| Brand | Autoscience |
|---|---|
| Origin | Tianjin, China |
| Model | ATP-3200 |
| Flow Rate Range | 0.21–2060 mL/min (dependent on tubing size) |
| Speed Range | 1–460 rpm |
| Speed Resolution | 0.1 rpm |
| Speed Stability | ≤ ±0.3 rpm |
| Max Pressure | 1.5 kg/cm² |
| Max Fluid Viscosity | 2000 cP |
| Operating Temperature | –10–100 °C (fluid), 0–50 °C (ambient) |
| Humidity | <80% RH |
| Dimensions (W×H×D) | 120 × 230 × 270 mm |
| Power Supply | 220 ±15% V, 50 Hz |
| Power Consumption | 150 W |
| Net Weight | 5.5 kg |
| Direction Control | Forward/Reverse |
| Tubing Compatibility | #14, #17, #18, #25 (Pharmed®/Norprene®-compatible) |
| Brand | Autosense |
|---|---|
| Model | ATP-3200 |
| Flow Rate Range | 0.25–2060 mL/min (dependent on tubing size) |
| Speed Range | 1–460 rpm, continuously adjustable |
| Speed Resolution | 0.1 rpm |
| Speed Stability | ≤ ±0.3 rpm |
| Tubing Compatibility | 14#, 16#, 25#, 17#, 18# (Pharmed®/Norprene®-equivalent silicone or thermoplastic elastomer tubing) |
| Max Fluid Pressure | 1.5 kg/cm² (≈147 kPa) |
| Operating Temperature | –10°C to 100°C (fluid), 0°C to 50°C (ambient) |
| Relative Humidity | <80% RH |
| Power Supply | 220 V ±15%, 50/60 Hz |
| Power Consumption | 150 W |
| Dimensions (W×H×D) | 120 × 230 × 270 mm |
| Net Weight | 5.5 kg |
| Direction Control | Forward/Reverse |
| Display | 4-digit LED, showing speed and flow (for three standard tubing sizes) |
| External Interface | TTL/RS-232-compatible control port for programmable automation |
| Compliance | Designed for GLP-compliant lab environments |
