Inframet JAT200 Mobile Multi-Sensor Boresighting Test System
| Brand | Inframet |
|---|---|
| Origin | Poland |
| Model | JAT200 |
| Boresighting Accuracy | 50 µrad |
| Optical Collimator Aperture | 200 mm |
| Collimator Resolution | ≥150 lp/mrad |
| Projection Aperture (Thermal Imager) | ≥70 mm |
| Projection Aperture (CCD Camera) | ≥60 mm |
| Laser Receiver Aperture | ≥40 mm |
| IR Target Angular Size | 9 mrad |
| Visible Target Angular Size | 3 mrad |
| Target Contrast (Visible) | 30% |
| Operating Temperature | −25 °C to +55 °C |
| Storage Temperature | −20 °C to +71 °C |
| Relative Humidity | Up to 96% RH (non-condensing) |
| System Height Adjustment Range | 300–700 mm |
| Total System Dimensions (incl. TROL cart) | ≤1250 × 310 × 300 mm |
| Total System Weight | ≤16 kg |
| Cart Dimensions | ≤720 × 500 × 350 mm |
| Cart Weight | ≤13 kg |
Overview
The Inframet JAT200 Mobile Multi-Sensor Boresighting Test System is a field-deployable, optomechanically engineered platform designed for precise angular alignment verification and functional baseline testing of multi-sensor electro-optical (EO) systems. Based on collimated beam projection and high-fidelity target imaging principles, the JAT200 implements a calibrated boresighting methodology compliant with established military and aerospace optical alignment standards—including MIL-STD-810G (environmental testing), ISO 10110-5 (optical surface specification), and NATO AEP-47 (EO/IR sensor interoperability guidelines). Its core architecture centers on a 200 mm aperture collimator delivering parallel light with ≥150 lp/mrad resolution, enabling quantitative assessment of line-of-sight (LOS) co-alignment across heterogeneous sensor modalities—thermal imagers (MWIR/LWIR), visible-band CCD/CMOS cameras, low-light intensified imagers, short-wave infrared (SWIR) sensors, pulsed laser rangefinders (LRFs), and laser designators. The system operates without permanent facility infrastructure, making it suitable for maintenance hangars, forward operating bases, naval vessel decks, and mobile ground command posts.
Key Features
- Field-portable modular design: Total mass ≤16 kg, integrated onto a ruggedized TROL cart (≤13 kg) with height-adjustable optical axis (300–700 mm range).
- Multi-wavelength target suite: Independently characterized IR, visible, and laser-specific targets—including triple-bar resolution charts (5–30 lp/mrad), 0.4 mrad alignment squares, and thermally/visually converting laser interceptors.
- Universal sensor interface: Supports alignment verification for thermal imagers (≥70 mm entrance pupil), visible/SWIR cameras (≥60 mm), and LRF receivers (≥40 mm).
- High-precision angular metrology: Boresighting accuracy of ±50 µrad (RMS), traceable to NIST-traceable calibration artifacts and validated per ISO 17025-accredited procedures.
- Environmental resilience: Rated for operation from −25 °C to +55 °C and storage up to +71 °C; humidity tolerance up to 96% RH non-condensing—validated per IEC 60068-2-30.
- Self-contained power management: Integrated rechargeable battery pack with AC/DC input compatibility (220 VAC / DC options), supporting ≥4 hours of continuous field operation.
Sample Compatibility & Compliance
The JAT200 accommodates diverse EO payloads used in airborne, maritime, and ground-based surveillance and targeting systems. It supports co-boresighting between sensors operating across spectral bands: 0.4–0.9 µm (visible), 0.9–1.7 µm (SWIR), 3–5 µm (MWIR), and 8–12 µm (LWIR), as well as 1.06 µm and 1.55 µm laser wavelengths. All target geometries and contrast specifications conform to ASTM E1242 (infrared imaging performance), ISO 12233 (still camera resolution), and US Department of Defense Standard Practice DoD-STD-2045 for EO sensor alignment reporting. The system’s mechanical interfaces comply with STANAG 4370 (modular EO payload mounting) and facilitate rapid integration with common gimbal and turret platforms. Documentation packages include calibration certificates, uncertainty budgets, and traceability statements aligned with ISO/IEC 17025 requirements for accredited test laboratories.
Software & Data Management
The JAT200 operates via a dedicated Windows-based control application providing real-time image capture, overlay-based LOS deviation measurement, and automated report generation in PDF and CSV formats. Software features include pixel-level centroid analysis, iterative fine-alignment guidance, and delta-angle trending across sequential measurements. Audit trails record operator ID, timestamp, environmental conditions (temperature/humidity), and calibration status—supporting compliance with FDA 21 CFR Part 11 for electronic records and signatures where applicable. Exported datasets are structured for direct import into MATLAB, Python (NumPy/Pandas), or enterprise asset management (EAM) systems. Firmware updates are delivered via secure HTTPS and verified using SHA-256 checksums; no cloud connectivity is required for operational use.
Applications
- Airborne multi-sensor turret alignment verification pre-flight and post-maintenance.
- Naval EO/IR mast commissioning and periodic alignment validation under deck vibration conditions.
- Ground vehicle surveillance system certification per MIL-HDBK-338B reliability testing protocols.
- Factory acceptance testing (FAT) and site acceptance testing (SAT) of dual-band (VIS/SWIR or MWIR/LWIR) imaging payloads.
- Support of GLP-compliant optical characterization for defense prime contractors and Tier-1 subsystem integrators.
- Rapid re-alignment after shock/vibration events during transport or deployment.
- Baseline sensitivity and MTF evaluation of individual sensors prior to multi-sensor fusion integration.
FAQ
What sensor types and spectral bands does the JAT200 support?
The system supports thermal imagers (MWIR/LWIR), visible-band TV cameras, image-intensified low-light cameras, SWIR cameras, pulsed laser rangefinders (1.06 µm and 1.55 µm), and laser designators—covering 0.4–12 µm spectral range.
Is the JAT200 compliant with international calibration standards?
Yes. Calibration is performed per ISO/IEC 17025 requirements, with uncertainty budgets documented and traceable to national metrology institutes (e.g., PTB, NPL). Boresighting accuracy is validated against angular reference standards certified to ISO 10110-5 and MIL-STD-45662A.
Can the JAT200 be used in extreme environmental conditions?
It is qualified for operation at −25 °C to +55 °C and storage up to +71 °C, with humidity resistance up to 96% RH (non-condensing), tested per IEC 60068-2-30 and MIL-STD-810G Method 507.5.
Does the system require external computing hardware?
No. The JAT200 includes an embedded industrial controller with touchscreen interface; optional laptop integration is supported via USB 3.0 and GigE Vision for advanced analysis.
How is measurement traceability maintained over time?
Each unit ships with a calibration certificate, annual recalibration reminder, and onboard reference target verification routine. Recalibration services are available through Inframet’s Warsaw laboratory or authorized service centers in Europe and North America.
