| Brand | Langbo |
|---|---|
| Model | LBCY-100 |
| Chamber Internal Dimensions (D×W×H) | 450×450×500 mm |
| External Dimensions (D×W×H) | 1050×870×1670 mm |
| Power Consumption | 3 kW |
| Temperature Range | 0–70 °C |
| Humidity Range | 50–95% RH |
| Ozone Concentration Range | 0–200 ppm (standard), optional 0–500 ppm |
| Temperature Uniformity | ±0.5 °C |
| Sample Rack Rotation | 360° continuous, 1 rpm |
| Gas Flow Velocity | 12–16 mm/s |
| Control System | Microprocessor-based LED display controller with PID algorithm |
| Ozone Monitoring | Imported electrochemical ozone analyzer with 4–20 mA analog output and RS232 interface |
| Ozone Generator | Silent corona discharge tube |
| Construction | Exterior — powder-coated cold-rolled steel |
| Door Seal | High-temp/low-temp resistant silicone rubber |
| Safety Protections | Over-temperature, over-current, leakage current, motor overheat, short-circuit protection |
| Supply Voltage | AC 380 V ±10%, 50 Hz ±0.5 Hz, 3-phase 5-wire |
| Compliance | GB/T 7762–2003, GB/T 3642–92 |
| Operating Environment | 5–30 °C, ≤85% RH |
