| Brand | AGC |
|---|---|
| Origin | Ireland |
| Model | NovaSTREAM 6000 |
| Detection Principle | Flame Ionization Detection (FID) |
| Measurement Range | 0–20,000 ppm C₁–C₁₀ (as methane or propane equivalent) |
| Minimum Detectable Level | <10 ppb |
| Linearity Error | ≤±1% F.S. |
| Repeatability | ±30 ppb |
| Span Drift | ±30 ppb (24 h) |
| Response Time (T₉₀) | ≤30 s |
| Operating Temperature | 10–40 °C |
| Display | 6.5-inch TFT LCD touchscreen |
| Data Storage | 10,000 measurement records |
| Communication Interface | RS232 |
| Dimensions (W×H×D) | 483 mm × 450 mm × 400 mm (19″ rack-mount compatible) |
| Alarm Outputs | Dry-contact relays for high/low concentration, system fault, sample gas interruption, zero/span gas loss, and flame-out detection |
| Built-in Diagnostics | 20 standardized fault codes |
| Auto-Calibration | Motorized solenoid valves for automated zero/span calibration cycles |
| Flow Control | Integrated electronic mass flow controllers (MFCs) for sample, hydrogen, air, and zero/span gases |
| Brand | AGC |
|---|---|
| Origin | Ireland |
| Model | NovaSTREAM 6000 |
| Linear Error | ≤±1% F.S. |
| Repeatability | ≤±1% F.S. |
| Drift | ≤±1% F.S./6 months |
| Response Time | ≤5 s (T90) |
| Detection Limit | <10 ppb |
| Power Consumption | <100 W |
| Minimum Inlet Pressure | 10 kPa |
| Display | 6.5-inch color LCD touchscreen |
| Output Interfaces | 2 × 4–20 mA, 1 × mV, VGA, USB, Ethernet, RS-232, RS-485 |
| Data Storage | Up to 24 months internally |
| Calibration | Automated with audit-trail logging |
