| Brand | Cubic |
|---|---|
| Model | Gasboard-2503-NH₃ |
| Detection Principle | Tunable Diode Laser Absorption Spectroscopy (TDLAS) |
| Target Gas | NH₃ |
| Measurement Range | 0–50 ppm |
| Accuracy | ±2% FS |
| Response Time (T90) | ≤20 s |
| Measurement Cycle | 1–3600 s |
| Output Interface | RS485 @ 12 V DC |
| Power Supply | 12 V DC |
| Average Power Consumption | ≤1 W |
| IP Rating | IP66 |
| Operating Temperature | 5–40 °C |
| Operating Humidity | 0–100% RH (non-condensing) |
| Atmospheric Pressure | 101 kPa |
| Explosion Protection | UL Class I, Division 2 |
| Design Life | 10 years |
| Application | Livestock Housing Air Quality Monitoring |
