HengaoDe HAD-150 Multi-Function Hammer Mill with Cyclonic Separation for Flour and Grain Sample Preparation

Overview

The HengaoDe HAD-150 Multi-Function Hammer Mill with Cyclonic Separation is an engineered solution for standardized, high-reproducibility sample comminution in cereal science, flour quality laboratories, and agricultural research. It operates on the principle of high-speed impact grinding: a rotor-mounted set of hardened steel hammers rotates at 16,800 rpm within a cylindrical grinding chamber, subjecting feedstock to repeated mechanical impact and shear forces. Particles are simultaneously classified by centrifugal force and air-assisted cyclonic separation—ensuring immediate ejection of ground material through a peripheral sieve while retaining oversized particles for further reduction. This closed-loop, airflow-driven separation eliminates manual sieving and cross-contamination between samples, aligning with ISO 7301, AACC Method 26-10A, and ICC Standard No. 168 for flour preparation prior to falling number, gluten index, and near-infrared (NIR) spectroscopic analysis.

Key Features

• Automated variable-speed feeding system with pneumatic flow control—adjustable based on grain moisture content, hull presence, or bulk density to prevent choke and ensure consistent throughput.
• Cyclonic discharge port enables direct collection into sample containers while self-cleaning the grinding chamber; no disassembly required between sequential runs.
• Integrated acoustic damping enclosure lined with high-density sound-absorbing composite material—measured noise output ≤75 dB(A) under full-load operation, compliant with ISO 4871 and EU Directive 2006/42/EC occupational exposure limits.
• Interlocked safety door switch halts motor operation instantly upon lid opening, satisfying EN 60204-1 machinery safety requirements.
• Three interchangeable stainless-steel sieve plates (0.5 mm, 0.8 mm, 1.5 mm aperture) allow precise control over particle size distribution for method-specific applications—from fine flour for NIR calibration to coarser fractions for enzymatic activity assays.
• Low residual mass (<2.0 g at ≤14% moisture) ensures representative subsampling and minimizes carryover error in trace analyte quantification.

Sample Compatibility & Compliance

The HAD-150 accepts dry or semi-dry granular materials including wheat, barley, rye, maize, soybeans, rapeseed, feed pellets, and botanical herbs. It is not suitable for fibrous, oily, or highly viscous matrices without pre-conditioning. All wetted components comply with FDA 21 CFR §177.2600 for food-contact polymers. The instrument meets CE marking requirements for electromagnetic compatibility (EN 61326-1) and low-voltage directive (2014/35/EU). Its grinding performance is validated against AACC International Approved Methods 26-10A (flour particle size), 22-10 (falling number sample prep), and 38-12 (gluten index preparation), supporting GLP-compliant documentation workflows.

Software & Data Management

As a standalone benchtop mechanical instrument, the HAD-150 does not incorporate embedded firmware or digital connectivity. However, its operational parameters—including feed rate, grinding duration, and sieve selection—are fully documented in user-defined SOPs. Laboratory Information Management Systems (LIMS) may log usage metadata via manual entry or barcode-scanned batch IDs. For audit readiness, all maintenance logs (e.g., hammer wear inspection, sieve replacement dates) must be retained per ISO/IEC 17025:2017 clause 7.6. Calibration certificates for optional external torque meters or particle size analyzers used in conjunction with the mill are traceable to NIM (National Institute of Metrology, China) standards.

Applications

• Preparation of homogenized flour samples for falling number testing (ISO 3093), wet gluten determination (ICC 155), and gluten index (AACC 38-12).
• Routine milling of cereal breeding lines for NIR spectral library development and quantitative trait locus (QTL) mapping studies.
• Grinding of feed ingredients for proximate analysis (crude protein, fiber, ash) per AOAC 984.13 and 967.12.
• Standardized comminution of botanicals and herbal powders for pharmacopoeial assays (USP , EP 2.8.24).
• QC sampling in flour mills where batch-to-batch consistency directly impacts baking performance and shelf-life stability.

FAQ

What is the recommended maintenance interval for hammer replacement?

Hammer life depends on abrasive load and moisture content; inspect after every 500 operating hours or when particle size distribution deviates >5% from baseline—documented in maintenance log per ISO/IEC 17025.

Can the HAD-150 process samples with >14% moisture?

No. Feedstock must be conditioned to ≤14% moisture prior to milling to avoid clogging, thermal degradation, and non-representative particle size distribution.

Is the cyclonic separator compatible with hazardous dust classification zones?

The unit is not ATEX-certified. For use in Zone 21 or 22 environments, integrate external explosion venting and grounding per IEC 60079-10-2 and NFPA 652.

Does the instrument support IQ/OQ documentation packages?

Yes—HengaoDe provides Factory Acceptance Test (FAT) reports and can supply URS-aligned Installation Qualification (IQ) templates upon request. Operational Qualification (OQ) must be performed in situ using certified reference materials.

What is the warranty coverage and service response time?

Standard 12-month parts-and-labor warranty. Technical support response time: ≤2 business days; on-site service available in major Chinese industrial hubs within 5 business days.
