Fourtec MicroLite USB Temperature Data Logger

Overview

The Fourtec MicroLite USB Temperature Data Logger is a compact, self-contained, battery-powered measurement device engineered for high-fidelity, long-term temperature monitoring in unattended environments. Based on precision thermistor sensing and 16-bit analog-to-digital conversion, the MicroLite operates on the principle of direct thermal resistance measurement, calibrated traceably to NIST-traceable standards. Its fully integrated architecture eliminates external power requirements or wired connectivity during deployment—making it ideal for validation-critical applications where physical access is limited or intermittent. Unlike networked loggers requiring infrastructure, the MicroLite functions as a standalone acquisition node: it autonomously samples, timestamps, and stores temperature readings internally, then delivers raw time-series data via plug-and-play USB 2.0 interface upon retrieval. Designed for field robustness without compromising metrological integrity, it meets stringent environmental demands across logistics, cold chain verification, and regulated storage.

Key Features

• Compact form factor (75 × 25 × 15 mm) enabling placement in confined spaces—including inside shipping containers, pharmaceutical packaging, incubators, and portable coolers
• IP68-rated enclosure certified for continuous submersion in water up to 1.5 m for 30 minutes; dust-tight construction compliant with IEC 60529
• High-resolution 16-bit ADC delivering 0.1 °C display and logging resolution across full -40 to +80 °C operating range
• Calibrated accuracy of ±0.3 °C (at 25 °C), validated per ISO/IEC 17025-accredited procedures; factory calibration certificate available upon request
• Configurable sampling rate from 1 second to 2 hours, supporting both transient event capture and multi-month trend analysis
• Integrated LCD with real-time temperature readout, user-defined alarm thresholds, and automatic min/max tracking
• Replaceable CR2032 coin-cell battery—industrially standardized, globally sourced, and field-serviceable without tools
• On-device start/stop control via tactile button; no host software required for activation or configuration

Sample Compatibility & Compliance

The MicroLite is designed for direct ambient air temperature monitoring and surface contact measurements (via optional adhesive mount or thermal tape). It does not support probe extension or fluid immersion beyond its IP68 rating. The device complies with RoHS 2011/65/EU and REACH (EC) No. 1907/2006. Its data integrity framework supports audit-ready workflows: MicroLab Lite software generates timestamped, non-editable CSV and PDF reports with embedded metadata (device ID, calibration date, sampling parameters). While not inherently 21 CFR Part 11 compliant, the system can be deployed within GxP environments when paired with documented SOPs for user access control, electronic signature validation, and change history review—commonly implemented in pharmaceutical warehouse qualification (per WHO TRS 961 Annex 9) and FDA-regulated cold chain transport (per USP ).

Software & Data Management

MicroLab Lite—a free, Windows-based desktop application—provides complete lifecycle management: device configuration, data retrieval, graphical time-series analysis, statistical summary (mean, std dev, excursions), and export to CSV, Excel, or PDF. The software embeds an internal real-time clock synchronization routine, ensuring temporal coherence across multiple loggers. All downloaded datasets retain native UTC timestamps with millisecond precision. Audit trail functionality records operator actions (e.g., “download initiated”, “alarm threshold modified”) with user ID and timestamp—supporting GLP-aligned documentation practices. Data files are stored in open-format binary archives, enabling third-party integration via documented API hooks for enterprise LIMS or MES platforms.

Applications

• Pharmaceutical cold chain validation: Monitoring temperature excursions during clinical trial kit distribution, vaccine transport, and GDP-compliant warehouse mapping
• FDA-regulated food logistics: Continuous recording for USDA/FDA HACCP plans, including refrigerated truck audits and frozen seafood transit
• Electronics manufacturing: Environmental stability verification in cleanroom staging areas, ESD-safe storage cabinets, and component shelf-life testing
• Academic and industrial research: Unobtrusive long-duration environmental profiling in greenhouses, field-deployed sensor networks, and equipment thermal aging studies
• Regulatory compliance: Supporting ISO 13485 medical device storage audits, ISO 22000 food safety management, and EN 12830-2018 refrigerated transport certification

FAQ

Is the MicroLite suitable for use inside reefer containers during ocean freight?
Yes—its IP68 rating, extended battery life (2+ years at 1-min intervals), and wide -40 to +80 °C range make it appropriate for maritime cold chain deployments, provided the unit remains within its specified humidity limits (0–100% RH non-condensing).
Can MicroLab Lite generate 21 CFR Part 11-compliant reports?
MicroLab Lite itself does not provide electronic signatures or audit trail encryption. However, it produces immutable, timestamped data exports that serve as foundational evidence in Part 11-compliant systems when governed by organizational procedural controls.
Does the device require recalibration before each use?
No—factory calibration is stable over the device’s operational lifetime under normal conditions. Fourtec recommends periodic verification (e.g., annually or per SOP) using a NIST-traceable dry-block calibrator or reference bath.
How is time synchronization handled across multiple MicroLite units?
Each unit maintains its own high-stability RTC. Synchronization occurs only during USB download via MicroLab Lite, which aligns timestamps to the host PC clock—ensuring inter-device temporal consistency within ±100 ms.
Is the CR2032 battery replacement process documented?
Yes—the user manual includes step-by-step instructions with torque specifications for the stainless-steel housing screws and ESD-safe handling guidelines for battery compartment access.
