ILISUN UNIMAT 050 / UNIMAT 052 Universal Testing Machines (Manual & Electromechanical)
| Origin | Germany |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Import Status | Imported |
| Model | UNIMAT 050 / UNIMAT 052 |
| Quotation | Upon Request |
| Max Force Capacity | 2 kN (UNIMAT 050), 5 kN (UNIMAT 052) |
| Force Sensor Options | 10, 20, 50, 100, 200, 500, 1,000, 2,000, and 5,000 N |
| Position Resolution | 0.01 mm |
| Crosshead Speed Range | 0.2–1,000 mm/min (±0.5% accuracy at 2 mm/min) |
| Internal Width | 50 mm (UNIMAT 050), 300 mm (UNIMAT 052) |
| Max Crosshead Travel | 720 mm (UNIMAT 050), 860 mm (UNIMAT 052) |
| Power Supply | 230 V, 50/60 Hz |
| Dimensions (L×W×H) | 1020×310×310 mm (050M), 1020×310×390 mm (050S/SV), 1145×495×350 mm (052S/SV) |
| Weight | Approx. 20 kg |
Overview
The ILISUN UNIMAT 050 and UNIMAT 052 are precision-engineered universal testing machines designed for static mechanical characterization of materials in research laboratories, quality control environments, and industrial R&D settings. Based on a robust electromechanical or manual drive architecture, these systems implement uniaxial tensile, compression, bending, peel, and shear testing principles in accordance with standardized test methods including ISO 6892-1, ASTM E8/E9, ISO 178, and ISO 1133. The UNIMAT platform integrates modular force transduction, high-resolution position sensing, and programmable crosshead motion to deliver repeatable, traceable mechanical data across diverse specimen geometries and material classes — from polymers and elastomers to thin metallic foils, composites, and biomedical specimens.
Key Features
- Modular force measurement architecture supporting interchangeable load cells with nominal capacities from 10 N to 5,000 N — calibrated per ISO 376 Class 0.5 or better.
- High-precision position detection with 0.01 mm resolution, enabled by optical encoder feedback and displayed via the PHYSIMETER 906MC digital readout unit (8-digit LCD, real-time dual-channel display of force and displacement).
- Electromechanical variants (UNIMAT 050S/052S and SV series) feature brushless DC motors with closed-loop speed control, achieving ±0.5% speed accuracy across the full range of 0.2–1,000 mm/min — critical for strain-rate-sensitive materials such as thermoplastics and hydrogels.
- Manually operated UNIMAT 050M/050MS models provide tactile control and zero electrical dependency, ideal for teaching labs or environments requiring intrinsic safety.
- Adjustable internal width (50 mm for UNIMAT 050; 300 mm for UNIMAT 052) and extended crosshead travel (up to 860 mm) accommodate both miniature coupons and elongated specimens without reconfiguration.
- All units comply with CE marking requirements under the Machinery Directive 2006/42/EC and Low Voltage Directive 2014/35/EU; optional configurations meet IEC 61000-6-2/6-4 EMC immunity and emission standards.
Sample Compatibility & Compliance
The UNIMAT series accommodates a broad spectrum of specimen types through standardized and custom夹具 (fixtures), including tensile grips, compression platens, three/four-point bending fixtures, peel adhesion jaws, and puncture probes. Specimen thicknesses from 0.1 mm to 25 mm and widths up to 300 mm (UNIMAT 052) are supported. Systems are routinely deployed in GLP-compliant laboratories performing ASTM D638, ISO 527, ISO 179, and USP mechanical testing. When equipped with audit-trail-enabled firmware and PHYSIMETER 906MC logging, the platform supports 21 CFR Part 11 compliance for electronic records and signatures in regulated pharmaceutical and medical device manufacturing.
Software & Data Management
While the base configuration operates via PHYSIMETER 906MC hardware interface, optional PC-based software packages (e.g., ILISUN TestControl Suite v4.x) enable automated test sequencing, real-time curve plotting (stress–strain, load–displacement), statistical post-processing (modulus, yield point, elongation at break), and export to CSV, XML, or PDF formats. All raw data files include embedded metadata: operator ID, timestamp, environmental conditions (if connected to optional temperature/humidity sensor), calibration certificate ID, and instrument serial number — ensuring full traceability for ISO/IEC 17025 accreditation audits.
Applications
- Mechanical property validation of polymer films, packaging laminates, and adhesive tapes in packaging R&D.
- Tensile strength and elongation testing of surgical sutures, wound dressings, and hydrogel-based biomaterials per ISO 10993-12.
- Compression testing of foam cushions, gaskets, and soft elastomeric components in automotive and consumer electronics.
- Bending stiffness evaluation of printed circuit board substrates and flexible PCBs per IPC-TM-650 2.4.1.
- Quality assurance of metal foils, thin wires, and micro-springs in precision engineering supply chains.
FAQ
What is the difference between UNIMAT 050 and UNIMAT 052?
The UNIMAT 050 is optimized for small-scale, high-precision testing with a 50 mm internal width and 720 mm crosshead travel; the UNIMAT 052 features an expanded 300 mm internal width and 860 mm travel for larger or irregularly shaped specimens.
Can the system be upgraded from manual to electromechanical operation?
No — UNIMAT 050M/050MS and UNIMAT 050S/052S/SV are distinct mechanical platforms; retrofitting is not supported due to fundamental differences in frame rigidity, drive train integration, and control electronics.
Is calibration certification included with shipment?
Yes — each delivered system includes a factory calibration certificate traceable to national standards (DKD/DAkkS-accredited lab), covering force (at three points across the selected load cell range) and position (at five equidistant points within travel range).
Does the PHYSIMETER 906MC support data export to LIMS?
Via RS-232 or USB-to-serial interface, the 906MC supports ASCII-based data streaming compatible with most laboratory information management systems when configured with appropriate middleware or script-based parsing.
Are fixtures and load cells covered under warranty?
All ILISUN-supplied force sensors and standard mechanical fixtures carry a 24-month limited warranty against material and workmanship defects; consumable grips and jaw faces are excluded unless specified otherwise in the sales agreement.
