IKA T10 Basic ULTRA-TURRAX® Dispersing Emulsifying Machine
| Brand | IKA |
|---|---|
| Origin | Germany |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | T 10 BASIC S025 |
| Pricing | Upon Request |
Overview
The IKA T10 Basic ULTRA-TURRAX® is a compact, high-speed dispersing and emulsifying machine engineered for precision sample homogenization in research laboratories, quality control environments, and small-scale R&D workflows. Operating on the principle of high-shear rotor-stator fluid dynamics, it generates intense mechanical energy through controlled rotational motion—enabling efficient particle size reduction, cell lysis, emulsion formation, and suspension stabilization. Designed for volumes ranging from 0.5 mL to 100 mL, this instrument delivers reproducible results across viscous, heterogeneous, or temperature-sensitive samples without requiring external cooling or vacuum integration. Its core architecture reflects IKA’s long-standing expertise in laboratory mixing technology, emphasizing mechanical robustness, ergonomic accessibility, and compliance-ready operational transparency.
Key Features
- Wide speed range: 8,000–30,000 rpm with electronic speed control for consistent shear input across varying viscosities and sample volumes
- Quick-release coupling system allows tool-free exchange of dispersing elements—minimizing cross-contamination and downtime between experiments
- Integrated universal power supply (100–240 V AC, 50/60 Hz) eliminates need for external adapters; supports direct wall outlet connection globally
- Low-noise motor design (<65 dB(A) at 20,000 rpm) ensures compatibility with shared lab spaces and noise-sensitive environments
- Ergonomic handheld housing with non-slip grip and balanced weight distribution (approx. 0.9 kg) facilitates extended manual operation without operator fatigue
- Stainless-steel dispersing tools (e.g., S025, S030, S040) are autoclavable and chemically resistant to common solvents, acids, and bases per ISO 8502-3 guidelines
- Optional disposable dispersing elements (2 mL and 7 mL formats) certified DNase/RNase-free and PCR-grade—validated for molecular biology applications including nucleic acid extraction and library preparation
Sample Compatibility & Compliance
The T10 Basic accommodates a broad spectrum of sample types—including aqueous suspensions, organic emulsions, polymer dispersions, biological tissues, and nanoparticle colloids—without requiring pre-dilution or viscosity adjustment. Its rotor-stator geometry enables effective processing of materials with dynamic viscosities up to 5,000 mPa·s (measured at 20°C). All stainless-steel components comply with EN 10204 3.1 material certification standards. When used with validated disposable tools and documented operating procedures, the system supports GLP-compliant workflows and can be integrated into FDA 21 CFR Part 11–aligned data integrity frameworks when paired with compliant third-party logging software.
Software & Data Management
The T10 Basic operates as a stand-alone analog-controlled device without embedded digital interfaces or firmware. Speed selection is performed via a calibrated rotary dial with tactile feedback and visual LED indication. While it does not feature onboard memory or USB connectivity, its consistent speed stability (±1% deviation over 5-minute continuous operation at rated load) permits reliable correlation with external timing and analytical instrumentation (e.g., particle size analyzers, spectrophotometers). For audit-trail requirements, users may record operational parameters—including speed, duration, tool type, and batch ID—in laboratory notebooks or LIMS-integrated electronic logbooks per ISO/IEC 17025 documentation practices.
Applications
- Routine homogenization of tissue samples for protein extraction and Western blot analysis
- Preparation of stable oil-in-water and water-in-oil emulsions in cosmetic and pharmaceutical formulation development
- Dispersion of carbon nanotubes, graphene oxide, and metal oxide nanoparticles in polymer matrices
- Cell disruption for microbial lysate preparation in microbiology and synthetic biology labs
- Viscosity-dependent pigment dispersion in ink and coating R&D
- PCR-ready sample prep using certified disposable probes—ensuring trace-level contamination control in genetic testing environments
FAQ
Is the dispersing tool included in the standard delivery?
No—the dispersing tool (e.g., S025) is sold separately and must be selected based on application requirements. The standard delivery includes only the T10 Basic main unit and R200 clamp.
Can the T10 Basic be mounted on a laboratory stand?
Yes—it is compatible with standard IKA R200 or equivalent vertical clamps and can be secured to retort stands for hands-free operation during extended processing cycles.
What maintenance is required for long-term reliability?
Routine cleaning of the motor shaft and coupling interface with isopropanol is recommended after each use; periodic inspection of rotor concentricity and stator wear is advised every 500 operating hours.
Does the device support regulatory validation protocols?
While the instrument itself lacks digital audit trails, its mechanical consistency, CE marking (2014/30/EU EMC Directive), and conformity to IEC 61000-6-3 emission limits enable inclusion in IQ/OQ/PQ qualification packages under user-defined SOPs.
Are replacement parts available globally?
Yes—IKA maintains an international spare parts network; rotor-stator sets, drive shafts, and housing gaskets are stocked and distributed through authorized channels in EMEA, APAC, and the Americas.
