RO Membrane Cartridge for MilliporeSigma IQ 7010, RiOs 16 & Elix 10 Systems (2 per Pack)
| Brand | Deepflow |
|---|---|
| Origin | Shanghai, China |
| Manufacturer Type | Authorized Distributor |
| Regional Category | Domestic (China) |
| Model | CYRC60HA2 |
| Pricing | Available Upon Request |
Overview
The CYRC60HA2 RO membrane cartridge is a precision-engineered reverse osmosis element designed exclusively for integration into MilliporeSigma’s IQ 7010, RiOs 16, and Elix 10 ultra-pure water purification systems. Utilizing thin-film composite (TFC) polyamide membrane technology, this cartridge achieves >99% rejection of dissolved ions, organic molecules (>100 Da), colloids, bacteria, and pyrogens from municipal or pre-treated feed water. Its spiral-wound configuration ensures uniform hydraulic distribution and minimizes fouling susceptibility under continuous laboratory-grade operation. The module operates within standard system pressure ranges of 2–6 bar (29–87 psi), compatible with integrated booster pumps and flow-regulated recirculation loops typical of benchtop and central purification platforms. Designed for seamless drop-in replacement, the CYRC60HA2 maintains full alignment with original equipment manufacturer (OEM) dimensional tolerances, sealing geometry, and flow-path hydraulics—ensuring uninterrupted compliance with ASTM D1193 Type I water specifications when used in validated system configurations.
Key Features
- Thin-film composite (TFC) polyamide active layer optimized for high salt rejection (>99.5% NaCl at 25°C, 500 ppm) and low organic leaching
- Spiral-wound construction with reinforced fiberglass center tube and permeate carrier mesh for mechanical stability across 1,000+ hour service life
- Pre-rinsed and endotoxin-tested (≤0.03 EU/mL) to meet ISO 14644-1 Class 5 cleanroom handling requirements
- Integrated O-ring seals compliant with USP Class VI elastomer standards; compatible with deionized water, low-conductivity rinse cycles, and ozone sanitization protocols
- Batch-certified with traceable lot documentation including pore size distribution (MWCO ~100 Da), flux rate (≥12 L/m²·h at 25°C, 1.5 bar), and chlorine tolerance (<0.1 ppm residual)
Sample Compatibility & Compliance
The CYRC60HA2 is validated for use with feed water meeting ANSI/NSF Standard 58 pre-treatment guidelines—including sediment filtration (≤5 µm), activated carbon adsorption (chlorine removal), and optional softening (hardness 1 ppm), or oxidant-rich streams without upstream mitigation. When installed in IQ 7010, RiOs 16, or Elix 10 systems operating under GLP/GMP-aligned procedures, the cartridge supports audit-ready traceability via serialized lot labels and CoA documentation aligned with ISO/IEC 17025-accredited testing. System-level output complies with ASTM D1193 Type I, CLSI EP28-A3c, and ISO 3696 Grade 1 specifications for resistivity (≥18.2 MΩ·cm at 25°C), total organic carbon (<5 ppb), and bacterial count (<0.1 CFU/mL).
Software & Data Management
While the CYRC60HA2 itself is a passive consumable, its lifecycle is fully trackable within MilliporeSigma’s Elix and RiOs system firmware (v4.2+). Integrated sensors monitor differential pressure (ΔP) across the membrane, real-time permeate conductivity, and cumulative runtime—triggering automated alerts for scheduled replacement (typically every 6–12 months depending on feed quality and daily throughput). All event logs—including installation timestamp, pressure decay trends, and alarm history—are exportable as CSV or PDF via USB or Ethernet interface, supporting 21 CFR Part 11-compliant electronic records when paired with validated system software configurations.
Applications
This RO cartridge serves as the primary desalination stage in multi-step ultrapure water generation for critical laboratory workflows including HPLC mobile phase preparation, ICP-MS calibration standard dilution, cell culture media formulation, ELISA reagent synthesis, and semiconductor wafer rinsing. Its consistent performance under variable inlet conditions enables reproducible water quality across shifts and instruments—reducing variability in analytical baselines, column longevity, and assay sensitivity. In teaching laboratories, it provides a demonstrable platform for studying membrane transport kinetics, concentration polarization effects, and fouling resistance mechanisms under controlled operational parameters.
FAQ
What is the recommended replacement interval for the CYRC60HA2 cartridge?
Replacement is advised after 6–12 months of continuous operation or upon ΔP increase ≥0.8 bar above baseline, whichever occurs first. Actual service life depends on feed water quality, pre-treatment efficacy, and daily usage volume.
Is this cartridge certified for pharmaceutical-grade water production?
The CYRC60HA2 meets material and performance criteria for USP Purified Water and WFI pre-treatment stages but must be deployed within a fully validated system architecture—including post-RO polishing (e.g., EDI, UV oxidation, 0.22 µm filtration) to satisfy FDA 21 CFR 211.65 and EU GMP Annex 1 requirements.
Can the CYRC60HA2 be sterilized using steam or autoclaving?
No. This cartridge is not rated for steam sterilization. Sanitization must follow OEM-recommended protocols—typically hot water (80–85°C) or ozone circulation—and must never exceed 40°C during storage or dry handling.
Does Deepflow provide regulatory documentation for audit support?
Yes. Each shipment includes a Certificate of Analysis (CoA), Material Declaration (RoHS/REACH), and a Statement of Conformance to ISO 9001:2015 manufacturing controls—all available digitally upon request with lot-specific identifiers.
