LUXIANGYI TG16-WS Benchtop High-Speed Centrifuge

Overview

The LUXIANGYI TG16-WS Benchtop High-Speed Centrifuge is engineered for precision separation of biological suspensions, cell lysates, nucleic acid preparations, and serum/plasma fractions in regulated laboratory environments. Operating on the principle of sedimentation under controlled centrifugal force, it delivers reproducible separation outcomes by generating relative centrifugal forces (RCF) up to 23,669 × g at a maximum rotational speed of 16,000 rpm. Its compact benchtop footprint—measuring only 330 mm × 420 mm × 280 mm—makes it suitable for space-constrained biosafety cabinets, core facilities, and teaching laboratories without compromising mechanical stability or thermal management. The unit employs a brushless DC motor drive system, eliminating carbon brush wear and enabling consistent torque delivery across the full speed range. This architecture supports high-cycle operational durability while maintaining acoustic emissions below 65 dB(A), meeting ISO 21501-4 noise benchmarks for routine laboratory instrumentation.

Key Features

• Microprocessor-based control system with real-time RPM/RCF interconversion and automatic parameter retention across power cycles.
• Capacitive touch interface with intuitive menu navigation and dual-unit display (rpm and ×g) for rapid protocol validation.
• Programmable acceleration/deceleration profiles—nine preset ramp curves enable optimization of pelleting integrity for shear-sensitive samples such as exosomes or ribonucleoprotein complexes.
• Integrated electronic lid lock with automatic engagement detection, overspeed protection, rotor imbalance sensing, and fault-triggered audible/visual alerts compliant with IEC 61010-2-020 safety requirements.
• Thermally stable aluminum rotor chamber with passive cooling design; no external refrigeration required, reducing energy consumption and maintenance overhead.
• Modular rotor compatibility supporting six standard configurations—including fixed-angle rotors for microtubes (0.2–2.2 mL), conical tube rotors (5–15 mL), and swing-bucket assemblies for 50 mL polypropylene tubes—each validated for maximum load and speed ratings per ISO 15195:2019 calibration guidelines.

Sample Compatibility & Compliance

The TG16-WS accommodates a broad spectrum of sample containers—from low-retention PCR tubes to clinical centrifuge tubes—via interchangeable adapters certified for autoclaving (121°C, 20 min). All rotor assemblies are dynamically balanced and serial-numbered for traceability. The instrument meets essential regulatory prerequisites for GLP-compliant workflows: built-in audit trail logging (timestamped start/stop events, rotor ID, speed, time, and RCF), password-protected parameter editing, and non-volatile memory retention of user-defined protocols. While not actively refrigerated, its thermal performance profile aligns with ASTM E2919-22 recommendations for ambient-temperature high-speed centrifugation in QC/QA settings where cryogenic preservation is not mandated.

Software & Data Management

No proprietary software installation is required; all configuration and operation occur via the onboard HMI. However, the system supports optional RS-232 or USB-to-serial interfaces for integration into centralized lab information management systems (LIMS). Exportable run logs include ISO 8601 timestamps, rotor identification codes, actual vs. setpoint speed deviation data, and cumulative runtime metrics—enabling retrospective analysis during internal audits or FDA 21 CFR Part 11–aligned review processes. Firmware updates are delivered via secure USB key with cryptographic signature verification to ensure firmware integrity.

Applications

• Preparative isolation of peripheral blood mononuclear cells (PBMCs) from whole blood using density gradient media (e.g., Ficoll-Paque™).
• Clarification of bacterial culture supernatants prior to protein purification or endotoxin removal steps.
• Concentration of viral vectors (AAV, lentivirus) and extracellular vesicles from conditioned media in gene therapy process development.
• Routine phase separation in immunoassay workflows—including ELISA plate supernatant harvesting and antigen-antibody complex pelleting.
• High-throughput nucleic acid extraction support, particularly in automated liquid handling environments where centrifugation is embedded as a discrete module.
• Quality control testing of vaccine formulations, including particulate matter analysis and adjuvant dispersion homogeneity assessment.

FAQ

Is the TG16-WS compliant with international electrical safety standards?
Yes—the unit conforms to IEC 61010-1 (2010) and IEC 61010-2-020 (2016) for laboratory equipment, with CE marking and third-party verification of dielectric strength, leakage current, and protective earth continuity.
Can this centrifuge be used for clinical diagnostics under CLIA or CAP requirements?
It supports CLIA-waived and moderate-complexity testing when operated within validated protocols; however, final compliance depends on site-specific validation documentation and quality system implementation.
What rotor certification documentation is provided?
Each rotor includes a manufacturer-issued certificate of conformity listing dynamic balance test results, material composition (6061-T6 aluminum alloy), and maximum rated speed per ISO 15195 Annex B.
Does the instrument support remote monitoring or network connectivity?
Native Ethernet or Wi-Fi is not integrated, but analog/digital I/O ports allow connection to building management systems or PLC-controlled lab automation platforms via custom interface modules.
Are replacement rotors and adapters available through global distribution channels?
Yes—BIORIDGE maintains an authorized distributor network across North America, EMEA, and APAC regions; all consumables carry batch-specific traceability and are supplied with updated compatibility matrices aligned with current firmware versions.
