| Brand | AET |
|---|---|
| Origin | Japan |
| Model | Coaxial Resonant Cavity System |
| Frequency Range | 800 MHz – 9.4 GHz |
| Permittivity (ε′) | 1–15 |
| Accuracy | ±1% |
| Loss Tangent (tan δ) | 0.001–0.1 |
| Accuracy | ±5% |
| Resonant Modes | Type A (0.8 / 2.45 / 4.2 / 5.8 / 7.6 GHz) and Type B (1.0 / 3.1 / 5.2 / 7.3 / 9.4 GHz) |
| Measurement Principle | High-Q coaxial cavity resonance with 3D electromagnetic field simulation (CST Microwave Studio®) |
| Brand | AET |
|---|---|
| Origin | Japan |
| Model | Powder Resonant Cavity System |
| Frequency Range | 1–10 GHz |
| Permittivity Range | ε′ = 1–6 |
| Permittivity Accuracy | ±1% |
| Loss Tangent Range | tan δ = 0.001–0.01 |
| Loss Tangent Accuracy | ±5% |
| Minimum Sample Diameter | ≥5.5 mm |
| Sample Form | Powders (quartz tube loaded) and Low-Polarity Liquids |
| Brand | AET |
|---|---|
| Origin | Japan |
| Model | TM010/TM011 Cavity Resonator |
| Frequency Range | 1–10 GHz |
| Permittivity (ε′) | 1–30 |
| Accuracy | ±1% |
| Loss Tangent (tan δ) | 0.0001–0.05 |
| Accuracy | ±5% |
| Compliance | JIS C2565, ASTM D2520 |
| Sample Form | Rectangular bar (non-destructive) |
| Q-Factor | High (>10,000 typical) |
| Cavity Customization | Frequency-specific cavity modules available |
| Brand | AET |
|---|---|
| Origin | Japan |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Imported |
| Model | TE Cavity Resonator |
| Price Range | USD 42,000 – 140,000 |
| Frequency Range | 10–40 GHz |
| Permittivity (εᵣ) | 1–5 |
| Accuracy | ±1% |
| Loss Tangent (tan δ) | 0.0001–0.01 |
| Accuracy | ±5% |
| Sample Thickness | 0.01–0.3 mm |
| Minimum Sample Size | 50×50 mm (at 10 GHz), 40×40 mm (at 20 GHz), 30×30 mm (at 28/40 GHz) |
| Compliance | JIS R1641, IPC-TM-650 2.5.5.13 |
| Measurement Geometry | In-plane (parallel to film surface) |
| Cavity Type | Split-cylinder TE-mode resonant cavity |
| Brand | AET |
|---|---|
| Origin | Japan |
| Model | Liquid Resonant Cavity System |
| Frequency Range | 1–10 GHz |
| Permittivity Range | 1–6 |
| Permittivity Accuracy | ±1% |
| Loss Tangent Range | 0.001–0.01 |
| Loss Tangent Accuracy | ±5% |
| Minimum Sample Diameter | >5.5 mm |
| Brand | LUM |
|---|---|
| Origin | Germany |
| Model | LUMiFuge |
| Centrifugal Acceleration | up to 1200 × g |
| Sample Capacity | 8 positions |
| Temperature Control Range | 4–60 °C (in three programmable zones) |
| Sample Volume | 0.1–2 mL |
| Particle Size Range | 0.05–1000 µm |
| Concentration Range | 1–90 vol% |
| Viscosity Range | 0.8–10⁸ mPa·s |
| Density Range | 0.01–10 g/cm³ |
| Separation Velocity Resolution | 0.01–1000 µm/s |
| Compliance | ISO 13318-2 |
| Brand | HeatWave Labs |
|---|---|
| Origin | USA |
| Model | LaB6 |
| Operating Temperature | 950–1200 °C |
| Emission Current Density | ≥3–5 A/cm² (CW), >15 A/cm² (pulsed) |
| Cathode Material | Lanthanum Hexaboride (LaB6) |
| Insulation | Alumina (Al₂O₃) |
| Structural Body | Molybdenum (Mo) |
| Lifetime | >10,000 hours under optimal vacuum and thermal conditions |
| Electrical Isolation | Dual independent power leads fully isolated from housing |
| Gas-Free Operation | Yes |
| Optional Coatings | Os/Ru (M-type), Os/W, IR-emission-enhancing coatings |
| Scan Configurations Available | 311, 532, 411, 612, M (customizable per request) |
