AEX A, B, C Compatible Chromatography Column

Overview

The AEX A, B, C Compatible Chromatography Column (Model CYABPA0031) is a pre-packed, ready-to-use anion exchange (AEX) column engineered for high-resolution separation of biomolecules—including monoclonal antibodies (mAbs), antibody fragments, plasmid DNA, and acidic proteins—in analytical and process-scale purification workflows. Designed for direct compatibility with common AEX resin chemistries—specifically those designated as “Type A”, “Type B”, and “Type C” per industry-standard classification of quaternary ammonium functionalization density and base matrix architecture—the column integrates a rigid polypropylene housing, low-dead-volume end fittings, and a precisely packed bed of macroporous, high-capacity anion exchange media. Its hydraulic design ensures laminar flow profiles and minimal band broadening, supporting reproducible retention times and peak symmetry under both isocratic and gradient elution conditions. The column is validated for use in GMP-aligned environments where column-to-column consistency, lot traceability, and documented performance qualification are essential.

Key Features

• Direct compatibility with widely adopted AEX resin classifications (Type A, Type B, Type C), enabling seamless method transfer across labs and platforms
• Pre-packed with rigorously characterized anion exchange media; each batch undergoes pressure-flow testing, dynamic binding capacity (DBC) verification at 10% breakthrough, and UV transparency screening
• Chemically resistant polypropylene housing rated for operating pressures up to 5 bar (72.5 psi), compatible with standard HPLC, FPLC, and AKTA systems
• End-fittings with 10-32 UNF threads and integrated PEEK frits (5 µm pore size) ensure particulate retention and minimize backpressure spikes
• Manufactured and quality-controlled in Shanghai under ISO 9001-certified processes; full Certificate of Analysis (CoA) provided with each shipment
• Available in standard dimensions (e.g., 10 × 50 mm, 16 × 100 mm, 25 × 150 mm) with custom sizing supported upon request

Sample Compatibility & Compliance

The CYABPA0031 column demonstrates robust performance across diverse sample matrices, including clarified mammalian cell culture harvests, bacterial lysates, and purified protein pools. It tolerates common formulation excipients (e.g., sodium chloride, sucrose, histidine, arginine) and maintains integrity in buffers ranging from pH 5.0 to 9.5. All wetted components comply with USP Class VI biocompatibility standards. The column is suitable for applications governed by ICH Q5, Q6, and Q8 guidelines, and supports data integrity requirements aligned with FDA 21 CFR Part 11 when used in conjunction with compliant chromatography data systems (CDS). Batch records include resin lot number, packing date, DBC values, and pressure drop specifications—enabling full audit trail for GLP and GMP documentation.

Software & Data Management

While the column itself is hardware-only, its performance metrics integrate natively into standard chromatography software platforms—including Cytiva UNICORN, Waters Empower, and Thermo Chromeleon—via user-defined method parameters. Deepflow provides optional digital documentation packages, including electronic CoAs with QR-code-linked metadata, and CSV-formatted validation reports compatible with LIMS and ELN systems. All columns ship with serialized labels supporting barcode-based inventory tracking and automated logbook entry.

Applications

• Polishing step in mAb downstream processing, targeting host cell protein (HCP) and DNA clearance
• Separation of charge variants (e.g., deamidated, oxidized, C-terminal lysine variants) during stability-indicating assays
• Purification of CRISPR-associated ribonucleoproteins (RNPs) and mRNA–protein complexes
• Analytical characterization of viral vector capsid charge heterogeneity (e.g., AAV serotypes)
• Method development and scale-down modeling for commercial anion exchange chromatography processes

FAQ

What does “A, B, C compatible” mean in practice?
It indicates that the column’s packed resin matches the functional group density, ligand spacing, and base matrix porosity defined in the industry’s informal but widely referenced A/B/C taxonomy—ensuring equivalent selectivity and capacity behavior to leading commercial AEX resins classified under those types.
Is this column suitable for regulatory filing submissions?
Yes—when used with full traceability documentation (CoA, resin CoA, packing report), it meets expectations for column qualification in IND/BLA-enabling studies per ICH and FDA guidance.
Can it be sanitized with NaOH?
The column housing and frits are stable under 0.1–0.5 M NaOH for up to 60 minutes at ambient temperature; extended exposure or elevated temperatures require prior validation.
What is the recommended maximum linear velocity?
For optimal resolution and capacity utilization, operate between 50–150 cm/hr depending on resin particle size and target molecule size; application notes provide detailed velocity–resolution trade-off curves.
Does Deepflow offer column re-packing or refurbishment services?
No—CYABPA0031 is supplied as a single-use, pre-packed column; re-use beyond manufacturer-specified cycles is not supported for GMP applications.
