| Brand | TCT (Xiamen Tongchuang) |
|---|---|
| Origin | Fujian, China |
| Model | CSSE1000 |
| Reaction Pressure | Atmospheric (optional backpressure up to 0.5 MPa) |
| Reaction Temperature Range | Ambient to 1100 °C |
| Catalyst Bed Dimensions | 25 mm ID × 40 mm L |
| Gas Flow Control Range | 5 sccm – 30 SLPM |
| Temperature Control Accuracy | ±0.5 °C (heating zones & evaporator) |
| Gas Species Analyzed | CO, CO₂, CH₄, C₆H₁₄, C₃H₈, NO, NOₓ, O₂, NH₃, H₂O (optional), NO₂ (optional), SO₂ (optional) |
| Space Velocity Range | 3,000 – 50,000 h⁻¹ |
| Gas Mixing | Integrated turbulent-mixing chamber with flow conditioning baffle |
| Materials | 316L stainless steel tubing with VCR/SS-400 fittings |
| Condensate Management | Integrated inline condenser with phase separation prior to analyzer inlet |
| Liquid Dosing | Dual-plunger micropump or precision syringe pump (0.1–1000 mL/h) for controlled humidification |
| Compliance | Designed for GLP-compliant catalyst screening per ISO 21365, ASTM D7214, and SAE J1829 test protocols |
