ISOTECH milliK Precision Temperature Calibrator and Multifunction Thermometer

Overview

The ISOTECH milliK is a high-accuracy, multifunction precision temperature calibrator and reference thermometer engineered for primary and secondary calibration laboratories, national metrology institutes, and industrial quality assurance departments. It operates on the fundamental principles of thermoelectric voltage measurement (for thermocouples), resistance ratio comparison (for platinum resistance thermometers—PRTs and RTDs), and analog signal interrogation (for 4–20 mA loop signals and mV-level outputs). Its extended operational range—from −270 °C (near absolute zero, suitable for cryogenic reference point validation) to +1820 °C (enabling fixed-point calibrations at the freezing point of palladium and beyond)—is achieved through interchangeable sensor interfaces, cold-junction compensation algorithms compliant with ITS-90, and internal reference stability better than ±0.005 °C/°C over 24 hours. Unlike general-purpose handheld thermometers, the milliK functions as a transfer standard: it bridges the gap between laboratory-grade reference instruments and field-deployed sensors by providing direct traceability to SI units via NPL- or NIST-traceable calibration certificates.

Key Features

• Four-input universal sensor interface supporting Type B, R, S, K, E, J, T, N, C, D, and G thermocouples; 2-/3-/4-wire Pt100, Pt1000, and custom RTDs; glass-encapsulated and surface-mount thermistors; and passive/active 4–20 mA and 0–100 mV process signals.
• High-resolution 6.5-digit measurement engine with typical thermal EMF sensitivity down to 0.01 µV and resistance resolution of 0.1 mΩ at 100 Ω full scale.
• Real-time dual-mode visualization: numeric readout with configurable decimal places and trend graphing (time-stamped traces up to 10,000 points per channel).
• Onboard non-volatile memory stores >100,000 measurement records with full metadata—including date/time stamp, sensor ID, operator tag, environmental conditions (optional external RH/T input), and calibration status flags.
• USB 2.0 interface compliant with CDC ACM class for seamless integration into automated calibration management systems; supports SCPI command set for remote control and scripting.
• Rugged aluminum chassis with IP52-rated enclosure, front-panel tactile keys, and optional IEEE-488 (GPIB) or Ethernet (LXI Class C) expansion modules for factory-floor or cleanroom deployment.

Sample Compatibility & Compliance

The milliK accommodates a broad spectrum of temperature sensing elements without requiring external signal conditioners or isolators. Its hardware architecture includes automatic lead resistance compensation, programmable excitation currents (0.1–1 mA for RTDs), and open-circuit detection logic to prevent erroneous readings during probe insertion or disconnection. All measurement modes adhere to internationally recognized standards including IEC 60584-1 (thermocouple EMF tables), IEC 60751 (industrial platinum resistance thermometers), ASTM E230 (standardized thermocouple specifications), and ISO/IEC 17025 requirements for calibration uncertainty evaluation. When operated under controlled ambient conditions (23 ±1 °C, <50% RH), the instrument’s total expanded uncertainty (k=2) for SPRT-equivalent measurements is documented in its accredited calibration report—typically ≤0.015 °C at 0 °C and ≤0.035 °C at 660 °C (Al freezing point).

Software & Data Management

ISOTECH provides the milliK Control Suite—a Windows-based application supporting calibration procedure automation, certificate generation (PDF/XLSX), and audit-ready data archiving. The software implements full 21 CFR Part 11 compliance features: electronic signatures with role-based access control, immutable audit trails with timestamped user actions, and secure password policies. Calibration records include uncertainty budgets calculated per GUM (JCGM 100:2008), traceable to national standards bodies (e.g., NPL, PTB, NIST). Data exports support CSV, XML, and proprietary .MKD formats compatible with LIMS platforms such as LabWare, STARLIMS, and Thermo Fisher SampleManager.

Applications

• Primary calibration of thermocouples against fixed points (e.g., Cu, Al, Ag, Zn) in accordance with CCT-K3 and EURAMET cg-18 guidelines.
• Verification and adjustment of industrial temperature transmitters, smart sensors, and DCS/SCADA input modules in pharmaceutical, aerospace, and power generation facilities.
• Validation of sterilization cycles (autoclaves, depyrogenation tunnels) per ISO 17025 and FDA Annex 15 requirements.
• Research-grade thermophysical property characterization—e.g., thermal expansion coefficient derivation via synchronized length/temperature monitoring.
• Supporting GLP/GMP audits through fully documented, version-controlled calibration workflows and electronic signature enforcement.

FAQ

Does the milliK require annual recalibration?
Yes—ISOTECH recommends annual calibration against traceable standards to maintain stated accuracy and ensure continued compliance with ISO/IEC 17025. A full calibration report with uncertainty budget is issued upon service completion.
Can the milliK measure thermocouples and RTDs simultaneously?
Yes. It supports concurrent acquisition across up to four independent channels, each configurable for different sensor types and units—e.g., Channel 1: Type K thermocouple in °C; Channel 2: Pt100 RTD in Ω; Channel 3: 4–20 mA loop in %FS; Channel 4: mV input referenced to internal cold junction.
Is firmware upgrade supported in the field?
Yes. Firmware updates are delivered via USB stick or network connection using signed binaries; update logs are automatically appended to the audit trail.
What documentation accompanies delivery?
Each unit ships with a UKAS-accredited calibration certificate (valid for 12 months), EC Declaration of Conformity (CE marking), comprehensive user manual (EN/DE/FR/ES), and software license key for milliK Control Suite.
How is measurement uncertainty determined for custom configurations?
Uncertainty is calculated per GUM using type-A (statistical) and type-B (systematic) components—including sensor tolerance, reference stability, noise floor, and environmental influence factors—using ISOTECH’s validated uncertainty calculator embedded in the Control Suite.
