Agilent 8860-5977B Gas Chromatography Mass Spectrometry System (Refurbished)

Overview

The Agilent 8860-5977B Gas Chromatography Mass Spectrometry (GC-MS) system is a fully refurbished, factory-tested benchtop analytical platform engineered for high-throughput routine analysis in environmental, pharmaceutical, food safety, and forensic laboratories. This integrated configuration combines the robustness of the Agilent 8860 GC — built on the proven 7890-series architecture — with the enhanced sensitivity and reliability of the 5977B Single Quadrupole Mass Selective Detector (MSD). The system operates on electron ionization (EI) and optional chemical ionization (CI) modes, delivering quantitative and qualitative analysis across volatile and semi-volatile organic compounds. Its core measurement principle relies on gas-phase separation via capillary column chromatography followed by mass-selective detection using a quadrupole mass analyzer with unit-mass resolution. All components undergo full functional validation at SpectraLab Scientific’s ISO/IEC 17025-accredited refurbishment facility, including leak testing, tuning verification (using perfluorotributylamine, PFTBA), and performance qualification against ASTM D5845 and EPA Method 8270D criteria.

Key Features

• Agilent 8860 GC platform with dual inlet capability (split/splitless, PTV, or Cool-on-Column), three-valve support, and up to three detector outputs — optimized for method flexibility and system expandability
• Agilent 5977B MSD featuring High Efficiency Source (HES) technology, achieving 10× higher signal-to-noise ratio versus prior-generation single quadrupole systems; IDL (Instrument Detection Limit) verified at ≤1.5 fg for chlorobenzene (EPA 8270D)
• Agilent 7693A Automatic Liquid Sampler with 150-position tray, enabling unattended operation and reproducible injection volumes from 0.1–100 µL
• G2591C Extractor Ion Source — inert, easily removable, and compatible with both EI and CI modes; designed for rapid cleaning and minimal downtime
• IDP-3 Dry Scroll Vacuum Pump — oil-free, low-vibration, silent operation (<45 dB(A)), eliminating solvent backstreaming and reducing maintenance intervals
• Integrated MassHunter Data Acquisition and Analysis Software (v10.x or later), supporting method development, spectral library searching (NIST, Wiley), quantitation (SIM/MRM), and report generation compliant with 21 CFR Part 11 audit trail requirements

Sample Compatibility & Compliance

The 8860-5977B system supports a broad range of sample matrices following standard derivatization or extraction protocols (e.g., SPE, LLE, SPME). It is routinely applied to regulated analyses under EPA Methods 502.2, 524.4, 8260D, 8270D, and 8321B; ISO 17025-compliant laboratories utilize this configuration for pesticide residue screening (EN 15662), PAH profiling (ISO 18856), and VOC monitoring in drinking water (ISO 22067-1). All refurbished units include full documentation of calibration history, system suitability test (SST) records, and traceable certification to NIST-traceable standards. The hardware and software architecture supports GLP/GMP workflows, including electronic signatures, user access controls, and secure data archiving.

Software & Data Management

MassHunter Workstation software provides end-to-end control — from instrument setup and acquisition through processing, reporting, and data export. Key modules include MassHunter Quantitative Analysis (for calibration curve fitting, internal standard correction, and compliance reporting), MassHunter Qualitative Analysis (with deconvolution, spectral matching, and unknown identification), and MassHunter Acquisition (supporting scheduled runs, auto-tuning, and real-time diagnostics). Data files are stored in .D format, fully compatible with Agilent OpenLab CDS and third-party LIMS integrations. Audit trails record all user actions, parameter changes, and data modifications in accordance with FDA 21 CFR Part 11 requirements. Remote monitoring and method editing are enabled via Agilent’s WebControl interface over secure LAN/WAN connections.

Applications

This GC-MS system is validated for use in multiple regulatory and research domains: residual solvent analysis in APIs (ICH Q3C); environmental contaminant screening (PCBs, phthalates, flame retardants); food adulterant detection (melamine, mycotoxins, pesticides); forensic toxicology (drugs of abuse, volatiles in blood); and polymer additive migration studies (antioxidants, plasticizers). Its HES-enhanced sensitivity allows reduced sample volumes (down to 1 µL injections), minimizing reagent consumption and waste generation — aligning with green analytical chemistry principles outlined in ISO 14040 and ASTM E2964-14.

FAQ

Is this a factory-refurbished unit or third-party refurbished?
All instruments are refurbished and certified by SpectraLab Scientific’s in-house engineering team using original Agilent spare parts and diagnostic firmware. Each unit undergoes full functional testing per Agilent’s Service Manual Rev. D.
What warranty is included?
A comprehensive 90-day limited hardware warranty covers all GC, MSD, autosampler, and vacuum components. Extended service plans (1–3 years) with priority response and preventive maintenance are available upon request.
Are original Agilent consumables and accessories included?
Yes — each system ships with one set of G2591C ion source components, one GC column (DB-5ms, 30 m × 0.25 mm × 0.25 µm), and a complete toolkit. Additional consumables (inlet liners, septa, gold seals) are available separately.
Can this system be integrated into an existing LIMS environment?
Yes — MassHunter supports ODBC-compliant database exports and HL7/SOAP-based API integration. Agilent CrossLab Connect enables automated instrument status reporting and remote diagnostics.
Do you provide installation and training?
On-site or virtual commissioning, IQ/OQ documentation support, and two-day operator training (including method transfer and troubleshooting) are included in the standard delivery package.
