CZGY HJ-2A Dual-Station Digital Temperature-Controlled Magnetic Stirrer

Overview

The CZGY HJ-2A Dual-Station Digital Temperature-Controlled Magnetic Stirrer is an engineered solution for parallel sample processing in analytical, quality control, and preparative laboratory workflows. Based on the principle of rotating magnetic coupling—where a microcontroller-synchronized rotating permanent magnet beneath the heated ceramic plate induces torque on PTFE-coated stir bars immersed in liquid samples—the instrument delivers precise, reproducible agitation and thermal regulation across two independent workstations. Unlike single-station units, the dual-channel architecture enables simultaneous comparison experiments, standard curve preparation, or replicate reaction monitoring under identical thermal and mechanical conditions. Its design adheres to fundamental safety and operational standards expected in ISO/IEC 17025-accredited laboratories, including electrical insulation compliance (IEC 61010-1), thermal cut-off protection, and grounding requirements for Class I equipment.

Key Features

• Dual independent control channels: Each station features separate digital PID temperature regulation and stepless speed adjustment (0–2000 rpm), eliminating cross-interference between samples.
• High-stability ceramic heating plates (Ø120 mm × 2): Chemically inert surface resists corrosion from acids, bases, and organic solvents; uniform thermal distribution verified per ASTM E2234.
• Low-noise brushless DC motors (25 W per channel): Engineered for extended duty cycles—rated for 8 hours continuous operation at ≤1200 rpm, 4 hours at full 2000 rpm—with integrated thermal overload protection.
• Digital LED display with real-time feedback: Simultaneously shows setpoint and actual values for both temperature and speed; resolution: 1 °C / 1 rpm.
• Safety-focused construction: Grounding terminal included as standard; automatic thermal shutdown at >110 °C; non-slip rubber feet and splash-resistant front panel meet GLP handling guidelines.

Sample Compatibility & Compliance

The HJ-2A accommodates standard laboratory glassware up to 1000 mL capacity per station—including beakers, Erlenmeyer flasks, and digestion vessels—when used with appropriately sized magnetic stir bars (recommended: 30–40 mm length, PTFE or PTFE/glass coated). It supports aqueous, polar organic, and mildly aggressive media (e.g., diluted HCl, NaOH, ethanol/water mixtures) but is not rated for halogenated solvents or strong oxidizers. The instrument complies with electromagnetic compatibility (EMC) requirements per CISPR 11 Group 1, Class B, and satisfies basic electrical safety per IEC 61010-1:2010 for laboratory use. While not FDA 21 CFR Part 11–certified out-of-the-box, its manual operation mode and immutable parameter logging (via external data logger) support audit-ready documentation in GMP/GLP environments when integrated into validated SOPs.

Software & Data Management

The HJ-2A operates as a standalone analog-digital hybrid instrument without embedded software or network connectivity. All parameter inputs and status indicators are managed locally via push-button interface and dual 4-digit LED displays. For traceable recordkeeping, users may integrate the unit with third-party data acquisition systems using optional 0–5 V analog output modules (sold separately) that mirror speed and temperature signals. This configuration enables time-stamped logging in compliant platforms such as LabArchives or electronic lab notebooks (ELNs) aligned with ALCOA+ principles (Attributable, Legible, Contemporaneous, Original, Accurate, Complete, Consistent, Enduring, Available).

Applications

• Preparation of calibration standards and buffer solutions requiring uniform mixing and thermal equilibration prior to pH or conductivity measurement.
• Accelerated dissolution testing of pharmaceutical excipients under controlled temperature gradients (e.g., USP method adaptation).
• Multi-sample digestion protocols in environmental analysis (e.g., EPA Method 3015A for acid leaching of soil extracts).
• Controlled polymerization initiation where monomer homogeneity and reaction temperature stability directly impact molecular weight distribution.
• Cell culture reagent warming and suspension maintenance during passaging procedures in biosafety cabinets.

FAQ

What is the maximum recommended vessel size per station?
Standard use supports containers up to 1000 mL volume when placed centrally on the 120 mm diameter plate; optimal stirring efficiency is achieved with vessels having flat, non-tapered bases.
Can the HJ-2A be used with corrosive reagents like concentrated nitric acid?
No. The ceramic plate surface is resistant to mild acids and bases, but prolonged exposure to concentrated oxidizing agents may degrade the coating and compromise thermal uniformity.
Is speed synchronization between the two stations possible?
No. Each station operates independently; no hardware or firmware provision exists for inter-channel speed locking or master-slave control.
Does the unit include a built-in data export interface?
No. Data recording requires external analog-to-digital conversion or manual transcription from the LED displays.
What maintenance is required to ensure long-term accuracy?
Monthly visual inspection of plate surface integrity, annual verification of temperature sensor drift using a calibrated NIST-traceable thermometer, and periodic cleaning of ventilation grilles to prevent motor overheating.
