| Brand | Prescott |
|---|---|
| Origin | United Kingdom |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported |
| Model | Rheoline MDR |
| Price | Upon Request |
| Standard Compliance | ISO 6502, ASTM D5289 |
| Oscillation Frequency | 1.67 Hz |
| Oscillation Amplitude Options | 0.5° (standard), 1.0° or 3.0° (optional) |
| Temperature Range | 35–250 °C |
| Temperature Control | Digital PID |
| Torque Units | in·lb, dN·m |
| Temperature Units | °C, °F |
| Pressure Units (optional) | psi, kg/cm² |
| Time Format | min/sec, min/decimal, sec |
| Output Parameters | Elastic Modulus (G′), Viscous Modulus (G″), Tan δ, Curing Rate, Cavity Pressure (optional) |
| Data Storage | Microsoft Access or SQL database |
| Optional Accessories | Programmable multi-zone heating, Eccentric oscillating die, Cavity pressure transducer, Automated sample loader, Volumetric sample cutter |
| Software | Windows-based proprietary test platform with SPC module (optional), GLP/GMP-compliant audit trail support |
| Brand | TMI |
|---|---|
| Origin | USA |
| Model | 83-20 |
| Measurement Principle | Pendulum-type Elmendorf method |
| Max Range | 64,000 mN |
| Range Steps | 4,000 / 8,000 / 16,000 / 32,000 / 64,000 mN |
| Accuracy | ±1% of reading or ±0.25% of selected range |
| Sample Cut | Automatic pre-notch |
| Clamping | Pneumatic-mechanical dual-action clamp |
| Display | Digital force readout |
| Data Interface | RS-232 serial output |
| Safety | Interlocked transparent guard |
| Reset Mechanism | Motorized pendulum repositioning |
| Brand | Betacontrol |
|---|---|
| Origin | Germany |
| Model | Indicon One |
| Sensor Technology Options | Beta-ray transmission/backscatter, Infrared, Ultrasonic, Laser, X-ray, Microwave, White-light Interferometry |
| Application Scope | Polymer films, metal foils, nonwovens, paperboard, coated substrates, rubber layers, foam materials, laminates, and electroplated surfaces |
| Compliance Context | Designed for integration into industrial automation systems compliant with ISO 9001 process control requirements and suitable for GLP/GMP-aligned production environments |
| Pricing | Available upon technical consultation |
| Brand | Labtech Engineering |
|---|---|
| Roll Diameter | 150 mm |
| Configuration | Horizontal Open Two-Roll Mill |
| Drive Type | Variable-Frequency AC Motor with Precision Speed Control |
| Roll Surface | Chrome-Plated Steel |
| Roll Gap Adjustment | Manual Micrometer with Digital Readout |
| Safety Compliance | CE Marked, EN ISO 13857 & EN 61800-5-1 Compliant |
| Construction | Heavy-Duty Cast Iron Frame with Reinforced Bearing Housings |
| Temperature Control Option | Optional Water-Cooled or Electrically Heated Rolls (±1 °C Stability) |
| Power Supply | 380–415 V, 3-Phase, 50/60 Hz |
| Dimensions (L×W×H) | 1850 × 920 × 1280 mm |
| Weight | Approx. 1,450 kg |
