| Brand | Avantes |
|---|---|
| Origin | Netherlands |
| Model | AvaField-EDU |
| Spectral Range | 350–1050 nm |
| Spectral Resolution | 2.5 nm |
| Spatial Resolution (IFOV) | 0.18 mrad |
| Field of View (TFOV) | 8° |
| Imaging Resolution | 14 × 200 µm |
| Frame Rate | 15 fps |
| Optical Design | Filter-based with binary optical element |
| Measurement Platform | Ground-based |
| Detector | 2048-pixel CCD |
| Pixel Size | 14 × 200 µm |
| Wavelength Accuracy | ±0.5 nm |
| Spectral Sampling Interval | 0.6 nm |
| Minimum Integration Time | 1.1 ms |
| Dark Current Compensation | Dynamic onboard correction |
| Environmental Rating | IP54 (dust- and splash-resistant) |
| Operating Temperature | 0–40 °C |
| Storage Temperature | −15–55 °C |
| Dimensions | 170 × 120 × 60 mm |
| Weight | 0.8 kg |
