JB119 30 kN Dual-Column Electronic Universal Testing Machine
| Brand | Jiubin Instruments |
|---|---|
| Origin | Taiwan, China |
| Manufacturer Type | Authorized Distributor |
| Country of Manufacture | China |
| Model | JB119 |
| Instrument Type | Electromechanical Universal Testing Machine |
| Load Capacity | 30 kN |
| Pricing | USD 11,200 (FOB Taiwan) |
Overview
The JB119 30 kN Dual-Column Electronic Universal Testing Machine is an electromechanical static testing system engineered for high-precision tensile, compression, flexural, peel, shear, and cyclic mechanical property evaluation of metallic, polymeric, composite, ceramic, and elastomeric materials. Built upon a rigid dual-column steel frame with preloaded ball screws and precision-ground linear guides, the system delivers stable axial alignment and minimal deflection under load—critical for ASTM E4, ISO 7500-1 Class 1, and GB/T 16491 compliance. Its servo-controlled AC motor drive enables smooth, programmable crosshead speeds from 0.001 to 500 mm/min, supporting both displacement- and load-controlled test modes. The machine operates within ambient temperature ranges (10–35 °C) and relative humidity ≤80% (non-condensing), making it suitable for standard QC laboratories, university research facilities, and R&D centers requiring repeatable mechanical characterization per ISO 527, ASTM D638, ASTM D790, and ISO 178 protocols.
Key Features
- Rigid dual-column structural architecture with integrated load frame damping and anti-vibration base mounting capability
- High-resolution 24-bit analog-to-digital conversion for load cell signal acquisition (standard 30 kN ±0.5% full-scale accuracy, optional 5/10/50 kN interchangeable transducers)
- Real-time closed-loop control via embedded microprocessor with PID tuning for precise force and displacement regulation
- Modular extensometer interface supporting clip-on, video, and non-contact digital image correlation (DIC) inputs (compatible with ISO 9513-compliant devices)
- Integrated safety interlocks including emergency stop, upper/lower limit switches, overload protection, and software-based load threshold limits
- Compliance with electromagnetic compatibility standards EN 61326-1 and electrical safety standard EN 61010-1
Sample Compatibility & Compliance
The JB119 accommodates specimens up to 1,000 mm in height and 400 mm in width, with adjustable crosshead travel (up to 1,200 mm standard). Grip options include pneumatic wedge-action, hydraulic self-tightening, screw-type, and custom fixtures for films, fibers, adhesives, biomedical stents, and automotive gaskets. All mechanical tests align with international regulatory frameworks: data traceability supports GLP/GMP audit requirements; electronic signatures and audit trails comply with FDA 21 CFR Part 11 when paired with validated software modules; and calibration documentation adheres to ISO/IEC 17025-accredited practices. Third-party verification reports are available upon request for ISO 17025-certified calibration labs.
Software & Data Management
The system ships with PC-based testing software compliant with Windows 10/11 (64-bit), featuring intuitive test method templates (ASTM, ISO, GB), real-time stress–strain curve overlay, multi-curve comparison, and automated report generation in PDF, Excel, and XML formats. Raw data export includes time-stamped load, displacement, strain, and environmental metadata. Software architecture supports role-based user permissions, electronic signature workflows, and encrypted local database storage. Optional add-ons include cloud-synced data backup (AWS S3), RESTful API integration for LIMS connectivity, and automated calibration certificate import via QR-code scanning.
Applications
- Material qualification in automotive Tier-1 suppliers (e.g., tensile strength of brake hose reinforcement layers, peel adhesion of laminated EV battery encapsulants)
- Pharmaceutical packaging integrity testing (puncture resistance of blister foils, seal strength of pouches per ASTM F88/F1140)
- Academic research on nanocomposites and bioresorbable polymers (modulus, yield point, elongation-at-break under controlled strain rates)
- Quality assurance of wire-and-cable insulation (tensile elongation per IEC 60811-1-1)
- Mechanical validation of orthopedic implant coatings (adhesion strength of hydroxyapatite plasma-sprayed layers)
- Construction material certification (compressive strength of lightweight concrete blocks per ASTM C39)
FAQ
What is the maximum test speed achievable with the JB119 system?
The crosshead speed range is programmable from 0.001 mm/min to 500 mm/min, with speed accuracy maintained within ±0.2% of setpoint across the full range.
Does the JB119 support high-temperature or low-temperature testing?
The base configuration is rated for ambient conditions only; however, it is mechanically compatible with third-party environmental chambers (−70 °C to +300 °C) when mounted on vibration-isolated platforms.
Can test data be exported directly to statistical process control (SPC) platforms?
Yes—CSV and XML exports include all raw channel data and metadata; optional OPC UA or MQTT gateways enable real-time streaming to MES/SPC systems such as Minitab Workspace or Siemens Opcenter.
Is ISO 17025 calibration certification included with purchase?
A factory calibration certificate traceable to NIST standards is provided; ISO 17025-accredited calibration requires separate engagement with an accredited lab and is recommended annually.
What grip types are supplied as standard equipment?
Two sets of manual screw-action wedge grips (flat-faced, 0–20 mm capacity) are included; additional grip configurations are available as configurable accessories.
