| Brand | Aberlink |
|---|---|
| Origin | United Kingdom |
| Structure Type | Bridge |
| Operation Mode | Manual |
| Instrument Orientation | Vertical |
| Measurement Principle | Contact-Based Tactile Probing |
| Bearing System | Preloaded Self-Regulating Air Bearings |
| Drive System | Closed-Loop Servo Motor |
| Frame Material | High-Grade Aerospace Aluminium Alloy |
| Worktable Surface | Granite (Load Capacity: 1500 kg) |
| Probe Compatibility | Renishaw Multi-Series Touch Probes |
| Optional Software Module | CAD-Based Best-Fit Alignment & Deviation Analysis |
| Brand | Aberlink |
|---|---|
| Origin | United Kingdom |
| CMM Type | Bridge Configuration |
| Orientation | Vertical |
| Operation Mode | Fully Automatic |
| Measurement Principle | Contact-Based Tactile Probing |
| Structural Frame Material | Aerospace-Grade Aluminum Alloy |
| Load-Bearing Platform Capacity | Up to 6,000 kg |
| Base Interface | Direct-Foot Ground Coupling |
| Compliance | Designed for ISO 10360 and VDI/VDE 2617 Part 2 conformance |
| Brand | ABERLINK |
|---|---|
| Origin | United Kingdom |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Extol 370/520 |
| Pricing | Available Upon Request |
| Configuration | Hybrid (Contact + Optional Non-Contact Probes) |
| Operation Mode | Fully Automated |
| Machine Architecture | Vertical Cantilever |
| Measurement Principle | Contact-Based Tactile Metrology (ISO 10360-2 Compliant) |
| Brand | Aberlink |
|---|---|
| Origin | United Kingdom |
| CMM Type | Bridge Configuration |
| Operation Mode | Fully Automatic |
| Instrument Orientation | Vertical |
| Measurement Principle | Contact-Based Tactile Probing |
| Drive System | Frictionless Linear Motor Drive |
| Structural Design | Decoupled Motor Architecture (Motors Isolated from Granite Base) |
| Worktable | M6 Threaded Grid Mounting Surface |
| Integrated Control | Embedded Industrial PC and Motion Controller |
| Base Construction | Vibration-Damped Granite Base |
| Compliance Context | Designed for ISO 10360-compliant dimensional verification in production and QA environments |
| Brand | Aberlink |
|---|---|
| Origin | United Kingdom |
| Model | Fulcrum |
| Configuration | Cantilever-type |
| Operation Mode | Manual |
| Portability | Portable |
| Measurement Method | Contact-based (tactile probing) |
| Measurement Volume | 280 × 280 × 150 mm |
| Accuracy | (5.0 µm + L/1000 mm) |
| Standard Operating Temperature Range | 5 – 45 °C |
| Power Supply | Single-phase AC, no compressed air required |
| Primary Application | In-process rough inspection near machine tools |
| Brand | Aberlink |
|---|---|
| Origin | United Kingdom |
| Configuration | Bridge-Type |
| Operation Mode | Fully Automated |
| Instrument Orientation | Vertical |
| Measurement Principle | Contact-Based Tactile Probing |
| Structural Base | Granite Table with Honeycomb Aluminum Core |
| Bearing System | Self-Cleaning Preloaded Air Bearings on All Three Axes |
| Drive Mechanism | Zero-Backlash Frictionless Transmission |
| Control Architecture | Integrated Industrial PC and Motion Controller |
| Mounting Interface | Standard M6 Threaded Grid Across Table Surface |
| Compliance | Designed for ISO 10360-2 (CMM Performance Verification) and ISO 14253-1 (Geometrical Product Specifications) |
| Brand | Dantsin |
|---|---|
| Origin | Germany |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Scopecheck MB |
| Pricing | Upon Request |
| Configuration | Hybrid (Optical + Contact Probing Capable) |
| Operation Mode | Fully Automatic |
| CMM Class | Shop-Floor Hardened |
| Measurement Principle | Non-Contact Optical Imaging (Telecentric & Parallel Illumination) + Optional Tactile Probing |
| Measuring Volume Range | 500–2000 mm (X) × 600–3000 mm (Y) × 450–1500 mm (Z) |
| Volumetric Accuracy | ≤ 0.1 µm (at 20 ± 1 °C, thermal drift ≤ 0.5 K/h) |
| Maximum Scanning Speed | 250 mm/s |
| Base Material | Precision-Graded Granite |
| Guidance System | Air-bearing Linear Rails |
| Illumination System | Patented Parallel-Beam Telecentric Lighting with Removable Bottom Light Module |
| Environmental Compliance | ISO 10360-2, ISO 15530-3, VDI/VDE 2617 Part 9 |
