HUANKONG GHK100 Portable Ozone Analyzer

Overview

The HUANKONG GHK100 Portable Ozone Analyzer is a field-deployable, UV absorption-based gas measurement instrument engineered for high-fidelity, real-time quantification of ambient ozone (O₃) concentrations. It operates on the principle of ultraviolet photometry at 254 nm — a well-established, reference-grade methodology standardized in HJ 590–2010 and traceable to NIST-traceable calibration protocols. Unlike electrochemical or metal-oxide semiconductor sensors, the GHK100 employs a temperature-stabilized, low-power UV light source and precision optical path design to ensure minimal drift and high spectral specificity for ozone. Its compact architecture integrates an optimized absorption cell with a dual-beam optical configuration to compensate for lamp aging and particulate scattering effects, enabling stable baseline performance over extended unattended operation. Designed for regulatory-grade field use, the analyzer meets the metrological requirements defined in JJG 1077–2012 for ozone gas analyzers and supports compliance with indoor air quality assessment per GB/T 18883–2022 and ambient air monitoring under HJ 654–2013.

Key Features

• UV photometric detection at 254 nm with <1 ppb limit of detection and ±2% full-scale accuracy across 0–500 ppb range
• Fast T90 response time ≤20 seconds — suitable for dynamic plume tracking and mobile monitoring applications
• Integrated BeiDou/GPS dual-mode positioning module for georeferenced data logging and spatial mapping
• 5-inch industrial-grade capacitive touchscreen with intuitive UI, offline operation capability, and real-time trend visualization
• Rugged aluminum-magnesium alloy enclosure with foldable ergonomic handle — IP54-rated for dust and splash resistance
• Low-power UV optical module with >20,000-hour lamp lifetime and zero warm-up requirement
• Onboard 8 GB non-volatile storage supporting timestamped, GPS-tagged measurement logs (≥12 months at 1-min intervals)
• Multi-modal connectivity: embedded 4G LTE modem, IEEE 802.11 b/g/n Wi-Fi, and Bluetooth 5.0 for local printing and configuration

Sample Compatibility & Compliance

The GHK100 is validated for direct analysis of ambient air, indoor air, and workplace breathing-zone samples without dilution or pre-concentration. Its inlet system includes a user-replaceable hydrophobic particulate filter (recomm. replacement every 6 months) and a disposable PTFE membrane filter (recomm. replacement every 3–5 days in high-dust environments), ensuring optical path integrity and minimizing maintenance downtime. The analyzer conforms to Chinese national standards GB/T 18883–2022 (indoor air), HJ 590–2010 (UV photometric method), JJG 1077–2012 (verification procedures), and HJ 654–2013 (performance specifications for continuous ambient air monitoring systems). While not certified to ISO 13137 or EN 14625, its measurement principle and calibration traceability align with internationally accepted UV absorption best practices used in EPA TO-11A and EU Directive 2008/50/EC reference methods.

Software & Data Management

The GHK100 supports seamless integration with cloud-based environmental data platforms via secure HTTPS/MQTT protocols. Firmware enables configurable upload intervals, automatic firmware OTA updates, and encrypted data transmission compliant with TLS 1.2. Local data handling includes CSV export via USB mass storage mode, Bluetooth thermal printing of real-time reports, and password-protected access control. Audit trails record all configuration changes, calibration events, and filter replacement timestamps — supporting GLP-aligned documentation workflows. Data schema includes UTC timestamp, latitude/longitude (WGS84), altitude, temperature, pressure, relative humidity (via optional external sensor input), and raw absorbance values — facilitating traceable QA/QC review and third-party validation.

Applications

• Emergency response monitoring during ozone episodes or industrial release incidents
• Mobile air quality surveys from vehicles, bicycles, or handheld patrols
• Roadside and urban canyon monitoring for traffic-related ozone formation studies
• Occupational exposure assessment in water treatment facilities, disinfection chambers, and semiconductor cleanrooms
• Indoor air quality verification in schools, hospitals, and office buildings per GB/T 18883–2022
• Calibration transfer and QA/QC support for fixed-site ozone monitoring networks

FAQ

What is the calibration interval recommendation for the GHK100?
Annual calibration against a NIST-traceable ozone generator or certified standard gas cylinder is recommended; field zero/span checks should be performed before each deployment.
Can the GHK100 operate continuously on battery power?
Yes — the integrated lithium battery supports ≥10 hours of continuous measurement at 1-minute sampling intervals, extendable to 24+ hours in low-power logging mode.
Is the instrument suitable for outdoor use in extreme temperatures?
The operating temperature range is –10 °C to +50 °C; prolonged exposure above 45 °C may affect UV lamp stability and is not advised without active thermal shielding.
Does the GHK100 support remote firmware updates?
Yes — over-the-air (OTA) updates are delivered via secure HTTPS channel and require administrator authentication.
How is data integrity ensured during network outages?
All measurements are stored locally on the 8 GB flash memory with write-cycling protection; data sync resumes automatically upon reconnection without loss.
