| Brand | Jinhuatester |
|---|---|
| Model | TH-02 |
| Measurement Principle | 0°/Diffuse (CIE 15:2018 compliant) |
| Standards Compliance | ASTM D1003, ASTM D1044, ISO 13468, ISO 14782, GB/T 2410, JIS K 7105, JIS K 7361, JIS K 7136 |
| Illuminants | CIE A, C, D65 |
| Measured Parameters | Haze (%), Total Luminous Transmittance (%) |
| Aperture Sizes | 21 mm, 7 mm |
| Response Time | ≤1.5 s |
| Repeatability | ±0.05% |
| Resolution | 0.01% |
| Sample Thickness Limit | ≤145 mm |
| Display | 7-inch capacitive touchscreen (Android OS) |
| Optical Geometry | 0/D (Illumination Normal / Diffuse Collection) |
| Light Source | Long-life LED (rated >50,000 h) |
| Data Storage | Internal flash memory (≥100,000 records) |
| Interface | USB Type-A |
| Power Supply | DC 12 V / 3 A |
| Operating Temperature | 5–40 °C, RH ≤80% (non-condensing at ≤35 °C) |
| Storage Temperature | −20–45 °C, RH ≤80% (non-condensing at ≤35 °C) |
| Dimensions (L×W×H) | 310 × 215 × 540 mm |
| Weight | 6 kg |
| Brand | Jinhuatester |
|---|---|
| Origin | Shandong, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | China |
| Model | YLY-01S |
| Measurement Principle | Photoelastic Compensation & Interference Color Analysis (with λ/4 and Full-Wave Retardation Plates) |
| Measurement Accuracy | ≤2 nm |
| Retardation Resolution | 0.1 nm |
| Angular Resolution | 0.1° |
| Polarization Field Diameter | 150 mm |
| Analyzer Rotation Range | ±180° (360° total) |
| Field Luminance | >120 cd/m² |
| Adjustable Sample Gap | 50–250 mm |
| Power Consumption | <8 W |
| Light Source | LED (3500 K) |
| Net Weight | 8 kg |
| Compliance | GB/T 4545, GB/T 12415, GB/T 15726, GB/T 18144, YBB00162003, JC/T 655, JC/T 915, ASTM C148 |
| Brand | Jinhuatester |
|---|---|
| Origin | Shandong, China |
| Manufacturer Type | Direct Manufacturer |
| Model | YLY-01C |
| Measurement Accuracy | ≤2 nm |
| Retrace Error | ≤2 nm |
| Optical Path Difference Resolution | 0.1 nm |
| Angular Resolution | 0.1° |
| Polarization Field Diameter | 150 mm |
| Analyzer Rotation Range | 360° (±180°) |
| Luminance | >120 cd/m² |
| Adjustable Sample Spacing | 80–250 mm |
| Max Power Consumption | <30 W |
| Light Source | LED (3500 K) |
| Power Supply | AC 220 V, 50 Hz |
| Net Weight | 10 kg |
| Compliance Standards | GB/T 4545, GB/T 12415, GB/T 15726, GB/T 18144, YBB00162003, JC/T 655, JC/T 915, ASTM C148 |
| Brand | Jinhuatester |
|---|---|
| Model | TH-02 |
| Measurement Principle | 0/D geometry (diffuse transmission) |
| Standards Compliance | ASTM D1003, ASTM D1044, ISO 13468, ISO 14782, GB/T 2410, JIS K 7105, JIS K 7361, JIS K 7136 |
| Illuminants | CIE-A, CIE-C, CIE-D65 |
| Aperture Sizes | 21 mm, 7 mm |
| Display | 7-inch capacitive touchscreen, Android OS |
| Measurement Time | ≤1.5 s |
| Repeatability | ±0.05% |
| Resolution | 0.01% |
| Transmittance Range | 0–100% |
| Sample Thickness Limit | ≤145 mm |
| Power Supply | DC 12 V / 3 A |
| Operating Temperature | 5–40 °C, RH ≤80% (non-condensing at 35 °C) |
| Storage Temperature | −20–45 °C, RH ≤80% (non-condensing at 35 °C) |
| Dimensions (L×W×H) | 310 × 215 × 540 mm |
| Weight | 6 kg |
| Interface | USB |
