Erlab Halo P Smart Professional Laboratory-Grade Air Purifier

Overview

The Erlab Halo P Smart is a professional laboratory-grade air purifier engineered for continuous, high-efficiency removal of airborne biological and particulate hazards in controlled scientific environments. It operates on a dual-stage filtration architecture combining pre-filtration with certified high-efficiency particle retention—specifically designed to meet the stringent air quality requirements of biosafety laboratories, analytical testing facilities, cleanrooms (ISO Class 5–8), and containment workspaces where pathogen mitigation is critical. Unlike general-purpose air cleaners, the Halo P Smart is validated for use in proximity to biosafety cabinets (BSCs), fume hoods, and laminar flow workstations, providing supplementary air decontamination without compromising airflow integrity or safety cabinet certification. Its core function relies on forced-air circulation through rigorously tested, EN 1822-compliant ultra-low penetration air (ULPA) or high-efficiency particulate air (HEPA) filter media—capable of capturing particles as small as 0.1 µm with defined minimum efficiency at the most penetrating particle size (MPPS).

Key Features

• Configurable filtration module: Standard HEPA H14 filter (≥99.995% @ 0.1–0.2 µm MPPS) or optional ULPA U17 filter (≥99.999995% @ 0.1 µm), both independently certified per EN 1822-1:2019 and tested in accordance with ISO 14644-3 for cleanroom compatibility.
• Integrated real-time particle sensor with digital display showing PM_1.0, PM_2.5, and PM₁₀ concentrations (μg/m³) and instantaneous CADR (Clean Air Delivery Rate) in m³/h.
• Quiet operation mode (<45 dB(A) at 1 m) with multi-stage fan control enabling precise airflow adjustment (120–380 m³/h) to match room volume and occupancy profiles.
• Robust aluminum-alloy housing with antimicrobial coating; fully compliant with IEC 61000-6-3 (EMC) and IEC 60335-1 (safety) for uninterrupted operation in regulated lab infrastructure.
• Filter life monitoring system with visual and audible alerts; integrated RFID tag enables traceable filter replacement history aligned with GLP documentation requirements.

Sample Compatibility & Compliance

The Halo P Smart is validated for continuous operation in Class II and III biosafety laboratories handling Risk Group 2 and 3 microorganisms (per WHO Laboratory Biosafety Manual, 4th ed.). Its ULPA/U17 configuration satisfies the particle removal performance criteria referenced in ISO 14644-1 for ISO Class 3–5 environments and supports compliance with USP and for sterile compounding and hazardous drug handling. The unit is CE-marked and conforms to EN 1822-3:2020 for filter classification, EN 13141-7:2021 for residential and commercial air cleaning devices, and meets the mechanical and electrical safety requirements outlined in EN 61000-6-2 and EN 61000-6-4. All filter media are manufactured under ISO 9001-certified processes and undergo individual leak testing prior to installation.

Software & Data Management

The Halo P Smart includes an embedded data logging module supporting up to 30 days of timestamped environmental records (PM concentration, runtime, fan speed, filter status). Data export is available via USB-C interface in CSV format for integration into LIMS or electronic lab notebooks (ELN). Optional Ethernet/Wi-Fi connectivity enables remote monitoring through Erlab’s centralized AirGuard™ platform—supporting audit trails, user access controls, and automated report generation compliant with FDA 21 CFR Part 11 requirements for electronic records and signatures. All firmware updates are digitally signed and version-controlled to ensure regulatory traceability.

Applications

• Mitigation of aerosolized pathogens during microbiological culture handling, centrifugation, and pipetting operations.
• Supplemental air decontamination in PCR preparation areas to prevent cross-contamination between samples.
• Continuous background air cleaning in cytotoxic drug preparation suites (e.g., oncology pharmacies) where ULPA-level filtration is mandated by USP .
• Reduction of ambient bioaerosol load in animal holding rooms and vivarium support labs meeting AAALAC International standards.
• Integration with HVAC bypass systems in renovation-constrained legacy labs requiring localized air quality enhancement without duct modification.

FAQ

Does the Halo P Smart require validation for use in GMP or GLP environments?
Yes—filter integrity testing (e.g., DOP/PAO scanning per ISO 14644-3) and operational qualification (OQ) protocols are provided in the Installation & Qualification (IQ/OQ) package for compliance with EU Annex 1 and FDA guidance on environmental monitoring.
Can the unit be installed inside a biosafety cabinet?
No—it is designed for ambient room air purification only and must be placed outside the BSC work area to avoid disrupting inward face velocity and alarm thresholds.
Is filter replacement documented for audit purposes?
Yes—each filter carries a serialized RFID tag; replacement events are automatically logged with date/time stamp, operator ID (if networked), and filter lot number—exportable for internal audits or regulatory inspections.
What is the recommended maintenance interval for pre-filters?
Pre-filters should be inspected every 30 days and replaced every 3–6 months depending on ambient dust loading; extended service life is possible in low-particulate environments such as ISO Class 5 cleanrooms.
Does Erlab provide IQ/OQ documentation for this model?
Yes—fully customizable IQ/OQ templates compliant with ISO/IEC 17025 and ASTM E2500-22 are included with purchase and supported by Erlab’s global validation services team.
