| Brand | Alphalas |
|---|---|
| Origin | Germany |
| Model | BBA-10 |
| Type | Ultra-fast broadband DC-coupled pulse amplifier |
| Bandwidth | DC to >1 GHz (typ.) |
| Rise time | <350 ps (typ.) |
| Gain | up to 40 dB (adjustable) |
| Output voltage swing | ±2.5 V into 50 Ω |
| Input impedance | 50 Ω |
| Output impedance | 50 Ω |
| Power supply | ±15 V DC |
| Operating temperature | 0–50 °C |
| Brand | Alphalas |
|---|---|
| Model | UPD-30-VSG-P |
| Detector Material | Si PIN |
| Spectral Range | 320–900 nm |
| Rise Time | < 30 ps |
| Bandwidth | > 12 GHz |
| Active Area Diameter | 0.2 mm |
| Responsivity | ~0.4 A/W @ 633 nm |
| Output Polarity | Positive |
| Connector | SMA |
| Bias Voltage | 0 V (photovoltaic mode) or –5 V (reverse bias) |
| Operating Temperature | –10 to +50 °C |
