DRETOP JRZ-150-S3 Dry Screw & Roots Vacuum Pump System

Overview

The DRETOP JRZ-150-S3 is a two-stage oil-free vacuum pump system integrating a dry screw forepump and a high-efficiency Roots booster pump in a single compact, engineered package. It operates on the principle of positive displacement via synchronized, non-contacting helical rotors—eliminating lubricants from the gas path and ensuring contamination-free vacuum generation. Unlike traditional oil-sealed rotary vane or liquid ring pumps, this system delivers clean, dry vacuum across a wide operating range—from atmospheric pressure down to 0.5 Pa—making it suitable for applications where hydrocarbon residue, oil backstreaming, or moisture sensitivity compromises process integrity. Its design targets demanding industrial and laboratory environments including semiconductor thin-film deposition, pharmaceutical lyophilization, vacuum heat treatment, and advanced materials synthesis—where compliance with ISO Class 5–7 cleanroom requirements, USP analytical instrument qualification, and FDA 21 CFR Part 11 data integrity standards is mandatory.

Key Features

• Oil-free operation: No internal lubrication ensures zero hydrocarbon contamination—critical for optical coating, ALD/CVD processes, and high-purity material handling.
• Water-cooled thermal management: Integrated closed-loop cooling (4 L/min flow rate) maintains stable rotor temperatures below 85 °C under continuous load—reducing thermal drift and extending bearing life.
• Corrosion-resistant construction: Optional electropolished stainless steel (316L) chambers and plasma-sprayed ceramic coatings (e.g., Al₂O₃ or Cr₂O₃) enable reliable operation with acidic vapors (HCl, HF), alkaline condensates (NH₃), or aggressive solvents.
• Particle-tolerant architecture: Straight-through gas path and optimized clearance sealing minimize dust accumulation; compatible with inline particulate filters (ISO 12103-1 A2 test dust rated up to ISO Coarse Code 18/15).
• Low-vibration mechanical design: Dynamic rotor balancing per ISO 1940 G2.5 grade and multi-stage elastomeric mounting reduce transmitted vibration to <2.5 mm/s RMS—enabling integration near sensitive metrology tools or electron microscopes.
• Energy-optimized drive: Combined screw-Roots staging achieves 65–72% volumetric efficiency at 10–100 Pa; optional variable-frequency drive (VFD) enables demand-based speed control and up to 35% energy reduction versus fixed-speed operation.

Sample Compatibility & Compliance

The JRZ-150-S3 handles complex process gases—including condensable vapors (water, solvents), mildly corrosive media (CO₂, Cl₂, NH₃), and sub-micron particulates—without performance degradation. It meets ISO 21360-1:2021 for vacuum pump performance testing and conforms to CE Machinery Directive 2006/42/EC and Electromagnetic Compatibility Directive 2014/30/EU. For regulated environments, optional validation packages support IQ/OQ documentation aligned with GMP Annex 15 and EU GMP Annex 11. The system’s leak-tightness (<1 × 10⁻⁷ mbar·L/s He) and repeatability (±1.5% full-scale pumping speed) are verified per ASTM E1866-20.

Software & Data Management

Equipped with standard RS-485 Modbus RTU and optional Ethernet/IP interface, the JRZ-150-S3 supports integration into centralized SCADA or MES platforms. PLC-controlled variants include real-time monitoring of inlet pressure (capacitance manometer input), motor current, coolant temperature, and vibration amplitude—with configurable alarm thresholds and audit-trail logging compliant with FDA 21 CFR Part 11. Firmware supports time-stamped event history (≥10,000 entries), password-protected parameter access, and automatic shutdown on thermal overload or flow interruption.

Applications

• Semiconductor manufacturing: Load-lock evacuation, sputtering chamber roughing, and etch tool base-pressure stabilization.
• Pharmaceutical R&D: Freeze-drying cycle optimization, solvent recovery in API crystallization, and sterile barrier integrity testing.
• Materials science: Vacuum brazing of Ti-alloys, electron-beam melting (EBM) pre-purge, and high-temperature annealing under inert atmosphere.
• Academic laboratories: UHV pre-pumping for surface analysis systems (XPS, AES), accelerator beamline conditioning, and quantum device fabrication.
• Green technology: Lithium-ion battery electrode drying, hydrogen fuel cell component outgassing, and PV module lamination vacuum hold.

FAQ

What vacuum level can the JRZ-150-S3 achieve without a backing pump?
The JRZ-150-S3 requires a forepump (integrated in this configuration); its ultimate pressure of 0.5 Pa is only attainable when paired with the specified DS-series dry screw pump.
Is nitrogen purging available as a factory-installed option?
Yes—N₂ purge ports are standard on all JRZ models; flow control valves and pressure regulators can be pre-configured per ISO 8573-1 Class 2 purity requirements.
Can this system be validated for GxP environments?
Yes—DRETOP provides FAT/SAT protocols, calibration certificates traceable to NIST, and IQ/OQ templates compliant with ASTM E2500 and ISPE Baseline Guide Vol. 5.
What maintenance intervals are recommended for continuous 24/7 operation?
Rotor bearing replacement is scheduled every 12,000 hours; coolant filter exchange every 6 months; and ceramic coating inspection every 24 months under typical chemical exposure conditions.
Does the system support remote diagnostics via cloud connectivity?
With optional IoT gateway module (DRETOP CloudLink™), real-time health monitoring, predictive failure alerts, and firmware OTA updates are enabled—subject to customer network security policy approval.
