SMA 905 |
| Connector Type | SMA 905 |
| Wavelength Range | 5–6 µm (CO) & 9–11 µm (CO₂) |
| Component Category | Optical Coupling Element |
| Compliance | CE-marked, RoHS-compliant |
| Mounting Interface | Standard optical breadboard-compatible flange |
Overview
The art photonics FBC-CO/CO2-10-SMA 905 is a precision-engineered fused-fiber beam combiner designed specifically for simultaneous delivery and spatial superposition of mid-infrared laser radiation from carbon monoxide (CO) and carbon dioxide (CO₂) gas lasers. Operating within the fundamental vibrational absorption bands—5–6 µm for CO and 9–11 µm for CO₂—the coupler employs thermally stable, low-OH silica-based fiber preforms fused under controlled atmospheric conditions to preserve waveguide integrity and minimize modal distortion. Unlike broadband dichroic mirrors or free-space beam combiners, this all-fiber solution eliminates alignment sensitivity, reduces beam walk-off, and maintains polarization fidelity across both input channels. It is optimized for continuous-wave (CW) and pulsed laser systems with average powers up to 10 W per channel, making it suitable for applications requiring stable, maintenance-free co-propagation of dual-wavelength IR beams in compact optical architectures.
Key Features
- Fused biconical taper design enabling >92% combined transmission efficiency at both CO and CO₂ wavelengths
- SMA 905 connectors with precision ceramic ferrules ensuring repeatable insertion loss (<0.8 dB per channel) and angular alignment tolerance <±0.3°
- Hermetically sealed stainless-steel housing rated IP65 for operation in laboratory environments with ambient humidity up to 85% RH
- Thermal stability tested from −10 °C to +60 °C; insertion loss drift <±0.15 dB over full temperature range
- No active cooling required; passive thermal management via aluminum alloy heat-sink baseplate
- Compliant with IEC 61300-2-4 (fiber optic connector durability) and IEC 61300-2-17 (tensile load testing)
Sample Compatibility & Compliance
The FBC-CO/CO2-10-SMA 905 is compatible with standard multimode mid-IR fibers including fluoride (ZBLAN), chalcogenide (As₂S₃), and hollow-core photonic bandgap fibers when terminated with SMA 905 interfaces. It supports beam diameters up to 200 µm (1/e²) per input port and accommodates numerical apertures up to NA = 0.22. The device conforms to ISO 10110-7 for surface quality (scratch-dig 20–10), EN 61000-6-3 for electromagnetic compatibility, and meets the mechanical robustness requirements of MIL-STD-810G Method 514.6 for vibration resistance. All units undergo 100% optical throughput verification at both 5.3 µm and 10.6 µm using NIST-traceable calibrated power meters prior to shipment.
Software & Data Management
As a passive optical component, the FBC-CO/CO2-10-SMA 905 does not incorporate embedded firmware or digital interfaces. However, it is fully interoperable with industry-standard laser control platforms—including Thorlabs Kinesis, Newport Motion Control Suite, and LabVIEW-based DAQ systems—when integrated into larger beam delivery assemblies. For traceability and quality assurance, each unit ships with a Certificate of Conformance (CoC) listing serial-numbered test data: insertion loss per channel, return loss (>45 dB), and polarization-dependent loss (<0.25 dB). These records support GLP-compliant documentation workflows and are compatible with LIMS integration via CSV export.
Applications
- Multi-wavelength IR spectroscopy setups requiring synchronized CO/CO₂ excitation for isotopic ratio analysis (e.g., δ¹³C, δ¹⁸O)
- Combined photothermal and photoacoustic imaging systems where CO provides high-resolution structural contrast and CO₂ enables deep-tissue thermal modulation
- Industrial laser processing stations integrating CO for fine ablation (e.g., polymer microstructuring) and CO₂ for bulk material removal
- Atmospheric simulation chambers utilizing dual-laser differential absorption lidar (DIAL) configurations
- Calibration sources for Fourier-transform infrared (FTIR) spectrometers operating across the 4–12 µm spectral window
