MOTIS FT-45 45-Degree Flammability Tester
| Origin | Shanghai, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | FT-45 |
| Pricing | Available Upon Request |
Overview
The MOTIS FT-45 45-Degree Flammability Tester is an engineered solution for quantitative assessment of surface flammability in textiles and flexible materials under standardized inclined orientation. Designed in strict conformance with the U.S. Flammable Fabrics Act (FFA) and mandated testing protocols of the U.S. Consumer Product Safety Commission (CPSC), this instrument executes the 45-degree angle ignition test — a critical regulatory requirement for apparel, children’s sleepwear, toys, upholstered furniture fabrics, and healthcare textiles. The test principle relies on controlled application of a calibrated open flame at a precise 45° incline to a horizontally clamped specimen; subsequent measurement of flame spread distance over time yields the burn rate (in inches per minute or mm/s), which directly informs compliance classification per CFR 1610, ASTM D1230, NFPA 702, CA TB117, and BIFMA X5.1.
Key Features
- Robust stainless-steel test chamber with integrated tempered glass observation window for real-time visual monitoring and operator safety
- Standardized 26-gauge needle burner assembly with fine-adjustable flame height (typically 3/4″ ± 1/8″ as specified in CFR 1610)
- High-precision digital timer with 0.1-second resolution and automatic start/stop triggering upon flame contact and extinction
- Programmable ignition delay (pre-ignition dwell time) to accommodate material-specific conditioning requirements
- Dedicated brushing apparatus compliant with CFR 1610 Section 3.2 for standardized surface fiber orientation prior to testing
- Interchangeable sample holders—including CPSC-compliant rectangular frame (150 mm × 50 mm), TB117-specific multi-position clamp, and ASTM D1230 dual-specimen fixture—to ensure cross-standard adaptability
- Included stainless-steel specimen clips and certified flame calibration template for traceable burner alignment and thermal output verification
Sample Compatibility & Compliance
The FT-45 accommodates flat, flexible specimens up to 150 mm in length and 50 mm in width, including woven/knitted fabrics, nonwovens, laminated composites, and coated textiles. It supports pre-conditioning per ASTM D1776 (standard atmospheric conditioning at 21°C ± 1°C and 65% ± 2% RH). All operational parameters align with Good Laboratory Practice (GLP) documentation requirements and are compatible with audit-ready data capture for FDA-regulated environments. Test reports generated meet evidentiary thresholds for CPSC submission and are structured to satisfy ISO/IEC 17025 accreditation criteria for testing laboratories.
Software & Data Management
While the FT-45 operates as a stand-alone electromechanical tester, its timing and ignition control architecture supports integration with external PC-based data acquisition systems via TTL-level trigger I/O ports. Optional firmware upgrade enables USB-serial logging of timestamped ignition events, burn duration, and manual pass/fail annotations. All recorded data comply with 21 CFR Part 11 principles when used in conjunction with validated third-party LIMS platforms—supporting electronic signatures, audit trails, and secure user access controls. Calibration logs, maintenance records, and operator training documentation are maintained in accordance with CPSC guidance documents and internal quality management systems.
Applications
- Regulatory screening of children’s sleepwear and daywear per 16 CFR Part 1615/1616
- Pre-market validation of upholstery fabrics for residential and commercial furniture under CA TB117-2013 and TB117-2020
- Quality assurance testing of hospital gowns, drapes, and bedding per NFPA 702 and ASTM F2895
- Supplier qualification for toy manufacturers requiring ASTM F963-23 Section 4.10 compliance
- R&D evaluation of flame-retardant finishes, intumescent coatings, and inherently flame-resistant fibers (e.g., modacrylic, aramid, polybenzimidazole)
- Failure analysis and root-cause investigation of non-conforming lots during production audits
FAQ
What standards does the FT-45 directly support out-of-the-box?
CFR 1610 (U.S. apparel), ASTM D1230 (apparel & accessories), NFPA 702 (healthcare textiles), CA TB117 (upholstery), and BIFMA X5.1 (office furniture).
Is flame calibration required before each test series?
Yes—per CPSC guidelines, burner flame height and geometry must be verified using the included calibration template prior to every test session or shift.
Can the FT-45 be used for vertical flame testing (e.g., ASTM D6413)?
No—the FT-45 is purpose-built for 45-degree inclination only; vertical flame testing requires a dedicated ASTM D6413-compliant apparatus.
Does the system include software for automated report generation?
The base unit does not include embedded reporting software, but timing outputs are compatible with Excel-based templates and validated LIMS integrations.
What maintenance intervals are recommended for long-term accuracy?
Monthly visual inspection of burner tip integrity, quarterly verification of timer calibration against NIST-traceable stopwatch, and annual full functional verification per manufacturer’s service protocol.
