| Brand | Agiltron |
|---|---|
| Origin | USA |
| Model | PeakSeeker Pro |
| Excitation Wavelength | 785 nm |
| Laser Power | 5–300 mW |
| Spectral Range | 200–3000 cm⁻¹ |
| Spectral Resolution | ≈12 cm⁻¹ |
| Wavelength Stability | <1 cm⁻¹ over 12 h |
| Photometric Stability | <4% over 12 h |
| Numerical Aperture | NA = 0.22 |
| Sample Spot Size | 0.1–0.3 mm |
| Dimensions (W×D×H) | 36 × 29 × 11 cm |
| Weight | <3.6 kg |
| Operating Temperature | −25°C to +45°C |
| Power Input | 100–240 VAC, 50/60 Hz → 15 VDC adapter |
| Brand | Agiltron |
|---|---|
| Origin | USA |
| Model | PinPointer |
| Instrument Type | Handheld Raman Spectrometer |
| Excitation Wavelength | 785 nm |
| Laser Power | 5–500 mW |
| Raman Spectral Range | 200–2400 cm⁻¹ |
| Spectral Resolution | ~10 cm⁻¹ |
| Raman Shift Stability | < 1 cm⁻¹ over 12 h |
| Photometric Stability | < 4% over 12 h |
| Collection Numerical Aperture | 0.28 |
| Working Distance | 5 mm |
| Spot Size | < 0.2 mm |
| Power Supply | Rechargeable Li-ion battery + universal AC adapter (100–240 V, 50/60 Hz) |
| Dimensions | 216 × 109 × 64 mm |
| Weight | 1.36 kg |
| Operating Temperature | −25 °C to +70 °C |
| Brand | HORIBA |
|---|---|
| Origin | USA |
| Model | Duetta |
| Wavelength Range (Fluorescence) | 250–1100 nm |
| Spectral Bandwidth (Slit) | 1–20 nm |
| Optical Resolution | 1 nm |
| Sensitivity (Water Raman RMS) | 6000:1 |
| Wavelength Accuracy | ±1 nm |
| Dispersion Element | Grating |
| Detector | CCD |
| Measurement Modes | Simultaneous Fluorescence & Absorbance |
| A-TEEM™ Capability | Yes |
| Auto Inner-Filter Correction | Yes |
| Brand | HORIBA |
|---|---|
| Origin | France |
| Model | Smart SE |
| Spectral Range | 450–1000 nm |
| Spot Size Options | Multiple Micro-Spot Sizes with Real-Time Visual Observation |
| Incidence Angle | Variable (Motorized Multi-Angle Capability) |
| Measurement Speed | Full-Spectrum Acquisition in <1 Second |
| Single-Measurement Time | <2 s (Typical, Including Stage Positioning) |
| Sample Stage | Motorized XYZ Translation (200 mm × 200 mm Travel, Z-Travel >35 mm) |
| Detector | CCD-Based Spectral Analyzer |
| Modulation Technology | Liquid Crystal Variable Retarder (LCVR), No Moving Parts in Optical Path |
| Configuration Flexibility | Supports Both In-Line Process Integration and Stand-Alone Lab Use |
| Compliance | Designed for ISO/IEC 17025-Compatible Metrology Environments |
| Software | HORIBA DeltaPsi² Platform with Audit Trail, User Access Control, and Exportable Raw Data (CSV, XML, HDF5) |
| Brand | HORIBA |
|---|---|
| Origin | France |
| Model | PP-TOFMS |
| Acquisition Rate | 1 spectrum per 30 µs |
| Mass Resolution | 5,000 (at m/z 208, high-resolution mode) |
| Dynamic Range | 10⁷ |
| Mass Accuracy | ±40 ppm |
| Sensitivity | 10³ cps/ppm |
| Depth Resolution | <1 nm |
| Ion Mode | Positive and Negative |
| Flexible Ion Blanking | Up to 4 ions |
| Sample Loading | Horizontal, ambient-pressure compatible |
| Mass Coverage | H to U, including isotopes and molecular species |
| Analysis Mode | Pulsed RF sputtering with 3D depth profiling capability |
| Quantification | Matrix-effect-reduced semi-quantitative analysis without calibration standards |
