Optical Laboratory Equipment
Filter
Showing 481–510 of 607 results
| Brand | ZOLIX |
|---|---|
| Model | Omni-λBright300 |
| Light Source Type | 75 W Xenon Lamp |
| Wavelength Range | 260–1000 nm |
| Spectral Bandwidth | 1–22 nm (continuously adjustable) |
| Wavelength Accuracy | ±0.2 nm |
| Wavelength Repeatability | ±0.1 nm |
| Output Power | 22 mW (at 90° port, dependent on grating, slit width, and wavelength) |
| Optical Output | SMA905 fiber connector (quartz fiber, UV-VIS-NIR grade) |
| Beam Height | 160 mm (185 mm with base plate and rubber feet) |
| Dimensions | 870 × 320 × 335 mm |
| Weight | 30 kg |
| Stability | ±0.5% (rms over 8 hours) |
| Interface | USB 2.0 |
| Compliance | CE-marked, RoHS-compliant, GLP-ready documentation provided |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | OMPO12.7/25.4/30-B |
| Mounting Aperture (A) | 11 mm / 23 mm / 27 mm |
| Clamping Diameter (B) | 12.7 mm / 25.4 mm / 30 mm |
| Center Height (C) | 33 mm / 33 mm / 37 mm |
| Total Height (D) | 56 mm / 56 mm / 64 mm |
| Rotation Range (θx) | ±360° |
| Angular Resolution | 2° |
| Thickness | 16 mm |
| Compatible Accessories | PHSP12-Series Posts |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Model | OMRS-LBE22/WJ/CMount |
| Mounting Interface (LBE22) | M22×0.75 |
| Mounting Interface (WJ) | 4/5″–1/36 UNC |
| Mounting Interface (CMount) | 1″–1/32 UNC |
| Angular Adjustment Range | ±3° per axis |
| Degrees of Freedom | 2-axis (tip/tilt) |
| Compliance | Designed for ISO-standard optical breadboard compatibility (M6/M4 tapped holes) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Product Origin | Domestic (China) |
| Model | OMRS12.7-CS / OMRS20-CS / OMRS25-CS / OMRS25.4-CS / OMRS30-CS |
| Clamping Diameter A | 12.7 mm / 20 mm / 25 mm / 25.4 mm / 30 mm |
| Clear Aperture B | 11 mm / 18 mm / 23 mm / 23 mm / 28 mm |
| Angular Adjustment Range | ±3° (Pitch & Yaw) |
| Center Height D | 25 mm (OMRS12.7–25.4-CS), 27.5 mm (OMRS30-CS) |
| Front Plate Width E | 50 mm (OMRS12.7–25.4-CS), 55 mm (OMRS30-CS) |
| Total Width F | 53 mm (OMRS12.7–25.4-CS), 58 mm (OMRS30-CS) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | OMRS12.7/20/25/30-BS |
| Pricing | Upon Request |
| Clamping Diameter A (mm) | 12.7 / 20 / 25 / 30 |
| Clear Aperture B (mm) | 11 / 18 / 22 / 27 |
| Angular Adjustment Range (°) | ±3 / ±3 / ±3 / ±3 |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | OMRS12.7/20/25/30-S |
| Quotation | Upon Request |
| Clamping Diameter A (mm) | 12.7 / 20 / 25 / 30 |
| Clear Aperture B (mm) | 11 / 18 / 22 / 27 |
| Angular Adjustment Range (°) | ±3 / ±3 / ±3 / ±3 |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | OMRS38.1/50-BS |
| Quotation | Upon Request |
| Clamp Diameter A | 38.1 mm / 50 mm (or 50.8 mm) |
| Clear Aperture B | 35 mm / 47 mm |
| Angular Adjustment Range | ±3° |
| Angular Resolution | Not Specified |
| Repeatability | Not Specified |
| Material | Not Specified |
| Mounting Holes | Not Specified |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer | ZOLIX (OEM/ODM Capable) |
| Model | OMRS38.1/50-S |
| Clamping Diameter A | 38.1 mm / 50 mm (dual-option design) |
| Clear Aperture B | 35 mm / 47 mm |
| Angular Adjustment Range | ±3° per axis |
| Construction | Precision-machined aluminum alloy with hardened stainless steel adjustment screws |
| Mounting Base | Standard M6 threaded holes (center-to-center spacing 25.4 mm) |
| Compatibility | Compatible with 30 mm and 50 mm optical rail systems |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Origin | Domestic (China) |
| Model | OMRS38.1/50/50.8-CS |
| Quotation | Upon Request |
| Clamping Diameter A | 38.1 mm |
| Clamping Diameter B | 50 mm |
| Clamping Diameter C | 50.8 mm |
| Clear Aperture | 35 mm / 47 mm / 47 mm |
| Angular Adjustment Range | ±3° for all axes |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Line | OMRSxx Series |
| Mounting Aperture Range | 12.7 mm to 50.8 mm |
