| Origin | Jilin, China |
|---|---|
| Manufacturer Type | Authorized Distributor |
| Origin Category | Domestic (China) |
| Model | TLS-1KN |
| Pricing | Upon Request |
| Max Load Capacity | 1 kN |
| Force Accuracy | ±0.5% FS |
| Force Resolution | 0.1 N |
| Speed Range | 0.05–500 mm/min |
| Speed Accuracy | ±0.5% |
| Large-Deformation Measurement Range | 20–1000 mm |
| Large-Deformation Accuracy | ±0.5% |
| Crosshead Travel | 1000 mm |
| Displacement Accuracy | ±0.5% of reading |
| Effective Test Width | 550 mm |
| Indentor Diameter (for indentation hardness) | Φ200 mm |
| Support Plate Dimensions | 380 × 380 mm, with 6 mm diameter holes on 20 mm centers |
| Power Supply | AC 220 V, 1 kW |
