DRETOP TDK-8AD Electrically Heated Constant-Temperature Water Bath

Overview

The DRETOP TDK-8AD Electrically Heated Constant-Temperature Water Bath is a precision-engineered laboratory thermal platform designed for stable, uniform, and repeatable heating of samples in aqueous media. Operating on resistive immersion heating with direct contact between the sealed heating element and bath fluid, the unit maintains setpoint temperatures within ±0.5°C across its full operational range (RT+5°C to 100°C), making it suitable for applications requiring reliable thermal conditioning without active fluid circulation. Unlike recirculating baths, the TDK-8AD relies on natural convection and optimized internal geometry—including laser-cut, densely perforated 304 stainless steel inner lining—to promote homogeneous heat distribution throughout the 30 L working volume. Its non-circulating architecture eliminates pump-related maintenance, noise, and potential contamination pathways, aligning with GLP-compliant workflows where passive thermal stability and mechanical simplicity are prioritized.

Key Features

• Microprocessor-based PID temperature controller with LED digital display, offering 0.1°C resolution and programmable timer (1–9999 minutes)
• High-accuracy platinum resistance temperature sensor (PT100-class equivalent) integrated into the heating zone for real-time feedback and minimal thermal lag
• 304 stainless steel inner tank and lid, electrostatically coated outer housing, and multi-layer insulation for corrosion resistance, thermal efficiency, and long-term durability
• One-touch drain valve and built-in water-level sensor enabling automatic dry-run protection and audible/visual over-temperature alarm
• Power-efficient 2000 W heating system with low thermal inertia design—optimized for rapid warm-up and minimal overshoot during setpoint transitions
• Memory retention function preserving user-defined parameters after power interruption; automatic recovery upon re-energization

Sample Compatibility & Compliance

The TDK-8AD accommodates standard laboratory glassware including beakers, flasks, test tubes, and jacketed reactors up to Ø150 mm diameter and 200 mm height. Its open-bath configuration supports immersion of external probes, sensors, or reaction vessels requiring external thermal coupling. The unit complies with IEC 61010-1:2010 safety standards for electrical equipment used in laboratory environments. While not intrinsically rated for hazardous locations, its construction meets general-purpose requirements for ISO/IEC 17025-accredited testing laboratories performing routine thermal conditioning per ASTM E2251 (Standard Practice for Calibration of Liquid-in-Glass Thermometers) and USP (Thermal Analysis). Optional RS485 interface enables integration into centralized lab monitoring systems supporting audit trails compliant with FDA 21 CFR Part 11 when paired with validated software.

Software & Data Management

The TDK-8AD operates as a standalone analog-digital hybrid instrument with no embedded operating system or network stack. All control logic resides in the microcontroller firmware, ensuring deterministic response and immunity to software crashes. Data logging requires external recording via the optional RS485 port using third-party SCADA or LabVIEW-compatible drivers (provided separately). Time-stamped temperature readings can be captured at user-defined intervals (e.g., every 10 seconds) and exported to CSV for traceability in QA/QC documentation. For regulated environments, the device supports manual calibration verification per SOPs aligned with ISO/IEC 17025 Clause 6.5.2, with certificate-of-conformance documentation available upon request.

Applications

• Controlled-temperature incubation of biological reagents, enzyme solutions, and cell culture media
• Pre-heating and thermal equilibration prior to viscometry, calorimetry, or spectrophotometric assays
• Supporting distillation, solvent evaporation, and concentration steps in organic synthesis and analytical sample preparation
• Calibration of liquid-in-glass thermometers and digital temperature probes against NIST-traceable references
• Thermal conditioning of polymer solutions, adhesives, and coatings prior to rheological or mechanical testing
• Warming of histological specimens and diagnostic reagents in clinical pathology labs under CLIA-equivalent protocols

FAQ

Is the TDK-8AD compatible with oil-based heat transfer media?
Yes—the 304 stainless steel tank and sealed heater are chemically resistant to mineral oils, silicone oils, and glycerol-water mixtures up to 100°C. However, viscosity-dependent convection may reduce temperature uniformity compared to water; validation per application is recommended.
Does this model support external temperature probe input for chamber monitoring?
No—the TDK-8AD uses only its integrated sensor for control. External probe inputs require upgrade to the TDK-8AX or TDK-F8AX variants with dual-sensor capability.
What maintenance is required to ensure long-term accuracy?
Monthly descaling with 5% citric acid solution is advised when using tap water; distilled or deionized water is strongly recommended to prevent scale buildup on the heater surface and sensor junction.
Can the unit be operated continuously for 72+ hours?
Yes—designed for unattended operation with thermal cutoffs, dry-run protection, and reinforced insulation. Continuous duty cycle is validated per IEC 60068-2-2 (dry heat testing) protocols.
Is CE marking applicable for export to the European Union?
The TDK-8AD carries CE marking under the Low Voltage Directive (2014/35/EU) and EMC Directive (2014/30/EU), with technical documentation available for customs clearance and conformity assessment.
