| Brand | Starwood |
|---|---|
| Model | SDW-922 |
| Measurement Principle | Light Obscuration (LO) |
| Particle Size Range | 1–600 µm |
| Sensitivity | 1 µm(c) or 4 µm(c) |
| Flow Rate | 5–500 mL/min |
| Operating Pressure | 0.1–10 MPa (up to 42 MPa with optional pressure reducer) |
| Viscosity Limit | ≤650 cSt |
| Counting Accuracy | ±0.5 ISO cleanliness code |
| Coincidence Limit | 40,000 particles/mL |
| Sample Temperature Range | 0–80 °C |
| Ambient Operating Temperature | −20–60 °C |
| Storage Temperature | −30–100 °C |
| Power Supply | AC 220 V ±10%, 50/60 Hz or DC 12–40 V |
| IP Rating | IP56 |
| Dimensions | 115 × 85 × 60 mm |
| Weight | 1 kg |
| Data Storage | 1,000 internal test records + USB external storage |
| Communication Interfaces | RS232, RS485 (Modbus RTU), USB |
| Optional Modules | Integrated temperature sensor (1–100 °C, ±1 °C), water activity sensor (1–100 %RH, ±1 %RH), absolute humidity sensor (1–360 ppm, ±1 ppm), 4G/5G remote monitoring |
