Bruker 456 Gas Chromatograph with CP-8400 Auto Sampler
| Brand | Bruker |
|---|---|
| Origin | Canada |
| Manufacturer Type | Authorized Distributor |
| Origin Category | Imported Instrument |
| Model | 456 |
| Product Category | Chromatography |
| Operational Age | 4–5 years |
| Warranty Period | 6 months |
| Included Automation | CP-8400 Autosampler |
Overview
The Bruker 456 Gas Chromatograph is a high-performance, benchtop analytical system engineered for robust separation, identification, and quantification of volatile and semi-volatile organic compounds. Built upon proven capillary GC architecture, the instrument employs temperature-programmed oven control, precision pressure/flow regulation, and a thermally stable detector interface to ensure consistent retention time reproducibility and peak resolution. Designed and manufactured in Canada under Bruker’s quality management system, this refurbished unit retains full mechanical and electronic integrity—verified through comprehensive functional validation including baseline stability assessment, retention time repeatability (RSD < 0.15% over 10 injections), and detector linearity verification across five concentration levels. The integrated CP-8400 autosampler enables unattended operation with precise 1–100 µL injection volume control, programmable vial tray temperature management (4–40 °C), and dual syringe capability for sample and internal standard introduction.
Key Features
- Refurbished and fully validated Bruker 456 GC platform meeting original OEM specifications for column oven temperature range (–20 °C to 450 °C), ramp rate (0.1–120 °C/min), and thermal stability (±0.01 °C)
- CP-8400 autosampler with 108-position vial capacity, wash station with dual solvent capability, and automated syringe calibration routine
- Modular detector compatibility—including FID, TCD, and ECD configurations—retaining native signal-to-noise ratios and linear dynamic ranges per Bruker documentation
- Embedded firmware version 3.2.x supporting method transfer from legacy Bruker GC systems and backward-compatible data file formats (.raw, .cdf)
- Structural refurbishment includes replacement of critical wear components: septum purge solenoids, column nut seals, detector jet assemblies, and oven insulation panels
- Calibration traceability documented against NIST-traceable standards; full validation report available upon request
Sample Compatibility & Compliance
The Bruker 456 GC–CP-8400 configuration supports analysis of environmental samples (EPA Method 8260C, 8270D), petrochemical fractions (ASTM D3606, D5186), pharmaceutical residual solvents (ICH Q3C), and food flavor volatiles (AOAC 994.11). All refurbished units undergo compliance verification per ISO/IEC 17025:2017 requirements for testing laboratories, including documented evidence of system suitability testing (SST) per USP and EU Ph. Eur. 2.2.46. Data acquisition and processing workflows are compatible with 21 CFR Part 11–compliant software environments when paired with validated third-party chromatography data systems (CDS). Instrument logs retain audit trail functionality for injection sequence, method parameters, and detector response metadata.
Software & Data Management
The system operates natively with Bruker’s Compass GC 2.0 software suite (licensed and pre-installed), enabling method development, sequence definition, real-time monitoring, and report generation. Raw data files adhere to ANDI/NetCDF format standards, ensuring interoperability with OpenLab CDS, Chromeleon, and Empower platforms. All refurbished instruments include encrypted backup of factory-default firmware, diagnostic utilities, and service history logs. SpectraLab Scientific provides post-delivery remote support for CDS integration, user access control setup, and electronic signature implementation aligned with GLP/GMP documentation practices.
Applications
- Environmental monitoring: BTEX, PAHs, chlorinated hydrocarbons, and pesticide residues in water, soil, and air matrices
- Petrochemical QA/QC: Hydrocarbon type analysis (HTA), gasoline oxygenates (MTBE, ETBE), and sulfur compound profiling
- Pharmaceutical manufacturing: Residual solvent testing in APIs and excipients per ICH guidelines
- Food & beverage safety: Flavor compound profiling, adulterant detection (e.g., olive oil authenticity), and packaging migration studies
- Forensic toxicology: Volatile substance screening in blood and tissue homogenates
FAQ
Is this instrument covered by Bruker’s original manufacturer warranty?
No—the unit is sold under a 6-month limited warranty provided by SpectraLab Scientific, covering defects in materials and workmanship. Original Bruker warranty expired upon initial sale; however, full service history and refurbishment documentation are supplied.
Can the system be configured with a mass spectrometer?
Yes—the Bruker 456 GC features standard GC-MS interface hardware (electron ionization source port, vacuum manifold, and transfer line heater); compatibility with Bruker Scion SQ or third-party MS detectors requires additional interface alignment and firmware update verification.
What documentation accompanies the instrument?
Each unit ships with a Certificate of Refurbishment, System Validation Report (including SST results), firmware version log, electrical safety test record, and complete set of operational manuals in English.
Is on-site installation and qualification support available?
Yes—SpectraLab Scientific offers optional IQ/OQ protocol execution, including site preparation review, utility verification, and documented performance testing aligned with ASTM E2656 and ISO 17025 Annex A.2 requirements.
