CAM2 Software by FARO
| Brand | FARO |
|---|---|
| Origin | USA |
| Manufacturer Type | Authorized Distributor |
| Product Category | Imported |
| Model | CAM2 |
| Pricing | Contact for Quote |
Overview
CAM2 is a comprehensive metrology software platform developed by FARO Technologies, Inc., engineered for precision 3D measurement, inspection, and quality control in industrial manufacturing, aerospace, automotive, and heavy machinery applications. Built on a modular architecture, CAM2 integrates seamlessly with FARO’s family of portable coordinate measuring machines (CMMs), including laser trackers, articulating arms, and 3D scanners. The software employs advanced point cloud registration algorithms, iterative closest point (ICP) alignment, and GD&T (Geometric Dimensioning and Tolerancing) evaluation engines compliant with ASME Y14.5 and ISO 1101 standards. Unlike generic CAD viewers or basic reporting tools, CAM2 delivers full metrology-grade analysis — enabling users to perform first-article inspection (FAI), production part approval process (PPAP) reporting, deviation mapping, and statistical process control (SPC) directly from raw 3D measurement data.
Key Features
- Fully integrated GD&T evaluation engine supporting position, profile, orientation, form, and runout tolerances per ASME Y14.5–2018 and ISO 1101:2017
- Multi-sensor data fusion: aligns and correlates point clouds from laser trackers, articulated arms, and structured-light scanners within a unified coordinate system
- Automated report generation with customizable templates compliant with AIAG PPAP Level 3 requirements
- Real-time deviation color-mapping against nominal CAD models (STEP, IGES, Parasolid, CATIA V5/V6, NX, SolidWorks)
- Robust mesh processing tools including noise filtering, hole filling, curvature analysis, and surface simplification
- Scripting support via Python API for automated workflows, batch inspection routines, and integration with MES/PLM systems
- Role-based user permissions and audit trail logging aligned with ISO 9001 and IATF 16949 documentation requirements
Sample Compatibility & Compliance
CAM2 supports native import of industry-standard CAD formats and measurement data files, including FARO proprietary .faro, .fws, and .fls formats, as well as universal formats such as STL, OBJ, PLY, and ASCII/CSV point clouds. It is validated for use with FARO Laser Tracker iON, QuantumS, and FocusS series; FARO Arm Quantum and Platinum series; and FARO ScanPlan and Freestyle 3D scanners. The software complies with NIST-traceable calibration protocols and maintains full traceability for measurement uncertainty budgets in accordance with ISO/IEC 17025:2017 Annex A.5. All inspection reports include embedded metadata required for FDA 21 CFR Part 11 compliance when deployed in regulated environments under controlled validation protocols.
Software & Data Management
CAM2 implements a centralized project database architecture that ensures version-controlled storage of measurement plans, CAD models, inspection routines, and historical results. Data encryption at rest (AES-256) and in transit (TLS 1.2+) meet enterprise IT security policies. Audit logs record all user actions—including feature creation, tolerance modification, report export, and user login—with timestamps and operator IDs. Optional integration with FARO WebShare Cloud enables secure remote collaboration, real-time dashboard visualization, and long-term archival of metrology datasets. For regulated industries, optional IQ/OQ/PQ validation packages are available to support GMP/GLP environments.
Applications
CAM2 is routinely deployed in high-precision manufacturing scenarios requiring dimensional verification beyond conventional CMM capabilities. Typical use cases include large-scale aircraft wing assembly alignment using laser tracker networks; turbine blade contour inspection on multi-axis machining centers; weld gap and fit-up analysis in shipbuilding; tooling validation for composite layup molds; and reverse engineering of legacy parts where original CAD is unavailable. Its ability to handle datasets exceeding 1 billion points—while maintaining sub-micron repeatability in alignment—makes it suitable for both R&D metrology labs and shop-floor quality stations operating under APQP or Six Sigma frameworks.
FAQ
Is CAM2 compatible with non-FARO hardware?
CAM2 is optimized exclusively for FARO measurement devices. While it supports import of third-party point cloud data, full functionality—including real-time tracking, dynamic alignment, and sensor-specific calibration compensation—is only available with FARO-certified hardware.
Does CAM2 support automated inspection scripting?
Yes. CAM2 includes a documented Python API (CAM2 Script) enabling custom automation of measurement sequences, GD&T evaluation loops, report generation, and data export to SQL databases or ERP systems.
Can CAM2 generate AS9102-compliant First Article Inspection reports?
Yes. Preconfigured AS9102 Form 1–3 templates are included, with fields auto-populated from measurement plans and CAD annotations. All generated reports include digital signatures, revision history, and embedded measurement uncertainty statements.
What CAD file formats does CAM2 natively support?
Native CAD import includes STEP AP203/AP214, IGES, Parasolid (.x_t/.x_b), CATIA V5/V6 (.catpart/.catproduct), Siemens NX (.prt), and SolidWorks (.sldprt/.sldasm). Neutral mesh formats (STL, OBJ, PLY) are supported for comparison-only workflows.
Is CAM2 validated for use in FDA-regulated medical device manufacturing?
CAM2 itself is not a medical device, but it can be deployed in FDA 21 CFR Part 11-compliant environments when installed on validated Windows platforms and operated under documented IQ/OQ/PQ protocols provided by FARO or authorized partners.
