Galvanic AccuSeries Online Over-Alkalinity Analyzer
| Brand | Galvanic |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Imported |
| Model | AccuSeries |
| Pricing | Upon Request |
| Display | High-resolution LCD with auxiliary programmable keypad |
| Communication Interfaces | 4–20 mA, Modbus TCP/IP, RS232, RS485, USB, GUI PC direct connection, relay outputs |
| Architecture | Modular analytical method design with field-configurable protocols |
| Diagnostics | Remote self-diagnosis with real-time alerts for sample absence, reagent level, system fault, and maintenance status |
| Automation | Fully automated 24/7 operation including auto-calibration, auto-zeroing, reagent dispensing, line flushing, and endpoint detection |
| System Isolation | Physically separated electronic control unit and wet chemistry module |
| Corrosion Resistance | IP66-rated enclosure with H₂S- and Cl₂-resistant materials |
| Electronics Design | Partitioned motherboard architecture—failure in flow control module does not interrupt main processor or DCS/PLC communication |
| Programmability | User-defined assay sequences (reagent addition order, pre-/post-measurement rinse cycles, auto-zero timing) |
| Analytical Method | On-line potentiometric titration using 0.01 N HCl standard solution with pH electrode endpoint detection |
| Range Options | 0–1 g/L or 0–0.5 g/L OH⁻ + CO₃²⁻ (chlor-alkali brine application) |
| Accuracy | ±1% of full scale |
| Linearity | ±1% of full scale |
| Repeatability | ±1% of full scale |
| Response Time | 3–12 minutes per analysis cycle |
| Operating Ambient Temperature | –20 °C to +60 °C |
| Dimensions (H×W×D) | 1016 mm × 406 mm × 241 mm |
| Weight | 45.3 kg |
| Power Requirement | 10–32 VDC or 90–240 VAC |
| Power Consumption | 100 W |
| Analog Outputs | Up to eight isolated 4–20 mA channels |
| Digital Communication | Modbus RTU (RS232/RS485), Modbus TCP/IP |
Overview
The Galvanic AccuSeries Online Over-Alkalinity Analyzer is an industrial-grade, fully automated process analyzer engineered for continuous, real-time quantification of total hydroxide (OH⁻) and carbonate (CO₃²⁻) alkalinity in saturated brine streams within chlor-alkali production facilities. It operates on the principle of on-line potentiometric acid-base titration—using a precisely metered 0.01 N hydrochloric acid titrant and a high-stability pH electrode to detect the stoichiometric endpoint corresponding to complete neutralization of OH⁻ and CO₃²⁻ species. Unlike laboratory-based offline methods, the AccuSeries delivers traceable, repeatable measurements without manual intervention, enabling closed-loop control of caustic soda purity, membrane protection, and electrolyzer efficiency. Its design adheres to ISA-84 and IEC 61511 functional safety guidelines for SIL-2 capable instrumentation in hazardous area deployments.
Key Features
- Modular, field-reconfigurable assay architecture supporting custom titration protocols—including variable reagent addition sequences, programmable pre- and post-analysis rinses, and adaptive zero-point correction.
- Physically segregated electronics and wet-chemistry modules ensure operational continuity: failure in fluidic control does not compromise data acquisition or DCS/PLC communication integrity.
- Multi-stream capability—up to six independent sample inlets—enables parallel monitoring of primary brine, secondary wash lines, or regeneration loops from a single analyzer chassis.
- Robust environmental resilience: IP66-rated stainless-steel and polymer composite housing resists chloride ion penetration, hydrogen sulfide vapor, and ambient moisture—validated for installation in unconditioned outdoor enclosures or high-humidity electrolysis cell rooms.
- Comprehensive remote diagnostics suite with predictive alerting for low reagent volume, clogged tubing, electrode drift, air-in-line, and calibration deviation—integrated into standard Modbus and OPC UA data pipelines.
- Eight configurable 4–20 mA analog outputs support redundant signal routing to distributed control systems, safety instrumented systems (SIS), or historian databases—each channel assignable to raw concentration, status flags, or diagnostic codes.
Sample Compatibility & Compliance
The AccuSeries is specifically validated for saturated sodium chloride brine (25–32% w/w NaCl) at temperatures ranging from 25 °C to 90 °C and pressures up to 6 bar(g). It tolerates suspended solids ≤50 µm and turbidity <100 NTU without filtration. All wetted components—including peristaltic pump tubing, titration cell, and pH sensor housing—comply with FDA 21 CFR Part 11 requirements for audit-trail-enabled operations when paired with Galvanic’s optional SecureLog software. The analyzer meets CE marking directives (EMC 2014/30/EU, Low Voltage 2014/35/EU), ATEX II 2G Ex d IIB T4 Gb (for optional hazardous-area configuration), and ISO 9001-certified manufacturing standards. Calibration traceability aligns with NIST-traceable HCl standard solutions and certified pH buffer sets (ISO 3696 Grade 2 water).
Software & Data Management
Local operation is managed via a 7-inch high-brightness LCD interface with tactile keypad—supporting menu-driven setup, live trend visualization, and event log review. For enterprise integration, the AccuSeries provides native Modbus TCP/IP and RTU (RS485) protocols compliant with DCS/SCADA architectures. Optional SecureLog software enables full 21 CFR Part 11 compliance—including electronic signatures, role-based access control, immutable audit trails, and automatic backup to network storage. All measurement data includes timestamp, operator ID (if authenticated), calibration history, and raw sensor voltage traces—exportable in CSV or XML formats compatible with LIMS and MES platforms.
Applications
- Real-time over-alkalinity control in membrane-cell chlor-alkali plants to prevent caustic carryover and anode coating degradation.
- Monitoring carbonate buildup in brine purification units (e.g., lime-soda softening or ion exchange regenerants).
- Quality assurance of regenerated brine entering electrolyzers—ensuring OH⁻ + CO₃²⁻ remains below 0.3 g/L to meet ASTM D1129 and ISO 9297 specifications.
- Supporting GMP-compliant batch release decisions in pharmaceutical-grade sodium hydroxide manufacturing.
- Integration with advanced process control (APC) strategies for dynamic caustic dosing optimization based on feed brine composition.
FAQ
What titration method does the AccuSeries use, and how is endpoint detection achieved?
It employs potentiometric titration with standardized 0.01 N HCl and a dual-junction pH electrode calibrated against NIST-traceable buffers; endpoint is determined by first-derivative analysis of the pH curve.
Can the AccuSeries operate unattended for extended periods?
Yes—designed for 24/7 autonomous operation with scheduled auto-calibration, reagent replenishment alerts, and self-cleaning cycles; mean time between unscheduled maintenance exceeds 6 months under typical chlor-alkali duty cycles.
Is the analyzer suitable for Class I, Division 2 hazardous locations?
The base model is rated for general-purpose industrial environments; optional ATEX/IECEx-certified versions are available for Zone 1/21 deployment with intrinsically safe signal conditioning.
How is data integrity ensured during power interruptions?
Non-volatile memory retains all configuration, calibration coefficients, and recent measurement logs; upon power restoration, the system resumes operation without manual reset and flags any interrupted assay cycle in the event log.
Does the AccuSeries support third-party SCADA integration?
Yes—through open Modbus TCP/IP and RTU implementations; no proprietary drivers or middleware required; tested with Siemens PCS7, Emerson DeltaV, Honeywell Experion, and Yokogawa CENTUM VP.
