StellarNet
Filter
Showing all 6 results
| Brand | StellarNet |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Import Status | Imported |
| Model | BLACK-Comet |
| Spectral Range | 280–900 nm |
| Detector Type | CCD |
| Optical Resolution (FWHM) | 0.75–6 nm |
| Sensitivity | 100 photons/count at 400 nm |
| Signal-to-Noise Ratio | 1000:1 (CCD) |
| Dynamic Range | 2000:1 (6 decades) |
| Stray Light | 0.02% at 435 nm |
| Brand | StellarNet |
|---|---|
| Origin | USA |
| Model | Blue-Wave |
| Spectral Range | 280–900 nm |
| Detector Type | CCD |
| Optical Resolution | 0.75–6 nm (FWHM) |
| Sensitivity | 100 photons/count at 400 nm |
| Signal-to-Noise Ratio | 1000:1 (full well) |
| Dynamic Range | 2000:1 (6 decades) |
| Stray Light | 0.02% at 435 nm |
| Brand | StellarNet |
|---|---|
| Origin | USA |
| Model | BlueWave |
| Spectral Range | 200–1100 nm |
| Detector Type | CCD (2048 pixels) |
| Optical Resolution | 0.13–6 nm (FWHM, configuration-dependent) |
| Sensitivity | 100 photons/count at 400 nm |
| Signal-to-Noise Ratio | 1000:1 (full well, single acquisition) |
| Dynamic Range | 2000:1 (with 6-decade linear response) |
| Stray Light | <1% |
| A/D Converter | 16-bit, high-speed |
| Interface | USB 2.0 (plug-and-play, Windows XP/Vista/7 compatible) |
| Dimensions | 25.4 × 76.2 × 127 mm (1 × 3 × 5 in) |
| Software | Included SpectraWiz™ (free), LabVIEW & Excel/VBA SDKs |
| Brand | StellarNet |
|---|---|
| Origin | USA |
| Model | SolarRad |
| Spectral Range | 220–1100 nm (SolarRad), 200–1700 nm (SolarRad-DSR) |
| NIST-Traceable Irradiance Calibration | 300–1100 nm (UV-extended option available) |
| Spectral Resolution | <1.5 nm (VIS), <3 nm (NIR for DSR) |
| Detector | 2048-pixel CCD (SolarRad), 2048-pixel CCD / 512-pixel InGaAs PDA (SolarRad-DSR) |
| Cosine Receiver | CR2 with optional right-angle adapter |
| Wavelength Accuracy | <0.25 nm |
| Irradiance Accuracy | ±5% |
| Interface | USB 2.0 |
| Software | SpectraWiz® Suite, LabVIEW drivers, SDK for C/VB/VBA |
| Brand | StellarNet |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Import Status | Imported |
| Model | Stellar-RAD |
| Price Range | USD $38,000–$64,000 (FOB USA) |
| Spectral Range | 350–1150 nm (UV-Vis-NIR) |
| Wavelength Accuracy | <0.25 nm |
| Spectral Resolution | <1 nm (FWHM) |
| Irradiance Accuracy | ±5% (NIST-traceable) |
| Illuminance Range | 0.05–400,000 lx |
| Radiant Flux Range | 0.25–1600 W/m² |
| Colorimetric Accuracy | ±0.001 Δx,Δy (vs. NIST SRM lamps) |
| CCT Accuracy | ±2% |
| Integration Time | 10 ms–60 s |
| Detector | Sony 2048-pixel CCD |
| Optical Design | Scientific-grade Crossed Czerny-Turner |
| Input Optics | Cosine-corrected diffuser (f/2.5) |
| Data Interface | USB 2.0 (bus-powered) |
| Software | SpectraWiz v24.x (Windows 10/11) |
| Compliance | NIST-traceable calibration certificate included |
| Optional Modules | UV (250–400 nm), NIR (900–1700 nm), radiance/luminance lens kits, integrating sphere compatibility (e.g., IS-200, IS-500) |
| Brand | StellarNet |
|---|---|
| Origin | USA |
| Model | StellarCASE-NIR |
| Optical Configuration | Reflectance & Transmission (Fiber-Coupled) |
| Spectral Range | 900–1700 nm |
| Spectral Resolution | ~3–5 nm (FWHM) |
| Detector | InGaAs Linear Array |
| Integration Time | 1 ms – 10 s |
| Interface | USB 2.0 |
| Power | Internal Rechargeable Li-ion Battery (8 h typical) |
| Dimensions | 185 × 120 × 65 mm |
| Weight | 1.2 kg |
| Calibration Support | Factory NIST-Traceable Wavelength & Radiometric Calibration |
| Software Compatibility | Windows 10/11, StellarNet SpectraWiz® Suite v8.5+ |
| Data Export | CSV, TXT, XML, ASTM E131-compliant format |
