| Brand | Yasuda |
|---|---|
| Origin | Japan |
| Model | No.145-D |
| Standard Compliance | JIS Z 0237 |
| Specimen Dimensions | 25 mm × 150 mm (or 12 ± 0.5 mm × 150 mm) |
| Test Plate | SUS304, 50 mm × 125 mm × ≥1.1 mm |
| Load Range | 200 gf to 1,000 gf (±5 g tolerance) |
| Fixture Type | Upper hook-type, Lower flat chuck (30 mm width) |
| Vertical Travel | Max. 45 mm, motorized auto-stop actuation |
| Temperature Capability | Up to 150 °C |
| Timer Functions | Preheating time setting, fall-time measurement, programmable test duration |
| Optional Accessories | Low-temperature chamber, constant temperature/humidity chamber, in-chamber lighting, 90° peel test kit |
| Power Supply & Dimensions | Configuration-dependent |
