Sineo MDS-15 High-Throughput Sealed Microwave Digestion/Extraction/Synthesis Workstation
| Brand | Sineo |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic (China) |
| Model | MDS-15 |
| Pricing | Upon Request |
| Cavity Grade | Industrial-Grade |
| Batch Capacity | 16 Samples |
| Microwave Source | Dual Magnetron |
| Max Temperature | 310 °C |
| Max Pressure | 15 MPa |
Overview
The Sineo MDS-15 High-Throughput Sealed Microwave Digestion/Extraction/Synthesis Workstation is an industrial-grade platform engineered for precision sample preparation under controlled high-pressure and high-temperature microwave conditions. Based on over 30 years of microwave chemistry system development, the MDS-15 employs sealed-vessel, non-pulsed, frequency-variable 2450 MHz microwave irradiation to enable reproducible thermal decomposition, targeted analyte extraction, and accelerated reaction kinetics in closed systems. Its core architecture supports three primary operational modes—microwave-assisted acid digestion, solvent-based extraction, and high-pressure synthetic chemistry—making it suitable for laboratories requiring regulatory-compliant sample preparation across environmental, petrochemical, polymer, food, and clinical research domains. The workstation operates within a 65 L 316L stainless steel cavity with dual-layer PFA coating, rated for continuous service up to 310 °C and 15 MPa (2200 psi), meeting foundational mechanical and chemical durability requirements for GLP-aligned workflows.
Key Features
- Industrial-grade 316L stainless steel cavity (≥3 mm wall thickness) with dual-face PFA coating, certified for 5-year corrosion resistance under aggressive HNO₃/HF/HCl vapor exposure
- Self-ejecting six-layer structural safety door with dual electronic/mechanical interlocks, compliant with IEC 61000-4-2 and EN 61000-6-4 electromagnetic safety standards
- Safety Bolt pressure-release mechanism: non-sacrificial, zero-consumable design enabling quantitative pressure relief at preset thresholds without rupture or replacement
- Xtra Fiber™ aerospace-grade composite outer vessels—fully encapsulated in PFA—with burst resistance ≥70 MPa (10,000 psi) and thermal stability to 600 °C
- Uni-Turn synchronous rotation technology: eliminates sensor cable torsion while maintaining real-time, high-fidelity pressure (±0.01 MPa) and temperature (±0.1 °C) monitoring via piezoelectric and Pt100 sensors
- Dual magnetron configuration with 2D orthogonal emission geometry ensures uniform field distribution and >92% microwave energy coupling efficiency
Sample Compatibility & Compliance
The MDS-15 accommodates challenging matrices including petroleum distillates, polyolefins, silicone elastomers, animal fats, and plant waxes—samples historically resistant to conventional open-vessel digestion. Its TFM inner vessels (100 mL capacity, 310 °C/15 MPa rating) support EPA Method 3052, ASTM D5511, ISO 11885, and USP heavy metal digestions. All hardware and firmware comply with CE marking directives, RoHS 2011/65/EU, and are validated for audit readiness under FDA 21 CFR Part 11 when paired with optional electronic signature modules. The passive safety architecture—including top-mounted Safety Bolt release, redundant pressure transducers, and automatic cavity cooling (<15 min to ambient) —meets ISO/IEC 17025 clause 6.4.4 for equipment suitability verification.
Software & Data Management
The integrated control interface features a high-resolution LED display with real-time graphical plotting of temperature, pressure, power, and time profiles. Preloaded method libraries include 120+ validated protocols aligned with US-EPA, ASTM, and ISO reference procedures; users may create, version-control, and export custom methods with metadata tagging (operator ID, batch ID, audit trail timestamp). Data export supports CSV and XML formats compatible with LIMS integration. Optional IR full-can scanning enables parallel thermal mapping across all 16 positions, supporting multi-point validation per ISO/IEC 17025:2017 Annex A.3. Audit trails record all parameter modifications, start/stop events, and safety interventions with immutable timestamps.
Applications
- Regulatory digestion of soil, sediment, and sludge per EPA 3052 for ICP-MS trace metal quantification
- Complete mineralization of polyethylene, polycarbonate, and epoxy resins prior to halogen analysis (ASTM D7359)
- Accelerated lipid extraction from marine tissue using ethanol/hexane mixtures under subcritical conditions
- Solvothermal synthesis of MOFs and perovskite precursors at 220 °C/12 MPa with inert gas purging capability
- Hydrothermal carbonization of lignocellulosic biomass for biochar characterization studies
FAQ
What is the maximum batch size supported by the MDS-15?
The standard rotor configuration supports 15 positions; an optional upgrade enables 16-sample throughput per run.
Does the system support automated method validation per ISO/IEC 17025?
Yes—integrated calibration logging, sensor drift compensation algorithms, and electronic audit trails satisfy Clause 7.7.1 for measurement traceability.
Are consumables required for the Safety Bolt pressure-release system?
No—the Safety Bolt is a permanent, non-sacrificial component with no scheduled replacement interval.
Can the MDS-15 be integrated into a laboratory automation framework?
It provides RS-232 and Ethernet ports for SCADA-level communication and supports Modbus TCP protocol for PLC interfacing.
Is PFA coating on the cavity covered under warranty?
Yes—Sineo offers a documented 5-year limited warranty against coating delamination or chemical degradation under normal operating conditions.
