| Brand | Asahi Spectra |
|---|---|
| Origin | Japan |
| Model | MAX-303 |
| Light Source Type | 300W Compact Xenon Arc Lamp |
| Illumination Method | External Fiber-Coupled Illumination |
| Spectral Output Range | 235–1050 nm (dependent on mirror module and filter selection) |
| Mirror Modules Available | UV (250–385 nm), UV-VIS (300–600 nm), VIS (385–740 nm), IR (750–1050 nm) |
| Filter Wheel | 8-position, accepts 25 mm diameter × 6 mm thick filters |
| Light Intensity Control | Continuous ND-type attenuation, ±5% stability |
| Shutter | Pulse-motor-driven, exposure time 0.5–99999.9 s |
| Cooling | Forced-air convection |
| Power Supply | Switching-mode, AC 100–240 V, 50/60 Hz |
| Max Power Consumption | ≤530 VA (100 V/60 Hz), ≤520 VA (240 V/50 Hz) |
| Lamp Lifetime | ~500 h (to 50% initial radiant flux) |
| Operating Environment | 10–35 °C, 20–80% RH (non-condensing) |
| Dimensions (W×D×H) | 196 × 345 × 302 mm |
| Weight | 12.9 kg |
| Remote Interface | RS232C (cable length ≤3 m) |
| Brand | Asahi Spectra |
|---|---|
| Model | HAL320W |
| Light Source | Compact Xenon Lamp (300 W) |
| Spectral Range | 350–1800 nm |
| Spectral Match Class | JIS/IEC AAA (per JIS C8912:2011 & C8933:2011) |
| Output Method | Bundled Optical Fiber (Cartridge-Type, Alignment-Free) |
| AM Filter | Integrated Air Mass 1.5G |
| Irradiance Stability | ≤ ±1% (temporal, over 1 h) |
| Spatial Uniformity | ≤ ±2% (30 × 30 mm, A-class area at 1-sun, 75 mW/cm² @ 400–1100 nm) |
| Control | Remote Controller + RS232C Interface |
| Cooling | Forced Air |
| Lamp Life | 500 h (average) |
| Input | AC 90–264 V, 50/60 Hz |
| Power Consumption | < 510 VA |
| Dimensions (Main Unit) | 200 × 300 × 292 mm |
| Weight | 11.3 kg |
| Brand | Asahi Spectra |
|---|---|
| Origin | Japan |
| Model | MAX-400D |
| Light Source Type | Dual 400W Xenon Arc Lamps (VIS) |
| Spectral Range | 400–700 nm (with YSC0750 ultra-cold filter) |
| Input Voltage | AC 100–240 V ±10%, 50/60 Hz |
| Power Consumption | ≤1360 VA |
| Lamp Operating Conditions | DC 14.3 V, 28 A (per lamp) |
| Rated Lamp Life | 500 h (under specified operating conditions) |
| Illumination Method | External (non-contact, off-axis) |
| Cooling | Forced-air cooling |
| Control Interface | RS-485 remote control |
| Optical Output Coupling | Integrated bifurcated fiber-optic light guide (standard) |
| Filter Mount | 50 mm diameter or 50×50 mm square, thickness <6 mm |
| Dimensions | 390 × 341 × 292 mm (W×D×H) |
| Weight | 19.8 kg |
| Brand | Asahi Spectra |
|---|---|
| Origin | Japan |
| Model | HAL-320 |
| Light Source | Compact Xenon Lamp (300 W) |
| Spectral Range | 350–1100 nm |
| Spectral Match Class | JIS/IEC AAA (AM1.5G) |
| Illumination Method | External via Bundled Light Guide |
| Optical Alignment | Cartridge-Type (Alignment-Free) |
| Power Supply | Switching Type, AC 90–264 V, 50/60 Hz |
| Apparent Power | ≤510 VA |
| Lamp Voltage/Current | 14 V / 21 A (DC) |
| Lamp Life | 500 h (avg.) |
| Cooling | Forced Air |
| Shutter | Solenoid-Driven |
| Exposure Time | 0.5–99999.9 s |
| Intensity Control | 100–30 Steps + Continuous Adjustment |
| AM Filter | Integrated Air Mass 1.5G |
| Controller Interface | RS232C (cable ≤3 m), Remote Handheld (2 m) |
| Safety Interlocks | Lamp Fault, Top Door Open, Lamp Usage >500 h, Fan Failure, Thermal Anomaly |
| Operating Environment | 10–35 °C, 20–80% RH (non-condensing) |
| Dimensions (Main Unit) | 200 × 300 × 292 mm |
| Weight (Main Unit) | 11.3 kg |
| Brand | Asahi Spectra |
|---|---|
| Origin | Japan |
| Model | MAX-350 |
| Light Source Type | 300W Cermax Xenon Lamp |
| Illumination Mode | External Irradiation |
| Output Wavelength Range | 250–1050 nm (dependent on mirror module) |
| Mirror Modules | UV (250–385 nm), UV-VIS (300–600 nm), VIS (385–740 nm), IR (750–1050 nm) |
| Filter Wheel | 8-position, accepts 25 mm Ø × <6 mm filters |
| Light Intensity Control | 1000–50 steps (continuously variable ND attenuation) |
| Shutter | Pulsed motor-driven, exposure time 0.5 s – 24 h |
| Cooling | Forced-air |
| Power Input | AC 100–240 V, 50/60 Hz |
| Apparent Power | <540 VA (100 V/50 Hz), <520 VA (240 V/50 Hz) |
| Lamp Lifetime | ≥500 h (guaranteed within 1 year of delivery) |
| Optical Alignment | Cartridge-type, alignment-free design |
| Dimensions | 196 × 330 × 302 mm (W×D×H) |
| Weight | 12.2 kg |
| Operating Environment | 10–35 °C, 20–80% RH (non-condensing) |
| Safety Interlocks | Xenon lamp fault detection, cooling fan monitoring, thermal anomaly protection |
| Remote Interface | RS-485 |
| Controller | Integrated touchscreen panel |
| Brand | Alluxa |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Product Category | Imported Optical Component |
| Model | 7065 |
| Component Type | Optical Filter |
| Brand | Alluxa |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Product Category | Optical Component |
| Model | 7365 |
| Substrate | Fused Silica |
| Center Wavelength | 310 nm ± 2.0 nm |
| Full Width at Half Maximum (FWHM) | 10 nm ± 2.0 nm |
| Peak Transmission | >70% T Absolute |
| Blocking Level | OD4 |
| Blocking Range(s) | OD4 from 200–295 nm and 325–1200 nm |
| Diameter | 25.0 mm |
| Thickness | 2.0 mm |
| Mount | Anodized Aluminum Ring |
| Total Assembly Thickness | 5.0 mm |
| Angle of Incidence | 0° |
| Brand | TMC |
|---|---|
| Origin | USA |
| Model | STACIS Floor Platform 65 |
| Compliance | ASTM E1492, ISO 20486, SEMI S2 |
| Load Capacity | Up to 2,500 kg (configurable) |
| Active Isolation Bandwidth | 0.6–150 Hz |
| Residual Vibration | < 10 nm RMS (1–100 Hz) |
| Platform Material | 304 Stainless Steel |
| Footprint Customization | Yes, full dimensional and cutout flexibility |
| Controller | STACIS II Digital Feedback System with Ethernet/RS-232 Interface |
| Power Requirement | 100–240 VAC, 50/60 Hz |
| Environmental Operating Range | 15–30 °C, < 70% RH non-condensing |