| Adjustment Mechanism | Dual-Axis Micrometer-Grade Fine-Pitch Threaded Actuation |
| Mounting Options | Closed-Type Set-Screw (Standard), Open-Type Set-Screw (-B), Closed-Type Retaining Ring (-C) |
| Locking Options | Non-Locking (Standard) or Integrated Mechanical Lock (-S) |
| Material | Anodized Aluminum Alloy (6061-T6) with Stainless Steel Adjustment Screws |
| Compliance | Designed for ISO/IEC 17025-aligned optical alignment workflows |
| Software Integration | None (Manual Precision Mechanical System) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Line | OMRSxx-B Series |
| Mounting Aperture (A) | 12.7–50.8 mm |
| Clear Aperture (B) | 11–47 mm |
| Angular Adjustment Range | ±3° in Both Pitch and Yaw Axes |
| Mounting Interface | Dual-Orientation Threaded Holes (M4 & M6) |
| Base Material | Anodized Aluminum Alloy |
| Contact Surface | Triple PTFE-Tipped Adjustment Points |
| Structural Design | Open-Frame Kinematic Configuration |
| Compliance | Designed for ISO/IEC 17025-aligned optical alignment workflows |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Regional Category | Domestic (China) |
| Model | OMUS |
| Price Range | USD 700 – 1,400 (FOB) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Line | OMUS Series |
| Material | 304 Stainless Steel |
| Vacuum Compatibility | Yes (with vacuum-grade lubricant) |
| Spring Configuration | Quad-spring design (except OMUS12.7) |
| Thread Specification | Fine-pitch precision-ground threads with integrated locking mechanism |
| Mounting Options | Dual clamping mode (spring-actuated blade + set-screw), removable blade |
| Locking System | Dual-stage — thread-locking collar + front/rear plate locking threads |
| Adjustment Interface | Rear hex socket for wrench or included ergonomic handwheel |
| Base Plate Thickness | 18 mm |
| Standard Mounting Holes | M4 and M6 compatible |
| Compliance | Designed for ISO/IEC 17025-aligned optical alignment workflows, compatible with UHV-compatible assembly protocols when specified |
| Brand | ZOLIX |
|---|---|
| Model | OMxA |
| Type | Precision Multi-Dimensional Optical Mount |
| Adjustment Axes | 4–6 Degrees of Freedom (DOF) |
| Linear Travel (Y/Z) | ±2 mm |
| Angular Range (θy/θz) | ±3° |
| Axial Translation (X) | 6 mm |
| Rotation about Optical Axis (θx) | 360° |
| Mounting Interface | M4 tapped holes & φ6.5 counterbored holes |
| Standard Thread for Beam Expander | M22×0.75 |
| Cable Management | Open-back rear plate design |
| Compatibility | Universal adapter system (e.g., MAD-M22-xx series) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | OEM/ODM Producer |
| Product Category | Domestic |
| Models | OPBS10-488, OPBS20-488, OPBS10-514, OPBS20-514, OPBS10-532, OPBS20-532, OPBS10-632.8, OPBS20-632.8, OPBS10-1064, OPBS20-1064, OBPS20-0406, OBPS20-0608, OBPS20-0912, OBPS20-1215 |
| Transmission (TP) | >95% for p-polarized light |
| Reflection (RS) | >99% for s-polarized light |
| Extinction Ratio | >100:1 |
| Cube Side Length | 10 mm or 20 mm |
| Wavelength Options | 488 nm, 514 nm, 532 nm, 632.8 nm, 1064 nm (narrowband) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | OEM/ODM Producer |
| Country of Origin | China |
| Model Range | OPSP12.7, OPSP25.4, and Custom Sizes |
| Optical Aperture | Ø8.9 mm (OPSP12.7), Ø20.3 mm (OPSP25.4) |
| Wavelength Range | 400–700 nm |
| Substrate Thickness | 4 mm |
| Polarization Efficiency | >99.9% (typical extinction ratio ≥1000:1) |
| Damage Threshold (CW) | ≤100 W/cm² |
| Damage Threshold (Pulsed, 13 ns) | ≤6 J/cm² |
| Mounting | Unmounted or Optional Aluminum Ring Mount |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | OEM/ODM Producer |
| Product Category | Optical Component |
| Filter Type | Interference Filter (Narrowband, Bandpass, Edge, Notch) |
| Coating Technology | Multi-layer Dielectric Thin-Film Deposition |
| Compliance | ISO 10110-7, MIL-C-48497A (typical), RoHS-compliant materials |
