| Brand | Ted Pella |
|---|---|
| Origin | USA |
| Model | 36500-230 |
| Microwave Power | 100–750 W (1 W increments) |
| Frequency | 2.45 GHz |
| Temperature Control Accuracy | ±1 °C (aqueous samples) |
| Time Range | 1 s – 96 h |
| Vacuum Capacity | 20 inHg (three programmable modes) |
| Integrated Water-Cooling Flow | 1.5 L/min |
| Internal Magnetic Stirring | 0–3000 rpm |
| Touchscreen Interface | 7″ industrial-grade capacitive touchscreen |
| Method Storage | Up to 204-step protocols |
| Dimensions (W×D×H) | 553 × 514 × 546 mm |
| Weight | 37 kg |
| Certifications | ETL, CE |
| Voltage | 230 V, 10 A |
| Brand | Ted Pella |
|---|---|
| Origin | USA |
| Type | Manual Cleaving Instrument |
| Model | Small Sample Cleaver |
| Sample Width Capacity | 3–15 mm |
| Sample Thickness Range | 200–900 µm |
| Cleave Platform Dimensions | ≤2 × 2 mm |
| Indent Length | 0.5 mm |
| Compatibility | Designed for use with PELCO® LatticeAx® (1 mm indent) |
| Mounting | Four magnetic fixation points |
| Portability | Handheld, volume ≈ 100 mm³ |
| Brand | Ted Pella |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Imported |
| Model | LatticeAx 225 |
| Maximum Scribe Line Speed | 600 mm/min |
| Application Scope | Semiconductor Wafers, MEMS, Optoelectronics, and Thin-Film Devices |
| Positioning Accuracy | ±20 µm |
| Scribe Impression Length | <1 mm |
| Impression Width | ~10 µm |
| Imaging System | USB 2.0 Digital Microscope with Polarizing Filter and Real-Time Capture Software |
| Vacuum Fixation | Pneumatically Actuated Valve-Controlled Pump |
| Sample Compatibility | Si, SiC, GaAs, Sapphire, Glass, Quartz, and Thin-Film Substrates (Ø50–300 mm, Thickness 100–1000 µm) |
