| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Region Category | Domestic (China) |
| Model | LS-909 |
| Pricing | Upon Request |
| Dispersion Method | Dry & Wet Dispersion |
| Instrument Type | Laboratory Laser Particle Size Analyzer |
| Measurement Range | 0.02–3000 µm (wet), 0.1–3000 µm (dry) |
| Repeatability | <0.5% (D50 standard deviation) |
| Measurement Time | 1–2 minutes |
| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Original Equipment Manufacturer (OEM) |
| Instrument Type | Laboratory Wet-Dispersion Laser Diffraction Particle Size Analyzer |
| Measurement Range | 0.1–750 µm |
| Repeatability | <1% (D50 deviation against certified reference material) |
| Measurement Time | 1–2 minutes |
| Dispersion Method | Wet Dispersion |
| Number of Independent Detection Channels | 49 |
| Light Source | He-Ne laser, 2.0 mW output power, wavelength 632.8 nm |
| Sampling Frequency | 1 kHz |
| Operating Environment | 5–35 °C, RH <85% |
| Dimensions (L×W×H) | 838 × 265 × 295 mm (main unit) |
| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic |
| Model | DP-02 |
| Dispersion Method | Wet Dispersion |
| Instrument Type | Laboratory Laser Particle Size Analyzer |
| Measurement Range | 1–1500 µm |
| Repeatability | <3% |
| Measurement Time | 1–2 minutes |
| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic Instrument |
| Model | LS-909 II |
| Dispersion Method | Dry & Wet Dispersion |
| Instrument Type | Laboratory Laser Particle Size Analyzer |
| Measurement Range | 0.02–3000 μm (wet method, sample-dependent) |
| Repeatability | ≤ 0.5% (D50 deviation of certified reference material) |
| Measurement Time | 1–2 minutes per sample (including system preparation and cleaning) |
| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Origin Category | Domestic |
| Model | LS-909E |
| Pricing | Upon Request |
| Dispersion Method | Dry Dispersion |
| Instrument Type | Laboratory Laser Particle Size Analyzer |
| Measurement Range | 0.1–3000 µm |
| Repeatability | <0.5% |
| Measurement Time | 1–2 min |
| Measurement Principle | Full-Range Mie Scattering Theory |
| Sample Introduction | Automated Dry Feeding |
| Optical Source | Imported He-Ne Laser (λ = 632.8 nm, Power >2.0 mW) |
| Detector Channels | 87 (Frontal, Sideward, Large-Angle, Multi-Backward) |
| ADC Resolution | 18-bit |
| Sampling Rate | 10 kHz |
| Alignment System | Intelligent Auto-Alignment (Precision: ±0.2 µm) |
| Environmental Operating Range | 5–35 °C, RH <85% |
| Power Requirements | 200–240 V AC, 50 Hz (Host: 60 W |
| Dispersion System | 2000 W) |
| Dimensions (L×W×H) | 1320 × 340 × 360 mm (Host) |
| Brand | OMECC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic |
| Model | LS-609 |
| Pricing | Upon Request |
| Dispersion Method | Wet Dispersion |
| Instrument Type | Laboratory Laser Particle Size Analyzer |
| Measurement Range | 0.1–1000 µm |
| Repeatability | <1% (D50 deviation of certified reference material) |
| Measurement Time | 1–2 minutes |
| Light Source | Imported He-Ne laser, λ = 632.8 nm, output power >2.0 mW |
| Detection Channels | 49 independent photodetectors |
| Scanning Frequency | 1 kHz |
| Alignment Accuracy | ±0.5 µm (intelligent auto-alignment) |
| Environmental Operating Conditions | 5–35 °C, RH <85% |
| Data Output | Particle size distribution table & curve, D10/D50/D90, specific surface area, span, etc. |
| Dimensions (L×W×H) | 838×265×295 mm (main unit) |
| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Region Category | Domestic (China) |
| Model | PIP9.1 |
| Pricing | Available Upon Request |
| Measurement Principle | Digital Microscopy-Based Image Analysis |
| Test Range | 0.5–3000 µm |
| Repeatability Error | <3% |
| Output Data | Particle Size Distribution Table & Curve (by Equivalent Area Circle, Equivalent Short Diameter, etc.), Roundness Distribution Table & Curve, D10/D50/D90, Specific Surface Area (calculated), Mean Roundness, Roundness Range, Segment-Averaged Roundness, Representative Single-Particle Images |
| Core Hardware | Olympus Biological Microscope (Japan), 1.3 MP CMOS Sensor, USB 2.0 Interface |
| Key Automation | Auto-Focus, Auto-Field Scanning, Auto-Illumination Adjustment |
| Compliance Context | Aligns with GB/T 6408–2008 (Diamond Micropowder Standard), Supports GLP Documentation Workflow |
| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic |
| Model | Topsizer |
| Dispersion Method | Dry & Wet Dispersion |
| Instrument Type | Laboratory Laser Particle Size Analyzer |
| Measurement Range | 0.02–2000 µm (wet), 0.1–2000 µm (dry) |
| Repeatability | ≤0.5% (D50 of standard reference material) |
| Measurement Time | ≤10 s (typical) |
| Optical Principle | Full-range Mie scattering theory |
| Detector Channels | 98-channel 3D detection system (forward, side, large-angle, and backward scattering) |
| Scattering Angle Range | 0.016°–140° |
| Dual Light Sources | He-Ne laser (632.8 nm) + blue semiconductor laser (466 nm) |
| Laser Stability | Power fluctuation <0.5%, polarization ratio >500:1, TEM₀₀ mode >95% |
| Optical Platform | Monolithic high-precision aluminum alloy base |
| Optical Design | Sealed linear optical path with post-Fourier single-lens transformation |
| Fourier Lens Focal Length | Extended for enhanced large-particle sensitivity |
| Software Compliance | Fully compliant with FDA 21 CFR Part 11 and GMP Annex 11 requirements for computerized systems (user roles, audit trail, electronic signatures, data integrity) |
| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Direct Manufacturer |
| Region Category | Domestic (China) |
| Model | PIP8.1 |
| Price | Upon Request |
| Measurement Range | 0.5–3000 µm |
| Repeatability Error | <3% |
| Output Data | Particle size distribution table & curve, D10/D50/D90, specific surface area, aspect ratio statistics, PPC (Particle Profile Classification), equivalent diameter based on area-equivalent circle and minimum bounding rectangle short axis |
| Brand | OMEC |
|---|---|
| Origin | Guangdong, China |
| Manufacturer Type | Manufacturer |
| Product Category | Domestic |
| Model | Topsizer Plus |
| Pricing | Upon Request |
| Dispersion Method | Dry & Wet Dispersion |
| Instrument Type | Laboratory Laser Particle Size Analyzer |
| Measurement Range | 0.01–3600 µm (wet), 0.1–3600 µm (dry) |
| Repeatability | ≤0.5% RSD (D50 of standard reference material) |
| Measurement Time | ≤10 seconds per analysis |