| Spectral Range | UV–VIS–NIR (200–1200 nm, customizable per design) |
| Surface Quality | 60-40 scratch-dig |
| Parallelism | <3 arcsec |
| Clear Aperture | ≥90% of diameter |
| Substrate Material | Fused Silica, BK7, or CaF₂ (application-dependent) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Origin Category | Domestic |
| Models | OPR Series (Right-Angle, Equilateral, Pentaprism, Corner Cube), OPRM20-20, OPRC25.4-19, PPB-10-4 to PPB-25-4, SIGMA Dove Prism, CCH-25.4-1-LEBG, etc. |
| Material Options | K9, ZF2, BK7 optical glass |
| Surface Accuracy | λ/4 typical |
| Reflective Coating | Enhanced aluminum + black paint (PPB series), uncoated or custom AR/HR options available |
| Angular Tolerance | ≤3 arcminutes (pentaprisms), ≤5 arcseconds (corner cubes) |
| Beam Deviation | ≤5″ for corner cube retroreflectors |
| Compliance | ISO 10110-7, MIL-PRF-13830B surface quality standards |
| Brand | ZOLIX |
|---|---|
| Model | OTBB Series |
| Material | Ferromagnetic stainless steel top layer, carbon steel bottom layer, honeycomb (grid or cylindrical) aluminum or steel core |
| Thickness | 50 mm (standard), 100 mm (custom) |
| Surface flatness | 0.1 mm per 600 mm × 600 mm |
| Mounting hole pattern | 25 mm × 25 mm square grid |
| Thread specification | M6 tapped holes |
| Weight | ~11.5 kg for 300 mm × 300 mm variant |
| Surface finish | Matte (low-reflectivity) ground finish |
| Structural design | Three-layer sandwich architecture with precision-ground top plate |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | Domestic (China) |
| Model | OTNS Series |
| Component Category | Accessory Stand |
| Construction Material | Rectangular Hollow Structural Steel |
| Surface Finish | Matte Coating |
| Fabrication Method | Full Welded Monocoque Structure |
| Adjustability | Continuously Height-Adjustable |
| Mobility | Equipped with Locking Casters and Adjustable Levelling Feet |
| Compliance | Designed for Integration with ISO 10816-1 Compliant Optical Tables |
| Brand | ZOLIX |
|---|---|
| Model | OTR Series |
| Origin | Beijing, China |
| Manufacturer | ZOLIX (Producer) |
| Table Thickness Options | 100 mm / 200 mm / 300 mm |
| Surface Flatness | 0.02–0.05 mm per 600 mm × 600 mm |
| Mounting Hole Pattern | M6 threaded holes on 25 mm × 25 mm grid |
| Inherent Frequency Range | <5–8 Hz |
| Table Structure | Three-layer sandwich (top: 4–6 mm ferromagnetic stainless steel |
| core | steel honeycomb grid |
| bottom | 4–6 mm carbon steel with black powder coating) |
| Side Panels | Inner carbon steel + outer black aluminum-plastic laminate |
| Base Frame | Fully welded, 4- or 6-point support with height-adjustable mechanism (±20 mm range) and casters |
| Total Height | 800 mm (adjustable) |
| Mass Loading Capacity | ~120 kg/m² (100 mm), ~140 kg/m² (200 mm), ~167 kg/m² (300 mm) |
| Damping System | High-performance precision damped isolators (upper) + standard damped pads (lower) |
| Brand | ZOLIX |
|---|---|
| Model | OTSB |
| Material | Anodized Aluminum (Black Oxide Finish) |
| Thickness | 13 mm |
| Surface Flatness | ≤ 0.3 mm per 600 mm |
| Hole Pattern | 25 mm × 25 mm (M6 Tapped Holes) |
| Weight | ~3 kg (300 mm × 300 mm variant) |
| Custom Options | Metric/Imperial Hole Spacing (25.4 mm), Increased Thickness (19 mm), 1/4″-20 Threaded Holes |
| Origin | Beijing, China |
| Manufacturer | ZOLIX Optics |
| Brand | ZOLIX |
|---|---|
| Model | OTSB Series |
| Material | Anodized Black Aluminum Alloy |
| Thickness | 13 mm |
| Surface Flatness | 0.3 mm per 600 mm × 600 mm |
| Hole Pattern | 25 mm × 25 mm (M6 threaded) |
| Weight | ~3 kg (for 300 mm × 300 mm variant) |
| Origin | Beijing, China |
| Manufacturer Type | OEM/ODM Producer |
| Compliance | Designed for ISO/IEC 17025-compliant optical alignment environments |
| Optional Configurations | Metric (M6), Imperial (1/4"-20), Custom Pitch (25.4 mm), and Increased Thickness (19 mm) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Country of Origin | Domestic (China) |
