| Brand | BCC |
|---|---|
| Origin | Hebei, China |
| Model | MGA-6000 |
| Sensor Type | Paramagnetic |
| Measurement Range | 80/98–99.99% O₂ (user-selectable span) |
| Accuracy | ±0.1% FS |
| Repeatability | ±0.01% FS |
| Resolution | 0.01% O₂ |
| Response Time | T₉₀ ≤ 15 s |
| Sample Flow Rate | 400 ± 50 mL/min |
| Operating Temperature | –15 °C to +45 °C |
| Relative Humidity | ≤ 90% RH (non-condensing) |
| Data Storage | Scheduled automatic logging |
| Output Interfaces | 4–20 mA analog, RS232 / RS485 serial, USB, Ethernet (TCP/IP) |
| Brand | BCC |
|---|---|
| Model | MGA-6000 |
| Measurement Principle | Tunable Diode Laser Absorption Spectroscopy (TDLAS) |
| Target Gases | Formaldehyde (HCHO), Formic Acid (HCOOH) |
| Accuracy | ≤ ±1% FS |
| Repeatability | ≤ 1% FS |
| Zero/ Span Drift | ≤ ±1% FS / 24 h |
| Response Time (T90) | ≤ 20 s |
| Detection Limit | 1 ppb – 1 ppm (gas-dependent) |
| Measurement Ranges | 0–1, 0–10, 0–50, 0–100, 0–500, 0–1000 ppm, up to 100% vol (customizable) |
| Enclosure Options | 19" rack-mount, benchtop, portable |
| Output Interfaces | 4–20 mA, RS232 / RS485, USB, Ethernet (TCP/IP) |
| Brand | BCC |
|---|---|
| Origin | Hebei, China |
| Model | MGA-3000 |
| Sensor Type | Paramagnetic |
| O₂ Range | 0–100% vol |
| O₂ Resolution | 0.01% vol |
| O₂ Accuracy | ±1% FS |
| CO Range | 0–10 ppm |
| CO Resolution | 0.01 ppm |
| CO Accuracy | ±2% FS |
| CO₂ Range | 0–500 ppm |
| CO₂ Resolution | 0.1 ppm |
| CO₂ Accuracy | ±2% FS |
| Dew Point Temperature Range | −50 to +100 °C |
| Dew Point Resolution | 0.1 °C |
| Dew Point Accuracy | ±0.5 °C |
| Barometric Pressure Range | 50–110 kPa |
| Pressure Resolution | 0.01 kPa |
| Pressure Accuracy | ±0.5 kPa |
| Zero Drift | ≤2% FS |
| Span Drift | ≤±2% FS |
| Data Storage | Scheduled auto-storage |
| Analog Output | 4–20 mA |
| Digital Interfaces | RS232 / RS485 / USB / Ethernet |
| Brand | BCC |
|---|---|
| Origin | Hebei, China |
| Manufacturer Type | Authorized Distributor |
| Product Origin | Domestic (China) |
| Model | MGA-6000 |
| Linearity Error | ≤±2% FS |
| Repeatability | ≤1% |
| Zero/ Span Drift | ≤±1% FS / 24 h |
| Response Time (T₉₀) | ≤20 s |
| Measurement Range | 0–50 ppm (extendable to 0–100 ppm) |
| Resolution | 0.1 ppm |
| Output Interfaces | 4–20 mA, RS232 / RS485, USB, Ethernet |
| Brand | BCC |
|---|---|
| Origin | Hebei, China |
| Model | MGA-6000 |
| Sensor Type | Tunable Diode Laser Absorption Spectroscopy (TDLAS) |
| Measurement Range | 0–3000 ppb |
| Accuracy | ±0.1% FS |
| Response Time | 1–60 s |
| Repeatability | ≤ ±0.5% |
| Resolution | 1 ppb |
| Detection Limit (LDL) | 10 ppb |
| Drift | ≤ ±1% / 24 h |
| Output Interfaces | 4–20 mA, RS232/RS485, USB, Ethernet, 4G, 5G |
| Enclosure | 19″ rack-mountable & desktop form factor |
| Data Storage | Industrial-grade SSD with ≥5 years local data retention |
| Brand | BCC |
|---|---|
| Origin | Hebei, China |
| Model | MGA-6000 |
| Sensor Type | Tunable Diode Laser (TDLAS) |
| Measurement Range | 80/98–99.99% O₂ (user-selectable sub-ranges) |
| Accuracy | ±0.1% FS |
| Repeatability | ±0.01% FS |
| Stability | ±0.02% FS |
| Response Time | T₉₀ ≤ 15 s |
| Resolution | 0.01% O₂ |
| Sample Flow Rate | 400 ± 50 mL/min |
| Operating Temperature | −15 °C to +45 °C |
| Relative Humidity | ≤90% RH (non-condensing) |
| Output Interfaces | 4–20 mA analog, RS232 / RS485 serial, USB, Ethernet (TCP/IP) |
| Brand | BCC |
|---|---|
| Model | MGA-6000 |
| Measurement Principle | Tunable Diode Laser Absorption Spectroscopy (TDLAS) |
| Target Gases | Acetylene (C₂H₂) and Ethylene (C₂H₄) |
| Linearity Error | ≤ ±1% FS |
| Repeatability | ≤ 1% FS |
| Drift | ≤ ±1% FS/24 h |
| Response Time (T90) | ≤ 20 s |
| Detection Limit | 1 ppb – 1 ppm |
| Range Options | 0–1, 0–10, 0–50, 0–100, 0–500, 0–1000 ppm up to 100% vol (customizable) |
| Enclosure Types | 19″ rack-mount, benchtop, portable |
| Output Interfaces | 4–20 mA, RS232/RS485, USB, Ethernet |
