| Brand | JULABO-Chemtron |
|---|---|
| Origin | Germany |
| Generation Principle | Vacuum-driven Hollow-Fiber Membrane Separation |
| Nitrogen Flow Rate | 10–120 L/min |
| Nitrogen Purity | 98–99.9% |
| Nitrogen Dew Point | < −40 °C |
| Output Pressure | 7 bar (100 psi) |
| Air Flow (Dual Outputs) | up to 70 L/min @ 7 bar & 25 L/min @ 4 bar |
| Inlet Pressure | 8.5–10 bar |
| Pressure Drop | ≤1.5 bar |
| Particle Filtration | ISO 8573-1:2010 Class 1.2.1 |
| Operating Temperature | 15–35 °C |
| Certifications | CE, FCC, CSA, Factory-IQ/OQ Documentation Available |
| Brand | JULABO-Chemtron |
|---|---|
| Origin | Germany |
| Model | MISTRAL EVO HYBRID |
| Nitrogen Flow Rate | up to 12 L/min at 80 psi |
| Source Air Flow | up to 25 L/min at 100 psi |
| Exhaust Air Flow | up to 10 L/min at 80 psi |
| Nitrogen Purity | >98% |
| Dew Point | −40 °C |
| Operating Temperature | 15–40 °C |
| Power Supply | 110 V / 60 Hz or 230 V / 50 Hz |
| Power Consumption | 1800 W |
| Pressure Stability | ±0.5% (0.1 bar) |
| Display | 128×64 px graphical LCD |
| Noise Level | 55 dB(A) |
| Weight | 90 kg |
| Dimensions (L×W×H) | 482×835×641 mm |
| Certifications | CE, MET, FCC |
| Protection Class | IP2X |
| Output Interface | Quick-connect fitting for 6 mm OD tubing |