| Model | OTSS-15 / OTSS-18 / OTSS-20 / OTSS-24 / OTSS-30 |
| Length Options | 1500 mm / 1800 mm / 2000 mm / 2400 mm / 3000 mm |
| Mounting Interface | Standard T-slot with M6 threaded holes (pitch: 25 mm) |
| Structural Design | Modular, tool-free reconfigurable assembly |
| Compliance | Engineered to meet ISO 14738 (Safety requirements for optical tables and supporting structures) and GB/T 23131–2008 (Mechanical properties of laboratory equipment frames) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | OEM Manufacturer |
| Product Category | Optical Component |
| Model | PBS12 / PBS25 Series |
| Dimensions | 12.7 mm × 12.7 mm × 12.7 mm (PBS12) |
| Material | UV-Fused Silica |
| Coating | Broadband AR (Rₐᵥg < 0.5%) or Laser-Line V-Coating (Rₐᵥg < 0.25% @ design wavelength) |
| Polarization Extinction Ratio | Tp:Ts > 3000:1 (laser-line variants), > 2000:1 (high-power variants) |
| Surface Flatness | λ/4 @ 633 nm |
| Wavefront Distortion (transmission) | λ/4 @ 633 nm |
| Surface Quality | 40/20 scratch-dig |
| Clear Aperture | ≥80% |
| Deviation Angle | Transmission: 0° ± 5 arcmin |
| Reflection | 90° ± 5 arcmin |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | OEM/ODM Manufacturer |
| Product Line | PHK Series |
| Price Range | USD 700 – 1,400 (FOB) |
| Compatibility | Standard M4 & M6 threaded components |
| Packaging | Rugged carry-case with labeled compartments |
| Configurations | PHK12-20 (for Ø12 mm posts) and PHK25-16 (for Ø25 mm posts) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | OEM/ODM Manufacturer |
| Product Origin | Domestic (China) |
| Models | Comprehensive Range of Standard & Custom Sizes |
| Pricing | Available Upon Request |
| Material Options | BK7 (K9) Optical Glass, UV Fused Silica |
| Design Wavelength | 587.6 nm |
| Diameter Tolerance | +0.0 / −0.1 mm (Plano-Concave), +0.0 / −0.2 mm (Cylindrical) |
| Center Thickness Tolerance | ±0.2 mm |
| EFL Tolerance | ±2% |
| Edge Finishing | 0.2 mm × 45° chamfer |
| Coating | Uncoated (AR coating available on request) |
| Brand | ZOLIX |
|---|---|
| Origin | Beijing, China |
| Manufacturer Type | Direct Manufacturer |
| Product Category | Optical Component |
| Model | PPB Series |
| Price Range | USD 70 – 140 (per unit) |
| Compliance | ISO 10110-7 Compliant Surface Quality |
| Coating | Protected Aluminum (Internal Reflection) |
| Transmission Efficiency | ~77% (Two Internal Reflections) |
| Deviation Tolerance | ≤3 arcsec (90° Output Stability vs. Input Angle Variation) |
| Brand | ZOLIX |
|---|---|
| Model | PSA |
| Type | Precision Stepper-Driven Linear Translation Stage |
| Origin | Beijing, China |
| Manufacturer | ZOLIX (OEM/ODM Capable) |
| Drive Mechanism | Ground Ball Screw with Preloaded Linear Guide Rails |
| Standard Interface | RS232 Serial Communication |
| Compatible Controllers | SC300, MC-Series |
| Travel Range | 50–400 mm (model-dependent) |
| Lead Screw Pitch | 4 mm (PSA050–PSA200), 5 mm (PSA300–PSA400) |
| Microstepping Resolution | 2.5–3.125 µm (at 8× subdivision) |
| Max. Speed | 40–50 mm/s |
| Repeatability | <3 µm |
| Backlash | <5 µm |
| Straightness | <10 µm / 100 mm |
| Parallelism | <15 µm / 100 mm |
| End & Home Switches | Integrated Limit and Zero-Position Optical Sensors |
| Manual Override | Rear-Mounted Precision Knob |
| Mounting | Standard ISO/Metric T-Slot and Counterbored Hole Pattern (M4/M6) |
| Compliance | CE-marked per EN 61000-6-2/-6-4 |
| Brand | ZOLIX |
|---|---|
| Model | PSAG15-250 / PSAG15-370 |
| Angular Range | ±15° |
| Top Plate Dimensions | 280 × 250 mm / 340 × 250 mm |
| Center Height | 250 mm / 370 mm |
| Guide Type | Curved Arc Rail |
| Gear Ratio | 610:1 / 870:1 |
| Resolution (8-Microstep) | 0.00018° / 0.00013° |
| Stepper Motor | 1.8° step angle, 2.4 A rated current |
| Central Load Capacity | ≥50 kg |
| Origin | Beijing, China |
| Manufacturer | ZOLIX (OEM & ODM capable) |
