Showing all 4 results
| Brand | Xplore |
|---|---|
| Origin | Netherlands |
| Model | IM12 |
| Maximum Shot Volume | 12 mL |
| Mold Cavity Capacity | Up to 12 mL (geometry-dependent) |
| Split Mold Design | Heatable/Coolable |
| Max Barrel Temperature | 450 °C |
| Max Mold Temperature | 300 °C |
| Cooling Integration | Compatible with External Coolants |
| Max Injection Force | 12 kN @ 10 bar (1200 bar system pressure), 18 kN @ 16 bar (1800 bar system pressure) |
| Nozzle Heating Time (20 → 240 °C) | < 8 min |
| Power Supply | 208–240 V AC, Custom Voltages Available |
| Data Interface | USB for Real-Time Process Logging |
| Brand | Xplore |
|---|---|
| Origin | Netherlands |
| Model | MC 15 HT |
| Batch Capacity | 15 mL (3–7 mL optional via Vari-Batch™) |
| Max Torque | 40 Nm (full speed range 1–500 rpm) |
| Max Temp | 450 °C |
| Temp Control | 8 heating zones, 7 thermocouples, melt thermocouple feedback |
| Torque & Rheological Data Acquisition | melt torque, shear viscosity, shear rate, shear stress |
| Max Pressure | 250 bar |
| Cooling Time (240→80 °C) | <10 min (water-cooled) |
| Weight | 145 kg |
| Dimensions (H×W×D) | 95×50×27 cm |
| Drive Power | 1350 W |
| Electrical Supply | 400 V / 50–60 Hz, 3-phase 5-wire, 16 A (or 210 V option) |
| Screw Hardness | 54 HRC, coating 1000 HV |
| Barrel Hardness | 64 HRC, coating 2000 HV |
| Chemical Resistance | pH 0–14 |
| Data Export | Excel (.xlsx) |
| Brand | Xplore |
|---|---|
| Origin | Netherlands |
| Model | MC 40 |
| Max Torque | 40 Nm (1–500 rpm) |
| Batch Capacity | 40 mL |
| Max Temperature | 425 °C |
| Heating Time (80 → 240 °C) | <15 min |
| Cooling Time (240 → 80 °C) | <10 min (water-cooled) |
| Screw Speed | 1–500 rpm |
| Max Melt Pressure | 250 bar |
| Barrel Material | DIN 1.4112 steel, 54 HRC, 2000 HV coating |
| Screw Coating | 1000 HV |
| Heating Zones | 7 thermocouples + 12 heater cartridges |
| Drive Power | 1350 W |
| Dimensions (H×W×D) | 95 × 50 × 27 cm |
| Weight | 150 kg |
| Control Interface | Integrated touchscreen or USB-connected PC software (Excel-exportable data) |
| Brand | Xplore |
|---|---|
| Origin | Netherlands |
| Model | XM-12 |
| Max Shot Volume | 12 mL |
| Max Operating Temperature | 400 °C |
| Heating Zones | 2 |
| Max Injection Force | 18,000 N |
| Nozzle Heat-up Time (2–240 °C) | < 8 min |
| Dimensions (W×D×H) | 84 × 33 × 32 cm |
| Weight | 50 kg |
| Mold Temperature Control Range | Below ambient to 400 °C |
| Power Supply | 208–240 V AC |
